XSDC607139 – Telemecanique
On order156,13 € excl. VAT
193,60 € incl. VAT
Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 12...48 VDC, terminals - Telemecanique
Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 12...48 VDC, terminals.
This product is compatible with XSZBD10
SPECIFICATIONS
Main
Body type
Fixed
product specific application
Not applicable
Series name
General purpose
sensor name
XSD
Complementary
Product certifications
CCC
[us] rated supply voltage
12...48 V DC
cable entry
1 entry tapped for Pg 13.5 cable gland
detection face
Frontal
marking
CE
Discrete output function
1 NO
Enclosure material
Plastic
Detector flush mounting acceptance
Non flush mountable
Material
Plastic
switching frequency
<= 20 Hz
switching capacity in ma
1.5...100 mA
Front material
Plastic
electrical connection
Screw-clamp terminals
output circuit type
DC
Sensing range
> 40...60 mm
Sensor type
Inductive proximity sensor
Sensor design
Form 80 x 80 x 40
Wiring technique
2-wire
Size
40 mm
Type of output signal
Discrete
Environment
ip degree of protection
IP67
Range of product
Telemecanique Inductive proximity sensors XS
