XS7C4A1DPG13 - Inductive proximity sensors XS, inductive sensor XS7 40x40x117, PBT, Sn15 mm, 12...48 VDC, terminals - Telemecanique

Pending restock

Text About:

Inductive proximity sensors XS, inductive sensor XS7 40x40x117, PBT, Sn15 mm, 12...48 VDC, terminals - Telemecanique

SPECIFICATIONS

Main

Body type Fixed

Series name General purpose

sensor name XS7

Complementary

[sn] nominal sensing distance 15 mm

Cable entry number 1 tapped entry for Pg 13.5 cable gland

length [l] 40 mm

Product certifications CCC
CSA
UL

Handle front plate colour 40 mm

[us] rated supply voltage 12...48 V DC with reverse polarity protection

maximum residual current 0.6 mA open state

maximum voltage drop <4.2 V (closed)

detection face 5 positions turret head

marking CE

Device application -

Discrete output function 1 NO or 1 NC programmable

Enclosure material PBT

Detector flush mounting acceptance Flush mountable

Differential travel 3...15% of Sr

Material Plastic

width (w) 117 mm

supply voltage limits 10…58 V DC

switching frequency <= 300 Hz

Net weight 0.244 kg

Maximum delay first up 7.5 ms

Maximum delay recovery 1.8 ms

switching capacity in ma 1.5...100 mA with overload and short-circuit protection

Maximum delay response 1.2 ms

repeat accuracy <= 3% of Sr

Front material PBT

electrical connection Screw-clamp terminals, 4 x 1.5 mm²

output circuit type DC

Operating zone 0…12 mm

Sensor type Inductive proximity sensor

Shock resistance 50 gn for 11 ms conforming to EN 60068-2-27

Sensor design Form 40 x 40 x 117

Status led Output state: 1 LED (yellow)

Wiring technique 2-wire

Size 117 mm

Type of output signal Discrete

Environment

Ambient air temp for storage/transportation -40…85 °C

ip degree of protection IP67 conforming to IEC 60529
IP65 conforming to IEC 60529
IP69K conforming to DIN 40050

Range of product Telemecanique Inductive proximity sensors XS

ambient air temperature for operation -25…70 °C

vibration resistance 25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
