XVLA125 - LED pilot light with black bezel, Harmony XVL, yellow, 8mm, IP40, protruding LED, faston connectors, 12V - Schneider Electric

Expected in 2-4 weeks

9,46 € excl. VAT

11,54 € incl. VAT

Text About:

LED pilot light with black bezel, Harmony XVL, yellow, 8mm, IP40, protruding LED, faston connectors, 12V - Schneider Electric

In cart

11,54 €

SPECIFICATIONS

Main

[ui] rated insulation voltage 50 V conforming to IEC 60947-1

component name XVL

Complementary

Product certifications UL
CSA

Handle front plate colour 12 mm

mounting diameter 8 mm

Product or component type LED pilot light with black bezel

[us] rated supply voltage 12 V

Bulb lifespan 100000 h

Current consumption 18 mA

Connections - terminals Tag for Faston connectors: 2.8 x 0.5 mm
Tag for soldering connectors

width (w) 12 mm

Light block colour Yellow

Net weight 0.003 kg

depth 34 mm

Nominal voltage limit 0.8...1.1 Un

light source Protruding LED

Supply circuit type DC

Protection type Integral ballast resistor
Built-in by diode

Terminals description iso n°1 (X1-X2)PL

Environment

Ambient air temp for storage/transportation -40…70 °C

ip degree of protection IP40 conforming to IEC 60529
IP40 conforming to NF C 20-010

Range of product Harmony XVL

ambient air temperature for operation -25…70 °C

overvoltage category Class 3 conforming to IEC 60536
Class 3 conforming to NF C 20-030

protective treatment TC
