Main
Range
PowerLogic
secondary current
5 A
type of product or equipment
Transformateur de courant
Product Name
CT
[ui] rated insulation voltage
3 kV
Complementary
electrical insulation class
Classe B
[in] rated current
3000 A
[ue] rated operational voltage
< 720 V CA 50/60 Hz
[ith] conventional thermal current
60 kA
Handle front plate colour
127 mm intérieur :
160 mm extérieur :
[uimp] rated impulse withstand voltage
3 kV
accuracy class
Classe 0,5 à 25 VA
Classe 1 à 30 VA
allowable dynamic current
2,5 Ith
product weight
1,282 kg
maximum safety factor
5
mode d'installation
Vis de verrouillage isolée
width (w)
38 mm intérieur :
99 mm extérieur :
opening of the bars
127 x 38
filling
Avec
current transformer ratio
3000/5
current transformer type
Tropicalisé pour barre
depth
40 mm cadre :
78,4 mm total :
mounting bracket
Jeu de barres
Environment
ip degree of protection
IP20
product certificates
EAC
CE
operating ambient temperature
-25…50 °C
standards
VDE 0414
CEI 61869-2
relative humidity
0…95 %
