XSDM600539 – Telemecanique
On order174,78 € excl. VAT
216,73 € incl. VAT
Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 24...240VAC/DC, terminals - Telemecanique
Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 24...240VAC/DC, terminals.
This product is compatible with XSZBD10
SPECIFICATIONS
Main
Body type
Fixed
product specific application
Not applicable
Series name
General purpose
sensor name
XSD
Complementary
Product certifications
CCC
[us] rated supply voltage
12...240 V AC/DC
cable entry
1 entry tapped for Pg 13.5 cable gland
detection face
Frontal
marking
CE
Discrete output function
1 NO or 1 NC programmable
Enclosure material
Plastic
Detector flush mounting acceptance
Non flush mountable
Material
Plastic
switching frequency
<= 10 Hz
switching capacity in ma
5...100 mA DC, 5...500 mA AC
Front material
Plastic
electrical connection
Screw-clamp terminals
output circuit type
AC/DC
Sensing range
> 40...60 mm
Sensor type
Inductive proximity sensor
Sensor design
Form 80 x 80 x 40
Wiring technique
2-wire
Size
40 mm
Type of output signal
Discrete
Environment
ip degree of protection
IP67
Range of product
Telemecanique Inductive proximity sensors XS
