XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O - Telemecanique

Pending restock
XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O - Telemecanique - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O - Telemecanique - 0
XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O - Telemecanique
184,11 € excl. VAT
228,29 € incl. VAT
Text About:
Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O - Telemecanique
228,29 €
SPECIFICATIONS
Main
Device short name XMLB
pressure actuator Piston
Fluid connection type G 1/4 (female) conforming to ISO 228
product specific application -
[ui] rated insulation voltage 300 V conforming to UL 508
500 V conforming to EN/IEC 60947-1
300 V conforming to CSA C22.2 No 14
controlled fluid Hydraulic oil (0…160 °C)
Pressure switch type of operation Regulation between 2 thresholds
pressure rating 300 bar
pressure sensor type Electromechanical pressure sensor
Complementary
[in] rated current 3 A, B300, AC-15 (Ue = 120 V) conforming to EN/IEC 60947-5-1
1.5 A, B300, AC-15 (Ue = 240 V) conforming to EN/IEC 60947-5-1
0.1 A, R300, DC-13 (Ue = 250 V) conforming to EN/IEC 60947-5-1
local display With
Product certifications BV
EAC
CCC
LROS (Lloyds register of shipping)
CSA
UL
Adjustable range of switching point on falling pressure 2.6…263 bar
Auxiliary contacts operation Snap action
Handle front plate colour 113 mm
Product or component type Electromechanical pressure sensor
[uimp] rated impulse withstand voltage 6 kV conforming to EN/IEC 60947-1
Adjustable range of switching point on rising pressure 22…300 bar
Contacts material Silver contacts
Enclosure material Zinc alloy
Contacts type and composition 1 C/O
Electrical shock protection class Class I conforming to IEC 1140
Class I conforming to IEC 536
Class I conforming to NF C 20-030
width (w) 35 mm
Destruction pressure 1350 bar
Electrical circuit type Control circuit
Net weight 0.78 kg
setting External
Operating position Any position
terminal block type 4 terminals
depth 75 mm
mechanical durability 3000000 cycles
repeat accuracy 2 %
Materials in contact with fluid FPM, FKM
Steel
Brass
PTFE
electrical connection 1 male connector EN 175301-803-A (ex DIN43650), 4 pins
Maximum operating rate 60 cyc/mn
Maximum resistance across terminals 25 mOhm conforming to IEC 255-7 category 3
25 mOhm conforming to NF C 93-050 method A
Maximum permissible accidental pressure 675 bar
Maximum permissible pressure - per cycle 375 bar
Possible differential maximum at high setting 200 bar
Possible differential minimum at high setting 37 bar (- 1 bar, + 4 bar)
Possible differential minimum at low setting 19.4 bar (- 1.5 bar, + 1.7 bar)
Shock resistance 50 gn conforming to IEC 60068-2-27
Scale type Adjustable differential
Short-circuit protection 10 A cartridge fuse, type gG (gl)
Environment
Ambient air temp for storage/transportation -40…70 °C
ip degree of protection IP65 conforming to EN/IEC 60529
Range of product Telemecanique Pressure sensors XM
ambient air temperature for operation -25…70 °C
standards UL 508
EN/IEC 60947-5-1
CSA C22.2 No 14
CE
vibration resistance 4 gn conforming to IEC 60068-2-6 (f = 30…500 Hz)
protective treatment TC standard version
About this product

The XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O is fashioned to respond to the demands of industry specialists, such as control panel builders, electric engineers, maintenance service providers, and original manufacturers. XMLB300D2C11 grants unmatched reliability and worth for developers in the power systems industry. This Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O and other Pressure Switch XMLB from Schneider Electric are in stock at the lowest cost and lead time through BaltElec website, a reputable vendor aiding consultants in their acquisition needs.

Consumers who have used Schneider Electric Pressure Switch XMLB have commonly admired the manufacturer’s solidity. It has been mentioned that the unmatched functionality of XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O extends to a extensive scope of functions. Its supreme properties make it well-suited solution for wide-ranging specifications, guaranteeing the success of your industrial, tertiary, and automation contracts.

Our professionals centers in serving industrial and tertiary professionals’ needs. We know the distinct expectations and requirements of our customers in the industry. By joining forces with our team, your enterprise acquire access to the superior price and lead time of the top-of-the-line products like XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O from Schneider Electric at a competitive price. Registered users take pleasure in added discounts and dedicated support.

Don't wait and get XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O at our secure and easy-to-use website. Don't delay in making this intelligent resolution that assures the best quality and meets the special needs of suppliers like your company.

In case you have any problems or concerns about XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O or any other Schneider Electric products, message us or refer to our Assistance center section below. We have brought together answers to popular problems to advise you further in making an smart decision about industrial and tertiary electrical components.

Remember, XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O from Schneider Electric is credible, low-cost, and exceptional to other manufacturers in the Pressure Switch XMLB category. Don't hesitate to make it a part of your installation today. Order at Baltelec webstore, your respected merchant for all your Pressure Switch XMLB.

In our Baltelec.eu web store you will encounter Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O - XMLB300D2C11 worth 224.61 €, which will be a steadfast and new solution for your desires. This object is fabricated by the Schneider Electric brand using the current technologies and conforms to the optimal standards of security and efficiency. We give merchandise from the Pressure Switch XMLB category that blend sturdiness and functionality, which is an first-rate option for various functions. Independent of whether you need instruments for small production or for proficient industrial application, Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O will be a safe adjunct in your project.

Baltelec strives to make the getting process as effortless and fast as accomplishable for our customers. We offer detailed portrayals and high-quality photographs of Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O so that you can make an knowledgeable choice. A team of specialists is always ready to help you with any issues in the Pressure Switch XMLB section related to the selection and use of commodities. We are guaranteed that Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O will meet your standards and become an significant element of your device for just 224.61 €.

What People Ask about XMLB300D2C11:

  • Why should I buy XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O from Baltelec.eu online store?

    When your purchase Schneider Electric XMLB300D2C11 from Baltelec website, you will get original quality Schneider Electric Pressure Switch XMLB products at the best prices and lead time. Furthermore, loyal buyersget further discounts and expedited requests handling.

  • Schneider Electric XMLB300D2C11 meets the specification of my contract?

    To make sure that Schneider Electric Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O is suitable for your project, we provide detailed details concerning product's specs, features, and in some cases 3D models as well. You can access this information on the dedicated page of the product model. If you seek additional help, our support team representative is prepared to help you in making an informed choice.

  • What warranty coverage is offered for XMLB300D2C11?

    BALTELEC stands for the quality of the products we offer. The default guarantee coverage for Schneider Electric Pressure Switch XMLB including XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O is 12 months. However, it is subject according to the specific item, category, and might be extended. You can discover specific warranty details on the XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O product page or by reaching out to our customer support team.

  • Do you offer worldwide shipping for Schneider Electric XMLB300D2C11 including other Schneider Electric products?

    Yes. Apart from serving Estonia, Latvia, Lithuania and other European Union countries, we offer global shipping for Schneider Electric Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O. Please keep in mind that shipping options, costs, and shipping times might differ based on the destination. For volume orders, kindly contact BALTELEC sales team.

  • Do Schneider Electric MBC provided by Baltelec.eu adhere to global norms for security and reliability?

    Of course. All Schneider Electric items offered at Baltelec.eu web store adhere to international standards such as IEC 60898-1 standard and carry the CE mark. These standards guarantee that the items meet stringent safety, technological, dependability, and performance requirements.

  • Can BaltElec provide assistance on incorporating renewable energy solutions, such as solar energy systems or wind power converters, into my projects?

    Yes, sure!  Baltelec online store recognizes the relevance of clean energy incorporation within community. Our team of experts can assist you in choosing the right Schneider Electric products, to incorporate them into your renewable energy projects}. We can provide recommendations on integrating solar power systems, wind energy converters, and other sustainable options to maximize energy generation and effectiveness.

  • Are there eco-friendly options available within the Pressure Switch XMLB category to support green energy initiatives?

    Definitely!Yes! Baltelec.eu online store offers various eco-friendly solutions in the category of Pressure Switch XMLB that are in line with environmental sustainability objectives. Our brand's Schneider Electric products, such as the XMLB300D2C11 - Pressure switch XMLB 300 bar adjustable scale 2 thresholds 1 C/O, are designed with energy efficiency in mind. By integrating these products into your electrical system, you can maximize energy usage and reduce environmental impact. Additionally, we provide affordable pricing for our green Schneider Electric products,, making them an cost-effective choice for promoting sustainability.

  • Is XMLB300D2C11 sold by BALTELEC original?

    Absolutely, we exclusively provide genuine Schneider Electric products, including but not limited to XMLB300D2C11. We obtain our products exclusively through authorized distribution channels to guarantee their genuineness and high performance.
