XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m - Schneider Electric

Expected in 2-4 weeks
XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m - Schneider Electric - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m - Schneider Electric - 0
XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m - Schneider Electric
86,94 € excl. VAT
107,81 € incl. VAT
Text About:
Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m - Schneider Electric
107,81 €
SPECIFICATIONS
Main
product specific application -
cable length 2 m
Series name General purpose single mode
sensor name XUB
detection system Diffuse
electronic sensor type Photo-electric sensor
Complementary
[sn] nominal sensing distance 0.1 m diffuse
length [l] 76 mm
Product certifications UL
CE
CSA
Add on output Without
[us] rated supply voltage 12...24 V DC with reverse polarity protection
Current consumption 35 mA no-load
maximum voltage drop <1.5 V (closed state)
diameter 18 mm
Output type Solid state
Discrete output function 1 NC
Enclosure material Nickel plated brass
lens material PMMA
Material Metal
supply voltage limits 10…36 V DC
switching frequency <= 500 Hz
Net weight 0.05 kg
Discrete output type PNP
Maximum delay first up 15 ms
Maximum delay recovery 1 ms
switching capacity in ma <= 100 mA (overload and short-circuit protection)
Maximum delay response 1 ms
Maximum sensing distance 0.15 m diffuse
electrical connection Cable
Line of sight type 90° lateral
Shock resistance 30 gn (duration = 11 ms) conforming to IEC 60068-2-27
Setting-up Without sensitivity adjustment
Sensor design Cylindrical M18
Status led 1 LED (yellow) for output state
Wiring technique 3-wire
Type of output signal Discrete
Supply circuit type DC
Wire insulation material PvR
Environment
Ambient air temp for storage/transportation -40…70 °C
Emission Infrared diffuse
ip degree of protection IP67 double insulation conforming to IEC 60529
IP65 double insulation conforming to IEC 60529
Range of product Telemecanique Photoelectric sensors XU
ambient air temperature for operation -25…55 °C
vibration resistance 7 gn, amplitude = +/- 1.5 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
About this product

The XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m is developed to cover the expectations of industry experts, such as switchboard fabricators, electrical installers, upkeep firms, and OEMs. XUB4BPBWL2 provides superior capability and worth for consultants in the control systems industry. This Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m and other Photoelectric Sensors XU from Schneider Electric are on offer at the unbeatable price and procurement time through BaltElec, a respected reseller serving professionals in their obtaining needs.

Technicians who have adopted Schneider Electric Photoelectric Sensors XU have persistently commended the manufacturer’s sturdiness. It has been stated that the excellent energy-efficiency of XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m extends to a diverse range of use. Its supreme qualities make it well-suited solution for different applications, ensuring your industrial, tertiary and automation projects success.

Our experts focuses in catering industrial and tertiary professionals’ needs. We grasp the customized specifications and demands of our patrons in the industry. By teaming up with our experts, our partners access access to the leading costs and stock of premium products like XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m from Schneider Electric at a competitive price. Our registered accounts enjoy extra discounts and priority service.

Take action and buy XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m at our trusted and straightforward platform. Don't delay in making this savvy selection that promises the greatest quality and adheres to the targeted requests of suppliers like your organization.

Should there be any worries or concerns about XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m or any other Schneider Electric products, reach out to us or refer to our Frequently Asked Queries section below. We have curated answers to typical requests for information to support you further in making an well-informed decision about industrial and tertiary electrical components.

Remember, XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m from Schneider Electric is reliable, economical, and premier to its counterparts in the Photoelectric Sensors XU category. Make it a part of your inventory today. Obtain at BaltElec, your steady distributor for all your Schneider Electric.

In our Baltelec.eu cyber store you will encounter Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m - XUB4BPBWL2 worth 106.07 €, which will be a reliable and state-of-the-art solution for your preferences. This produce is fabricated by the Schneider Electric brand using the up-to-the-minute technologies and aligns with the maximum standards of security and efficacy. We propose goods from the Photoelectric Sensors XU category that associate longevity and usefulness, which is an top-notch preference for various intents. Without consideration of whether you call for gear for small construction or for skilled industrial exertion, Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m will be a faithful aide in your work.

Baltelec labors to make the procuring process as easy and fast as feasible for our buyers. We offer detailed descriptions and high-quality snapshots of Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m so that you can make an enlightened choice. A team of authorities is always ready to help you with any enquiries in the Photoelectric Sensors XU section related to the preferment and use of equipment. We are trusting that Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m will meet your needs and become an important element of your apparatus for just 106.07 €.

FAQ about XUB4BPBWL2 - Photoelectric sensors XU, XUB, diffuse, 90°, Sn 0.1 m, 12...24 VDC, cable 2 m:
