MC403A - MCB 4P 6kA C-3A 4M - Hager

Pending restock
MC403A - MCB 4P 6kA C-3A 4M - Hager - MCB 4P 6kA C-3A 4M - Hager - 0
MC403A - MCB 4P 6kA C-3A 4M - Hager - MCB 4P 6kA C-3A 4M - Hager - 0
MC403A - MCB 4P 6kA C-3A 4M - Hager
45,88 € excl. VAT
56,90 € incl. VAT
Text About:
MCB 4P 6kA C-3A 4M - Hager
 In cart
56,90 €
SPECIFICATIONS
Additional Information
curve C
type of pole 4 P
Main
Number of modules 4
rated operational voltage ue 230 / 400 V
Number of protected poles 4
rated short circuit breaking capacity icn ac according iec60898-1 6 kA
type of supply voltage AC
Complementary
air humidity protection for all climates
bottom connection alignement for modular devices Aligned terminal
bottom removability for modular devices No
concurrently switching n-neutral No
connection cross section of access and exit with screws, for flexible conductor 1 / 25 mm²
connection cross-sect. flexible conductor 1 / 25mm²
correction factor of magnetic tripping with 100 hz 1.1
correction factor of rating current for 2 devices placed side-by-side 1
depth of installed product 70 mm
electric endurance in number of cycles 4000
power loss per pole at in 2.03 W
rating current -10°c 3.3 A
[in] rated current 3 A
breaking capacity on 1 pole for it 400v nf 60947-2 3 kA
connection cross-sect. rigid cable 1 / 35mm²
correction factor of magnetic tripping with 200 hz 1.2
correction factor of rating current for 3 devices placed side-by-side 0.95
degree of pollution according to iec 60664 / iec 60947-2 2
height of installed product 83 mm
magnetic regulating currrent 5 / 10 In
number of mechanical operations 20000
rating current -15°c 3.4 A
top connection alignement for modular devices Aligned terminal
total power loss under in 8 W
class of energy limitation i²t 3
correction factor of magnetic tripping with 400 hz 1.5
correction factor of rating current for 4 and 5 devices placed side-by-side 0.9
min/maxi threshold value of the ac thermal operation 1.13 / 1.45 In
rating current -20°c 3.4 A
top removability for modular devices No
type of connection with screw
width of installed product 70 mm
connection cross-section of input and output with screws, for massive conductors 1 / 35 mm²
correction factor of magnetic tripping with 60 hz 1
correction factor of rating current for 6 devices placed side-by-side 0.85
min/maxi threshold value of the dc magnetic operation 7 / 15 In
rating current -25°c 3.4 A
storage/transport temperature -25…80 °C
tightening torque 2,8Nm
type of bottom connection for modular devices BIconnect
min/maxi threshold value of the dc thermal operation 1.13 / 1.45 In
rated short circuit breaking capacity icn under 400v ac according iec60898-1 6 kA
rating current -5°c 3.3 A
type of bottom rail clip for modular devices metallic
Rated insulation voltage 500 V
rating current 0°c 3.2 A
type of top connection for modular devices with screw
rated service breaking capacity ics ac according iec 60898-1 6 kA
rating current 10°c 3.2 A
type of top rail clip for modular devices NA
rated ultimate short-circuit breaking capacity icu under 415v ac iec 60947-2 10 kA
rating current 15°c 3.1 A
rating current 20°c 3.1 A
rating current 25°c 3 A
rating current 30°c 3 A
rating current 35°c 3 A
rating current 40°c 2.9 A
rating current 45°c 2.9 A
rating current 50°c 2.8 A
rating current 55°c 2.8 A
rating current 5°c 3.2 A
frequency 50 to 60 Hz
rating current 60°c 2.7 A
rating current 65°c 2.7 A
rating current 70°c 2.7 A
rated impulse withstand voltage 4000 V
Poles description 4 P
Environment
altitude 2000 m
european directive weee concerned
protection index ip IP20
standard text EN 60898-1
operating temperature -25…70 °C
About this product

The MC403A - MCB 4P 6kA C-3A 4M is designed to satisfy the necessities of professional purchasers, such as switchboard fabricators, electric engineers, support service firms, and Industry suppliers. MC403A presents excellent quality and asset for technicians in the energy management industry. This MCB 4P 6kA C-3A 4M and other Circuit Brakers from Hager can be ordered at the lowest cost and turnaround time through BALTELEC, a well-known vendor aiding tradesmen in their gathering needs.

Contractors who have opted for Hager Circuit Brakers have continuously approved the maker's dependability. It has been indicated that the extraordinary energy-efficiency of MC403A - MCB 4P 6kA C-3A 4M extends to a extensive scope of scenarios. Its supreme specifications make it appropriate for wide-ranging specifications, guaranteeing the success of your industrial, tertiary, and automation contracts.

Our team focuses in serving industrial and tertiary professionals’ needs. We get the individual expectations and desires of our patrons in the niche. By working with our company, your team secure access to the top costs and inventory of excellent products like MC403A - MCB 4P 6kA C-3A 4M from Hager at a reasonable price. Registered customers appreciate further discounts and preferred assistance.

Take action and obtain MC403A - MCB 4P 6kA C-3A 4M at our certified and straightforward web store. Don't delay in making this savvy plan that confirms the highest quality and complies with the special criteria of traders like yourselves.

Should there be any issues or concerns about MC403A - MCB 4P 6kA C-3A 4M or any other Hager products, contact us or refer to our Frequently Asked Queries section below. We have gathered answers to frequent uncertainties to aid you further in making an well-informed decision about industrial and tertiary electrical components.

Remember, MC403A - MCB 4P 6kA C-3A 4M from Hager is sure, wallet-friendly, and outstanding to industry peers in the Circuit Brakers category. Feel free to make it a part of your arrangement now. Snap up at BALTELEC, your reliable retailer for all your Circuit Brakers.

In our Baltelec.eu cyber store you will identify MCB 4P 6kA C-3A 4M - MC403A worth 55.98 €, which will be a trustworthy and fashionable solution for your demands. This object is produced by the Hager brand using the state-of-the-art technologies and obeys the premier standards of guarding and performance. We deliver items from the Circuit Brakers category that integrate robustness and effectiveness, which is an superb selection for various intents. Despite of whether you want hardware for small assembly or for specialized industrial exploitation, MCB 4P 6kA C-3A 4M will be a trustworthy assistant in your task.

Baltelec aims to make the procuring process as comfortable and fast as accomplishable for our clients. We offer detailed portrayals and high-quality snapshots of MCB 4P 6kA C-3A 4M so that you can make an conscious choice. A team of masters is always ready to help you with any queries in the Circuit Brakers section involved to the choice and use of materials. We are convinced that MCB 4P 6kA C-3A 4M will meet your prospects and become an imperative element of your kit for just 55.98 €.

Customer Queries about MC403A - MCB 4P 6kA C-3A 4M:

  • Why should I order MC403A - MCB 4P 6kA C-3A 4M from BALTELEC?

    When you order MC403A from BALTELEC, you get authentic high-quality Hager Circuit Brakers products at competitive prices and delivery period. Additionally, our partnersreceive additional savings and priority service.

  • Can you consult if MC403A is the right choice for my technical requirements?

    To confirm that MC403A - MCB 4P 6kA C-3A 4M is suitable for your technical requirements, we provide thorough information pertaining to product's specifications, features, and interoperability. You can find this data on the specific page of the product name. If you require more guidance, our customer support team stands ready to aid you in making an educated decision.

  • What guarantee coverage is offered for MC403A?

    BaltElec online store stands for the reliability of the items we distribute. The standard warranty coverage for Hager Circuit Brakers including Hager MCB 4P 6kA C-3A 4M is 12 months. Nonetheless, it depends depending on the specific product, product category, and could be extended. You can find detailed warranty information on the Hager MCB 4P 6kA C-3A 4M product page or by reaching out to our customer service representatives.

  • Do you offer international shipping for MC403A and other Hager items?

    Yes. Besides serving Estonia, Latvia, Lithuania and other European Union countries, we provide global shipping for Hager MCB 4P 6kA C-3A 4M. However that shipping options, costs, and delivery schedule might differ based on the shipping location. For bulk requests, kindly contact Baltelec.eu sales team.

  • Do Hager MBC provided by BaltElec meet global standards for safety and reliability?

    Of course. All Hager products available at Baltelec.eu online store conform to global standards such as IEC 60898-1 standard and carry the CE certification. These norms guarantee that the items meet rigorous safety, technological, reliability, and functional criteria.

  • Can BALTELEC provide support on incorporating renewable energy solutions, such as solar power systems or wind energy converters, into my projects?

    Absolutely!  Baltelec.eu website recognizes the significance of sustainable energy integration within projects. Our group of experts can support you in selecting the suitable Hager items, to integrate them into your renewable energy projects}. We can provide recommendations on integrating solar energy systems, wind power converters, and additional sustainable options to optimize power generation and efficiency.

  • Are there eco-friendly options offered within the Circuit Brakers category to encourage energy conservation efforts?

    Absolutely! Baltelec website provides a wide range of green solutions within the Circuit Brakers category that are aligned with environmental sustainability objectives. Our brand's Hager products, such as the MCB 4P 6kA C-3A 4M, are designed with energy efficiency in mind. By using these products into your electrical system, you can enhance energy usage and minimize environmental impact. Additionally, we provide affordable pricing for our energy-efficient Hager products,, making them an budget-friendly choice for promoting sustainability.

  • Is MCB 4P 6kA C-3A 4M available by BaltElec e-shop original?

    Indeed, we only provide original Hager products, including MC403A. We procure our products exclusively through official distribution channels to ensure their genuineness and excellent quality.
