9007FTSB2 - Limit switch, 9007, 9007FT foundry standard, spring return - Telemecanique - Limit switch, 9007, 9007FT foundry standard, spring return, CW+CCW, 1/2
9007FTSB2 - Limit switch, 9007, 9007FT foundry standard, spring return - Telemecanique - Limit switch, 9007, 9007FT foundry standard, spring return, CW+CCW, 1/2

9007FTSB2 – Telemecanique

On order
525,89 € excl. VAT
652,10 € incl. VAT
Limit switch, 9007, 9007FT foundry standard, spring return, CW+CCW, 1/2" NPT - Telemecanique
 In cart
652,10 €
Limit switch, 9007, 9007FT foundry standard, spring return, CW+CCW, 1/2" NPT
SPECIFICATIONS
Main
Body type Fixed
Device short name 9007T/FT
Series name Severe duty foundry
switch function SPDT-DB
head type Rotary head
Complementary
Product or component type Limit switch
nema degree of protection NEMA 1 conforming to Nema type 250, NEMA 2 conforming to Nema type 250, NEMA 4 conforming to Nema type 250, NEMA 12 conforming to Nema type 250, NEMA 13 conforming to Nema type 250
cable entry 1 entry for 1/2" - 14 NPT conforming to ANSI B1.20.1
Contacts material Silver flashed copper
Device application Standard foundry switch
contact operation Snap action
Electrical shock protection class Class 0 conforming to IEC 61140
Fixing mode By the body
body material Cast zinc
function available 2 stages sequential
Type of operator Spring return without operating lever
contact code designation A600, AC (Ue = 600 V) Ie = 5 A conforming to NEMA rating designation, A600, AC (Ue = 480 V) Ie = 6.25 A conforming to NEMA rating designation, A600, AC (Ue = 240 V) Ie = 12.5 A conforming to NEMA rating designation, A600, AC (Ue = 120 V) Ie = 20 A conforming to NEMA rating designation, P600, DC (Ue = 600 V) Ie = 0.2 A conforming to NEMA rating designation, P600, DC (Ue = 250 V) Ie = 1 A conforming to NEMA rating designation, P600, DC (Ue = 120 V) Ie = 5 A conforming to NEMA rating designation
Contacts usage Not applicable
repeat accuracy +/- 0.004 in linear travel of cam on 1.5 in lever arm
Positive opening Without
electrical connection Screw-clamp terminals AWG 22...AWG 12
Movement of operating head Rotary
Switch actuation CW and CCWfrom left or right
Type of approach Lateral approach
Shock resistance 30 gn for 9 ms conforming to IEC 60068-2-27
Terminals description iso n°1 A (left side contact)B (right side contact)
Environment
ip degree of protection IP67 conforming to IEC 60529
Range of product 9007
vibration resistance 10 gn (f= 10-55 Hz) conforming to IEC 60068-2-6
protective treatment Corrosion resistant gray paint
