RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric

Pending restock
RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - 0
RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - 1
RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - 2
RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric - 3
RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric
7,52 € excl. VAT
9,32 € incl. VAT
Text About:
Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - Schneider Electric
9,32 €
SPECIFICATIONS
Main
Device short name RPM
[ithe] thermal current under enclosure 15 A at -40…55 °C
[uc] control circuit voltage 230 V AC 50/60 Hz
[ui] rated insulation voltage 250 V conforming to IEC
300 V conforming to CSA
300 V conforming to UL
Series name Power
Complementary
[ie] rated operational current 15 A at 277 V (AC) conforming to UL
15 A at 28 V (DC) conforming to UL
15 A at 250 V (AC) NO conforming to IEC
15 A at 28 V (DC) NO conforming to IEC
7.5 A at 250 V (AC) NC conforming to IEC
7.5 A at 28 V (DC) NC conforming to IEC
Control type Lockable test button
Product certifications CSA
EAC
UL
Product or component type Plug-in relay
[uimp] rated impulse withstand voltage 4 kV during 1.2/50 µs
minimum switching capacity 170 mW at 10 mA, 17 V
protection category RT I
average coil consumption in va 1.6 at 60 Hz
Contacts material AgNi
Contacts type and composition 1 C/O
safety reliability data B10d = 100000
Net weight 0.026 kg
Operating position Any position
test levels Level A group mounting
mechanical durability 10000000 cycles
Rated operational voltage limits 184...253 V AC
electrical durability 100000 cycles for resistive load
Device presentation Complete product
average coil resistance 16270 Ohm at 20 °C +/- 15 %
Pollution degree 3
drop-out voltage threshold >= 0.15 Uc AC
Shape of pin Flat
Maximum switching capacity 3750 VA
420 W
Maximum switching voltage 250 V conforming to IEC
dielectric strength 1500 V AC between contacts with micro disconnection
2000 V AC between coil and contact with reinforced
Operate time 20 ms at nominal voltage
Operating rate <= 1200 cycles/hour under load
<= 18000 cycles/hour no-load
Resistive load current 15 A at 250 V AC
15 A at 28 V DC
Shock resistance 15 gn for in operation
30 gn for not operating
Release time 20 ms at nominal voltage
Status led With
Utilisation coefficient 20 %
Environment
Ambient air temp for storage/transportation -40…85 °C
Range of product Harmony Electromechanical Relays
ambient air temperature for operation -40…55 °C
degree of protection (housing only) IP40 conforming to EN/IEC 60529
standards CSA C22.2 No 14
UL 508
EN/IEC 61810-1
vibration resistance 3 gn, amplitude = +/- 1 mm (f = 10…150 Hz)5 cycles in operation
5 gn, amplitude = +/- 1 mm (f = 10…150 Hz)5 cycles not operating
About this product

The RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC is fashioned to fulfill the obligations of industry specialists, such as installers, electrical fitters, support service firms, and OEMs. RPM12P7 affords superior quality and utility for planners in the energy management industry. This Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC and other Harmony RP/RXM/RUM/RSB from Schneider Electric are in stock at the optimal price and shipment duration through BaltElec online store, a well-regarded provider assisting practitioners in their sourcing needs.

Professionals who have chosen Schneider Electric Harmony RP/RXM/RUM/RSB have commonly commended the brand's solidity. It has been emphasized that the superlative productivity of RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC extends to a extensive scope of utilizations. Its high-end aspects make it appropriate to cater to varied requirements, promoting success in your industrial, tertiary, and automation efforts.

Our company specializes in addressing industrial and tertiary professionals’ needs. We get the unique standards and expectations of our clients in the domain. By joining forces with Baltelec team, your team secure access to the finest costs and delivery period of superior products like RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC from Schneider Electric at an economical price. Authorized buyers enjoy additional savings and first-class attention.

Act now and secure RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC at our safe and accessible platform. Don't delay in making this astute move that confirms the supreme quality and caters to the particular needs of vendors like your firm.

Should there be any queries or concerns about RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC or any other Schneider Electric products, contact us or refer to our Help section section below. We have brought together answers to habitual problems to guide you further in making an thoughtful decision about industrial and tertiary electrical components.

Remember, RPM12P7 - Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC from Schneider Electric is steady, thrifty, and high-quality to other vendors in the Harmony RP/RXM/RUM/RSB category. Make it a part of your network straight away. Shop with confidence at baltele.eu, your reliable retailer for all your Harmony RP/RXM/RUM/RSB.

In our Baltelec.eu online store you will uncover Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC - RPM12P7 worth 9.17 €, which will be a reliable and contemporary solution for your desires. This item is developed by the Schneider Electric brand using the freshest technologies and obeys the uppermost standards of precaution and efficacy. We deliver commodities from the Harmony RP/RXM/RUM/RSB category that combine endurance and practicality, which is an outstanding possibility for various uses. In defiance of whether you want tools for small construction or for specialized industrial utilization, Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC will be a sure facilitator in your endeavor.

Baltelec aims to make the getting process as smooth and fast as viable for our customers. We offer detailed depictions and high-quality pictures of Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC so that you can make an informed choice. A team of masters is always ready to help you with any enquiries in the Harmony RP/RXM/RUM/RSB section relevant to the nomination and use of equipment. We are positive that Harmony, Power plugin relay, 15 A, 1 CO, with LED, with lockable test button, 230 V AC will meet your demands and become an key element of your kit for just 9.17 €.
