XS9C2A2A1M12 – Telemecanique
On order58,26 € excl. VAT
72,24 € incl. VAT
Inductive proximity sensors XS, inductive sensor XS9 40x40x70, PBT, Sn25 mm, 24 VDC, M12 - Telemecanique
Inductive proximity sensors XS, inductive sensor XS9 40x40x70, PBT, Sn25 mm, 24 VDC, M12.
This product is compatible with XZCP1141L5, XZCP1241L5
SPECIFICATIONS
Main
Body type
Fixed
Series name
General purpose
sensor name
XS9
Complementary
Product certifications
CSAUL
Analogue output range
0...10 V
[us] rated supply voltage
24 V DC with reverse polarity protection
Current consumption
0...4 mA no-load
detection face
5 positions turret head
marking
CE
Device application
Not applicable
Enclosure material
PBT
Detector flush mounting acceptance
Non flush mountable
Material
Plastic
Output current drift
5 PERCENTAGE
Front material
PBT
electrical connection
Male connector M12, 4 pins
output circuit type
DC
linearity error
<= 3% of Sr
Sensing range
> 15...40 mm
Sensor type
Inductive proximity sensor
Shock resistance
50 gn for 11 ms conforming to IEC 60068-2-27
Sensor design
Form 40 x 40 x 70
Status led
Output state: 1 LED (yellow)
Wiring technique
3-wire
Size
70 mm
Type of output signal
Analogue
Environment
ip degree of protection
IP67 conforming to IEC 60529, IP65 conforming to IEC 60529, IP69K conforming to DIN 40050
Range of product
Telemecanique Inductive proximity sensors XS
vibration resistance
25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
