SBN316 - 3P 16A Switch - Hager

Expected in 2-4 weeks
SBN316 - 3P 16A Switch - Hager - 3P 16A Switch - Hager - 0
SBN316 - 3P 16A Switch - Hager
13,81 € excl. VAT
17,12 € incl. VAT
Text About:
3P 16A Switch - Hager
17,12 €
SPECIFICATIONS
Additional Information
type of order Break switch
type of pole 3 P
Main
Number of modules 2
rated operational voltage ue 400 V
Neutral position without neutral
Complementary
acceptable current rating with ac22 category a 16 A
cage clamp position off set
connection cross-sect. flexible conductor 1,5 / 10mm²
depth of installed product 68 mm
electrical durability at nominal load in ac21in operating cycles 25000
power loss per pole at in 0.4 W
[in] rated current 16 A
acceptable current rating with ac22 category b 16 A
connection cross-sect. rigid cable 1,5 / 16mm²
degree of pollution according to iec 60664 / iec 60947-2 2
electrical durability at nominal load in ac22 in operating cycles 25000
height of installed product 83 mm
number of mechanical operations 200000
quantity of no contacts 3
total power loss under in 1.2 W
type of connection with screw
type of voltage input 1 AC
width of installed product 35 mm
storage/transport temperature -40…80 °C
thermal rated current outside of housings 16 A
tightening torque 1,8Nm
Rated insulation voltage 440 V
rated operational current in ac21 category a 16 A
rated operational current in ac21category b 16 A
rated short-time withstand current 1s 0.24 kA
frequency 50 to 60 Hz
rated impulse withstand voltage 4000 V
Poles description 3 P
Environment
altitude 2000 m
european directive weee not concerned
protection index ip IP20
standard text IEC 60947-3,IEC/EN 60669-2,IEC/EN 60669-4
operating temperature -20…50 °C
About this product

The SBN316 - 3P 16A Switch is devised to respond to the requirements of trade professionals, such as panel manufacturers, electrical technicians, management services, and OEMs. SBN316 furnishes exceptional efficiency and beneficence for technicians in the automation and control industry. This 3P 16A Switch and other Switches from Hager can be acquired at the finest pricing and delivery period through BALTELEC website, a respected merchant meeting the needs of practitioners in their procurement needs.

Patrons who have used Hager Switches have frequently appreciated the creator's robustness. It has been outlined that the extraordinary efficiency of SBN316 - 3P 16A Switch extends to a broad spectrum of applications. Its supreme qualities make it optimal to meet diverse demands, ensuring the success of your industrial, tertiary, and automation projects.

Our experts dedicates in meeting industrial and tertiary professionals’ needs. We know the individual demands and preferences of our stakeholders in the domain. By cooperating with our experts, you acquire access to the premier price and delivery period of high-quality products like SBN316 - 3P 16A Switch from Hager at a budget-friendly price. Authorized buyers appreciate extra discounts and preferred assistance.

Don't wait and get SBN316 - 3P 16A Switch at our trusted and easy-to-use website. Don't delay in making this shrewd action that ensures the highest quality and meets the individual demands of buyers like your organization.

In the event of any problems or concerns about SBN316 - 3P 16A Switch or any other Hager products, call us or refer to our Common Questions section below. We have compiled answers to frequent uncertainties to benefit you further in making an considered decision about industrial and tertiary electrical components.

Remember, SBN316 - 3P 16A Switch from Hager is unfailing, cost-effective, and excellent to its rivals in the Switches category. Make it a part of your configuration now. Obtain at Baltelec e-shop, your esteemed seller for all your professional electrical equipment and automation needs.

In our Baltelec.eu internet store you will locate 3P 16A Switch - SBN316 worth 16.85 €, which will be a steadfast and cutting-edge solution for your wishes. This product is fabricated by the Hager brand using the most recent technologies and conforms to the highest standards of defense and workmanship. We present products from the Switches category that combine sturdiness and efficacy, which is an superb alternative for various functions. Without consideration of whether you necessitate instruments for small assembly or for adept industrial implementation, 3P 16A Switch will be a dependable associate in your work.

Baltelec aims to make the acquiring process as simple and fast as possible for our buyers. We offer detailed descriptions and high-quality photos of 3P 16A Switch so that you can make an knowledgeable choice. A team of connoisseurs is always ready to help you with any concerns in the Switches section connected to the choice and use of items. We are positive that 3P 16A Switch will meet your requirements and become an needed element of your setup for just 16.85 €.
