MCN204 - MCN204 - Hager

Pending restock
MCN204 - MCN204 - Hager - MCN204 - Hager - 0
MCN204 - MCN204 - Hager
22,36 € excl. VAT
27,73 € incl. VAT
Text About:
MCN204 - Hager
27,73 €
SPECIFICATIONS
Additional Information
curve C
type of pole 2 P
Main
Number of modules 2
rated operational voltage ue 400 V
Number of protected poles 2
rated short circuit breaking capacity icn ac according iec60898-1 6 kA
type of supply voltage AC
Complementary
air humidity protection for all climates
bottom connection alignement for modular devices Aligned terminal
concurrently switching n-neutral No
connection cross section of access and exit with screws, for flexible conductor 1 / 25 mm²
connection cross-sect. flexible conductor 1 / 25mm²
correction factor of magnetic tripping with 100 hz 1.1
correction factor of rating current for 2 devices placed side-by-side 1
depth of installed product 70 mm
electric endurance in number of cycles 4000
power loss per pole at in 1.9 W
rating current -10°c 4.9 A
search words Circuit breaker;Machine;Built-in machine;Built-in device;Installation machine;Rail mounted device;Automatic cutout;Controller circuit-breaker;Built-in distribution unit;Automatic plug-in fuse
[in] rated current 4 A
breaking capacity on 1 pole for it 400v nf 60947-2 3 kA
connection cross-sect. rigid cable 1 / 35mm²
correction factor of magnetic tripping with 200 hz 1.2
correction factor of rating current for 3 devices placed side-by-side 0.95
degree of pollution according to iec 60664 / iec 60947-2 2
height of installed product 83 mm
magnetic regulating currrent 5 / 10 In
number of mechanical operations 20000
rating current -15°c 5 A
top connection alignement for modular devices Aligned terminal
total power loss under in 3.8 W
class of energy limitation i²t 3
correction factor of magnetic tripping with 400 hz 1.5
correction factor of rating current for 4 and 5 devices placed side-by-side 0.9
min/maxi threshold value of the ac thermal operation 1.13 / 1.45 In
rating current -20°c 5.1 A
type of connection with screw
width of installed product 35 mm
connection cross-section of input and output with screws, for massive conductors 1 / 35 mm²
correction factor of magnetic tripping with 60 hz 1
correction factor of rating current for 6 devices placed side-by-side 0.85
min/maxi threshold value of the dc magnetic operation 7 / 15 In
rating current -25°c 5.2 A
storage/transport temperature -25…80 °C
tightening torque 2,8Nm
type of bottom connection for modular devices BIconnect
min/maxi threshold value of the dc thermal operation 1.13 / 1.45 In
rated short circuit breaking capacity icn under 400v ac according iec60898-1 6 kA
rating current -5°c 4.8 A
Rated insulation voltage 500 V
rating current 0°c 4.7 A
type of top connection for modular devices with screw
rated service breaking capacity ics ac according iec 60898-1 6 kA
rated ultimate short-circuit breaking capacity icu under 400v ac iec 60947-2 10 kA
rating current 10°c 4.5 A
rated ultimate short-circuit breaking capacity icu under 415v ac iec 60947-2 10 kA
rating current 15°c 4.4 A
rating current 20°c 4.2 A
rating current 25°c 4.1 A
rating current 30°c 4 A
rating current 35°c 3.9 A
rating current 40°c 3.8 A
rating current 45°c 3.6 A
rating current 50°c 3.5 A
rating current 55°c 3.3 A
rating current 5°c 4.6 A
frequency 50 to 60 Hz
rating current 60°c 3.2 A
rating current 65°c 3 A
rating current 70°c 2.9 A
rated impulse withstand voltage 4000 V
Poles description 2 P
Environment
altitude 2000 m
european directive weee concerned
protection index ip IP20
standard text EN 60898-1
operating temperature -25…70 °C
About this product

The MCN204 - MCN204 is fashioned to cater to the obligations of trade professionals, such as switchboard fabricators, wiring specialists, management services, and primary equipment suppliers. MCN204 dispenses extraordinary robustness and asset for developers in the electromechanical industry. This MCN204 and other Circuit Brakers from Hager can be bought at the most competitive price and distribution time through baltelec.eu, a distinguished retailer serving professionals in their supply needs.

Customers who have used Hager Circuit Brakers have consistently extolled the producer's dependability. It has been highlighted that the impressive capability of MCN204 - MCN204 extends to a array of functions. Its excellent attributes make it fitting to satisfy a wide array of needs. Your developed solution will excel in quality, energy-efficiency and price.

BaltElec dedicates in accommodating industrial and tertiary professionals’ needs. We grasp the particular specifications and preferences of our clients in the industry. By collaborating with our specialists, your business get access to the premier price lists and delivery schedule of superior products like MCN204 - MCN204 from Hager at cost-effective price. Baltelec account members take advantage of added discounts and preferred assistance.

Don't wait and buy MCN204 - MCN204 at our protected and convenient online store. Don't delay in making this astute action that certifies the utmost quality and fulfills the personalized prerequisites of users like your enterprise.

Should you have any uncertainties or concerns about MCN204 - MCN204 or any other Hager products, communicate with us or refer to our Frequently Asked Questions section below. We have provided answers to standard requests for information to serve you further in making an well-considered decision about industrial and tertiary electrical components.

Remember, MCN204 - MCN204 from Hager is safe, cost-effective, and exceptional to other brands in the Circuit Brakers category. Feel free to make it a part of your inventory today. Obtain at Baltelec e-shop, your trusted partner for all your Hager.

In our Baltelec.eu online store you will find MCN204 - MCN204 worth 27.28 €, which will be a steadfast and fashionable solution for your preferences. This object is formulated by the Hager brand using the state-of-the-art technologies and aligns with the premier standards of guarding and competence. We deliver merchandise from the Circuit Brakers category that mix endurance and workability, which is an superb preference for various uses. Without consideration of whether you crave machinery for small assembly or for adept industrial implementation, MCN204 will be a steadfast facilitator in your endeavor.

Baltelec efforts to make the acquiring process as effortless and fast as possible for our shoppers. We offer detailed summaries and high-quality depictions of MCN204 so that you can make an knowledgeable choice. A team of professionals is always ready to help you with any queries in the Circuit Brakers section related to the deciding and use of merchandise. We are persuaded that MCN204 will meet your criteria and become an significant element of your setup for just 27.28 €.
