XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O - Schneider Electric

Expected in 2-4 weeks
XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O - Schneider Electric - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O - Schneider Electric - 0
XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O - Schneider Electric
162,67 € excl. VAT
201,71 € incl. VAT
Text About:
Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O - Schneider Electric
201,71 €
SPECIFICATIONS
Main
Device short name XMLB
pressure actuator Piston
Fluid connection type G 1/4 (female) conforming to ISO 228
product specific application -
[ui] rated insulation voltage 300 V conforming to UL 508
500 V conforming to EN/IEC 60947-1
300 V conforming to CSA C22.2 No 14
controlled fluid Hydraulic oil (0…160 °C)
Pressure switch type of operation Regulation between 2 thresholds
pressure rating 160 bar
pressure sensor type Electromechanical pressure sensor
Complementary
[in] rated current 3 A, B300, AC-15 (Ue = 120 V) conforming to EN/IEC 60947-5-1
1.5 A, B300, AC-15 (Ue = 240 V) conforming to EN/IEC 60947-5-1
0.1 A, R300, DC-13 (Ue = 250 V) conforming to EN/IEC 60947-5-1
local display With
Product certifications CSA
EAC
BV
UL
CCC
LROS (Lloyds register of shipping)
Adjustable range of switching point on falling pressure 0.7…139.2 bar
Auxiliary contacts operation Snap action
Handle front plate colour 113 mm
Product or component type Electromechanical pressure sensor
[uimp] rated impulse withstand voltage 6 kV conforming to EN/IEC 60947-1
Adjustable range of switching point on rising pressure 10…160 bar
awg gauge AWG 20...AWG 14
cable entry Cable gland 7…13 mm
Contacts material Silver contacts
Enclosure material Zinc alloy
Contacts type and composition 1 C/O
Electrical shock protection class Class I conforming to IEC 1140
Class I conforming to IEC 536
Class I conforming to NF C 20-030
width (w) 35 mm
Destruction pressure 720 bar
Electrical circuit type Control circuit
Net weight 0.75 kg
setting External
Operating position Any position
terminal block type 4 terminals
depth 75 mm
mechanical durability 6000000 cycles
repeat accuracy 2 %
Materials in contact with fluid Steel
PTFE
Brass
FPM, FKM
electrical connection Screw-clamps terminals, 1 x 0.5...2 x 2.5 mm²
Maximum operating rate 60 cyc/mn
Maximum resistance across terminals 25 mOhm conforming to IEC 255-7 category 3
25 mOhm conforming to NF C 93-050 method A
Maximum permissible accidental pressure 360 bar
Maximum permissible pressure - per cycle 200 bar
Possible differential maximum at high setting 100 bar
Possible differential minimum at high setting 20.8 bar (- 1.9 bar, + 1.6 bar)
Possible differential minimum at low setting 9.3 bar (- 1.8 bar, + 1.5 bar)
Shock resistance 50 gn conforming to IEC 60068-2-27
Scale type Adjustable differential
Short-circuit protection 10 A cartridge fuse, type gG (gl)
Environment
Ambient air temp for storage/transportation -40…70 °C
ip degree of protection IP66 conforming to EN/IEC 60529
Range of product Telemecanique Pressure sensors XM
ambient air temperature for operation -25…70 °C
standards EN/IEC 60947-5-1
CSA C22.2 No 14
UL 508
CE
vibration resistance 4 gn conforming to IEC 60068-2-6 (f = 30…500 Hz)
protective treatment TC standard version
About this product

The XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O is devised to address the expectations of technical experts, such as installers, electrical installers, maintenance companies, and primary equipment makers. XMLB160D2S12 delivers first-rate quality and beneficence for designers in the energy management industry. This Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O and other Pressure Switch XMLB from Schneider Electric are in stock at the optimal price and fulfillment period through BaltElec online store, a dependable provider helping tradesmen in their sourcing needs.

Clients who have selected Schneider Electric Pressure Switch XMLB have continuously approved the creator's reliability. It has been specified that the excellent workmanship of XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O extends to a collection of purposes. Its elite characteristics make it appropriate to satisfy a wide array of needs, ensuring your industrial, tertiary and automation projects success.

BaltElec specializes in serving industrial and tertiary professionals’ needs. We comprehend the particular standards and requirements of our patrons in the market. By collaborating with us, our customers obtain access to the optimal price and lead time of the top-of-the-line products like XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O from Schneider Electric at a value-for-money price. Baltelec account members appreciate extra discounts and dedicated support.

Begin today and procure XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O at our well-established and straightforward virtual storefront. Don't delay in making this prudent action that certifies the best quality and satisfies the customized standards of customers like your organization.

When you have any doubts or concerns about XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O or any other Schneider Electric products, message us or refer to our Frequently Asked Questions section below. We have curated answers to typical questions to facilitate you further in making an well-informed decision about industrial and tertiary electrical components.

Remember, XMLB160D2S12 - Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O from Schneider Electric is credible, budget-friendly, and first-rate to its competitors in the Pressure Switch XMLB category. Don't hesitate to make it a part of your apparatus at once. Shop with confidence at baltele.eu, your dependable vendor for all your Pressure Switch XMLB.

In our Baltelec.eu web store you will spot Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O - XMLB160D2S12 worth 198.45 €, which will be a trustworthy and new solution for your requirements. This item is fabricated by the Schneider Electric brand using the latest technologies and obeys the peak standards of guarding and capability. We present merchandise from the Pressure Switch XMLB category that amalgamate robustness and functionality, which is an fine option for various operations. Despite of whether you demand devices for small manufacturing or for competent industrial use, Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O will be a faithful associate in your job.

Baltelec works to make the getting process as manageable and fast as practicable for our clients. We offer detailed reports and high-quality visuals of Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O so that you can make an versed choice. A team of masters is always ready to help you with any enquiries in the Pressure Switch XMLB section connected to the choosing and use of items. We are trusting that Pressure switch XMLB 160 bar adjustable scale 2 thresholds 1 C/O will meet your prospects and become an needed element of your setup for just 198.45 €.
