ZCMD81L5 - Limit switch body, Limit switches XC Standard, ZCMD, 2NC+2 NO, gold, snap action, connection, 5 m - Schneider Electric
Expected in 2-4 weeks
74,16 €
Text About:
Limit switch body, Limit switches XC Standard, ZCMD, 2NC+2 NO, gold, snap action, connection, 5 m - Schneider Electric
SPECIFICATIONS
Main
Associated head
ZCE01
Body type
Fixed
design
Miniature
Device short name
ZCMD
cable length
5 m
[ui] rated insulation voltage
400 V (pollution degree 3) conforming to IEC 60947-5-1
Series name
Standard format
Complementary
product compatibility
XCMD
cable composition
9 x 0.34 mm²
Handle front plate colour
50 mm
Product or component type
Limit switch body
[uimp] rated impulse withstand voltage
4 kV conforming to IEC 60947-1
Contacts insulation form
Zb
Contacts material
Gold plated contacts
contact operation
Snap action
Contacts type and composition
2 NC + 2 NO
body material
Zamak
width (w)
30 mm
Net weight
0.525 kg
depth
16 mm
electrical durability
5000000 cycles, DC-13 120 V, 1 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
Positive opening
Without
electrical connection
Fixed cable
Maximum resistance across terminals
25 mOhm conforming to IEC 60255-7 category 3
Minimum actuation speed
0.01 m/min
Poles description
4
Short-circuit protection
6 A cartridge fuse, type gG
Wire insulation material
PvR
Environment
Ambient air temp for storage/transportation
-40…70 °C
Range of product
Telemecanique Limit switches XC Standard
