ZB6E1A - Contact block, Harmony XB6, single contact, for head 16mm, silver alloy, pins for printed circuit board, 1NO - Schneider Electric
Expected in 2-4 weeks
5,15 €
Text About:
Contact block, Harmony XB6, single contact, for head 16mm, silver alloy, pins for printed circuit board, 1NO - Schneider Electric
SPECIFICATIONS
Main
Device short name
ZB6
[ui] rated insulation voltage
250 V (pollution degree 3) conforming to EN/IEC 60947-1
contact block type
Single
Complementary
[ie] rated operational current
3 A at 120 V, AC-15, B300
1.5 A at 240 V, AC-15, B300
0.1 A at 250 V, DC-13, R300
0.22 A at 125 V, DC-13, R300
1.5 A at 240 V, AC-15, B300
0.1 A at 250 V, DC-13, R300
0.22 A at 125 V, DC-13, R300
Product certifications
GOST
CSA
CCC
UL
CSA
CCC
UL
Product or component type
Contact block
[uimp] rated impulse withstand voltage
4 kV conforming to EN/IEC 60947-1
Connections - terminals
Pins for printed circuit board
Contacts material
Silver alloy (Ag/Ni)
contact operation
Slow-break
Contacts type and composition
1 NO
Operating travel
2 mm (NO changing electrical state)
3.5 mm (total travel)
3.5 mm (total travel)
Sale per indivisible quantity
10
electrical reliability
Λ = 10exp(-8) at 5 V and 1 mA with confidence level of 90 % conforming to EN/IEC 60947-5-4
Net weight
0.004 kg
mechanical durability
5000000 cycles
electrical durability
1000000 cycles, AC-15 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
Positive opening
With conforming to EN/IEC 60947-5-1 appendix K
Operating force
1.6 N NO changing electrical state
Shock resistance
30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Short-circuit protection
6 A cartridge fuse type gG
Terminals description iso n°1
(3-4)NON
Environment
Ambient air temp for storage/transportation
-40…70 °C
ip degree of protection
IP20 conforming to IEC 60529
Range of product
Harmony XB6
ambient air temperature for operation
-25…70 °C
standards
EN/IEC 60947-1
EN/IEC 60947-5-4
JIS C 852
EN/IEC 60947-5-1
CSA C22.2 No 14
JIS C 4520
UL 508
EN/IEC 60947-5-4
JIS C 852
EN/IEC 60947-5-1
CSA C22.2 No 14
JIS C 4520
UL 508
vibration resistance
+/- 3 mm (f= 2…500 Hz) conforming to IEC 60068-2-6
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
protective treatment
TC
