XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked - Schneider Electric

Upon request only
XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked - Schneider Electric - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked - Schneider Electric - 0
XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked - Schneider Electric
excl. VAT
incl. VAT
Text About:
Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked - Schneider Electric
SPECIFICATIONS
Main
Device short name XB6
[ui] rated insulation voltage 250 V (pollution degree 3) conforming to EN/IEC 60947-1
Complementary
[ie] rated operational current 3 A at 120 V, AC-15, B300 conforming to EN/IEC 60947-5-1
1.5 A at 240 V, AC-15, B300 conforming to EN/IEC 60947-5-1
0.1 A at 250 V, DC-13, R300 conforming to EN/IEC 60947-5-1
0.22 A at 125 V, DC-13, R300 conforming to EN/IEC 60947-5-1
Product certifications CSA
UL
CCC
GOST
mounting diameter 16 mm
Product or component type Complete push-button
[uimp] rated impulse withstand voltage 4 kV conforming to EN/IEC 60947-1
nema degree of protection NEMA 13 conforming to UL 50
NEMA 4 conforming to UL 50
NEMA 4X conforming to UL 50
NEMA 13 conforming to CSA C22.2 No 94
NEMA 4 conforming to CSA C22.2 No 94
NEMA 4X conforming to CSA C22.2 No 94
Connections - terminals Faston connectors, connection size: 2.8 x 0.5 mm
bezel material Plastic
Cad overall depth 57 mm
Contacts material Silver alloy (Ag/Ni)
Cad overall height 18 mm
contact operation Slow-break
Contacts type and composition 1 NC
Electrical shock protection class Class II conforming to IEC 61140
Operating travel 2 mm (NC changing electrical state)
3.5 mm (total travel)
Cad overall width 18 mm
Sale per indivisible quantity 1
electrical reliability Λ = 10exp(-8) at 5 V and 1 mA with confidence level of 90 % conforming to IEC 60947-5-4
Type of operator spring return
Net weight 0.019 kg
Operating position Any position
mechanical durability 2000000 cycles
electrical durability 1000000 cycles, AC-15 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13 at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
Positive opening With conforming to EN/IEC 60947-5-1 appendix K
Shape of signaling unit head Square
Operating force 4.5 N NC changing electrical state
Operator profile Black flush, unmarked
Shock resistance 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Short-circuit protection 6 A cartridge fuse type gG
Terminals description iso n°1 (21-22)NC
Environment
Ambient air temp for storage/transportation -40…70 °C
ip degree of protection IP65 conforming to IEC 60529
Range of product Harmony XB6
ambient air temperature for operation -25…70 °C
standards UL 508
JIS C 4520
EN/IEC 60947-1
CSA C22.2 No 14
EN/IEC 60947-5-1
JIS C 852
EN/IEC 60947-5-5
vibration resistance +/- 3 mm (f= 2…500 Hz) conforming to IEC 60068-2-6
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
protective treatment TC
About this product

The XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked is formulated to fulfill the demands of industry specialists, such as electrical contractors, wiremen, maintenance service providers, and primary equipment suppliers. XB6CA22B offers impressive performance and benefits for experts in the electrical and automation industry. This Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked and other Plastic Modular XB6 from Schneider Electric are procurable at the most advantageous pricing and fulfillment period through BALTELEC.EU, a distinguished dealer serving contractors in their collection needs.

Clients who have selected Schneider Electric Plastic Modular XB6 have repeatedly admired the creator's durability. It has been emphasized that the remarkable performance of XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked extends to a diverse range of utilizations. Its ideal features make it great solution for assorted uses, ensuring your industrial, tertiary and automation projects success.

Our team concentrates in serving industrial and tertiary professionals’ needs. We recognize the individual needs and standards of our partners in the sector. By partnering with Baltelec.eu, your business gain access to the premier pricing and inventory of premium products like XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked from Schneider Electric at the lowest price. Registered customers get exclusive discounts and first-class attention.

Do not hesitate and acquire XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked at our safe and simple webshop. Don't delay in making this thoughtful resolution that ensures the paramount quality and addresses the defined specifications of contractors like you.

If you face any worries or concerns about XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked or any other Schneider Electric products, connect with us or refer to our Frequently Asked Questions section below. We have put together answers to regular problems to benefit you further in making an enlightened decision about industrial and tertiary electrical components.

Remember, XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked from Schneider Electric is secure, thrifty, and superior to market challengers in the Plastic Modular XB6 category. Make it a part of your inventory today. Purchase at BALTELEC, your preferred supplier for all your Plastic Modular XB6.

In our Baltelec.eu digital store you will locate Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked - XB6CA22B worth 32.49 €, which will be a trustworthy and cutting-edge solution for your expectations. This object is created by the Schneider Electric brand using the up-to-the-minute technologies and complies with the uppermost standards of protection and performance. We offer objects from the Plastic Modular XB6 category that unite robustness and usefulness, which is an superb possibility for various uses. Not minding of whether you crave hardware for small manufacturing or for competent industrial operation, Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked will be a secure assistant in your work.

Baltelec endeavors to make the getting process as accessible and fast as doable for our clients. We offer detailed narratives and high-quality illustrations of Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked so that you can make an well-informed choice. A team of maestros is always ready to help you with any uncertainties in the Plastic Modular XB6 section referencing to the picking and use of articles. We are persuaded that Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked will meet your requirements and become an essential element of your gear for just 32.49 €.

Frequently Asked Questions about XB6CA22B - Complete push button, Harmony XB6, black square flush pushbutton ? 16 spring return 1NC unmarked:
