XUVU06M3KSNM8 - Photoelectric sensors XU, ultrasonic sensor label fork 60x3, 12...24 V DC, PNP/NPN NO/NC connect M8 - Schneider Electric

Expected in 2-4 weeks

629,00 € excl. VAT

767,38 € incl. VAT

Text About:

Photoelectric sensors XU, ultrasonic sensor label fork 60x3, 12...24 V DC, PNP/NPN NO/NC connect M8 - Schneider Electric

In cart

767,38 €

SPECIFICATIONS

Main

Passage depth 69 mm

Passage width 3 mm

product specific application Detection of transparent labels

Series name Application packaging

sensor name XUV

detection system Thru beam

electronic sensor type Photo-electric sensor

Complementary

[sn] nominal sensing distance 3 mm thru beam

Accuracy +/- 0.20 mm at 120 m/min

Product certifications cULus
CE

Handle front plate colour 92.5 mm

[us] rated supply voltage 12...24 V DC with reverse polarity protection

maximum voltage drop <2 V (closed state)

Output type Solid state

Discrete output function 2 NO/NC programmable

Enclosure material Zinc alloy

lens material PC

Material Metal

width (w) 18 mm

supply voltage limits 10…30 V DC

switching frequency <= 1500 Hz

Net weight 0.13 kg

Discrete output type PNP and NPN

Maximum delay first up 30 ms

Maximum delay recovery 0.3 ms

switching capacity in ma <= 100 mA (overload and short-circuit protection)

depth 47 mm

Maximum delay response 0.3 ms

type of setting Without

electrical connection 1 male connector M8, 4 pins

Maximum passing speed of object 180 m/min

Minimum distance between labels 2 mm

Minimum label length 2 mm

Shock resistance 30 gn (duration = 11 ms) conforming to IEC 60068-2-27

Setting-up Numeric potentiometer

Sensor design Fork

Status led Output state: 1 LED (yellow)
Adjustment mode and keypad locking: 1 LED (red)

Wiring technique 4-wire

Type of output signal Discrete

Supply circuit type DC

Environment

Ambient air temp for storage/transportation -20…70 °C

Emission Ultrasonic

ip degree of protection IP65 conforming to IEC 60529

Range of product Telemecanique Photoelectric sensors XU

ambient air temperature for operation 5…55 °C

vibration resistance 7 gn, amplitude = +/- 1.5 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
