Main
product specific application
-
Series name
Application assembly
Application material handling
sensor name
XUK
detection system
Polarised reflex
electronic sensor type
Photo-electric sensor
Complementary
[sn] nominal sensing distance
12 m polarised reflex need reflector XUZC50HP
Product certifications
Ecolab
CE
cULus
Handle front plate colour
50 mm
[us] rated supply voltage
24 V DC with reverse polarity protection
Current consumption
<= 60 mA no-load
maximum voltage drop
<2 V
Output type
Solid state
Discrete output function
1 NO or 1 NC programmable
Enclosure material
ABS/PC
lens material
PMMA
Material
Plastic
width (w)
23 mm
supply voltage limits
10…30 V DC
switching frequency
<= 2000 Hz
Net weight
0.035 kg
Discrete output type
PNP
Maximum delay first up
300 ms
Maximum delay recovery
2 ms
switching capacity in ma
<= 100 mA (overload and short-circuit protection)
depth
50 mm
Maximum delay response
2 ms
Maximum sensing distance
14 m polarised reflex need reflector XUZC50HP
electrical connection
1 male connector M12, 4 pins
Shock resistance
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
Setting-up
Using teach button or remote teaching
Sensor design
Compact 50 x 50
Status led
1 LED (yellow) for output state
1 LED (green/yellow) for supply on/output state
Wiring technique
4-wire
Type of output signal
Discrete
Supply circuit type
DC
Environment
Ambient air temp for storage/transportation
-20…80 °C
Emission
Red laser polarised reflex class 1
ip degree of protection
IP67 conforming to IEC 60529
IP69K conforming to DIN 40050
Range of product
Telemecanique Photoelectric sensors XU
ambient air temperature for operation
-20…60 °C
-20…50 °C
vibration resistance
7 gn, amplitude = +/- 1.5 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
