LV847252 - Switch disconnector, MasterPact MTZ1 10HA, 1000A, 60kA/690VAC 50/60Hz (Icm), 3P, drawout - Schneider Electric

Pending restock EAN: 3606480815393

EAN: 3606480815393

1 980,00 € excl. VAT

2 455,20 € incl. VAT

Text About:

Switch disconnector, MasterPact MTZ1 10HA, 1000A, 60kA/690VAC 50/60Hz (Icm), 3P, drawout - Schneider Electric

In cart

2 455,20 €

SPECIFICATIONS

Main

Range Masterpact

sectioning ability Oui se conformer à EN/CEI 60947-3

job category AC-23A
AC-3

type of product or equipment Interrupteur-sectionneur

[ui] rated insulation voltage 1000 V CA 50/60 Hz se conformer à EN/CEI 60947-3

visible cut Non

switch-disconnector name Masterpact MTZ1 10 HA

performance level HA

Complementary

"no" connection 70 mm

[icm] rated short circuit making capacity 75 kA crête 220...690 V CA à 50/60 Hz

[ie] rated operational current 1000 A CA 50/60 Hz 690 V

[ue] rated operational voltage 690 V CA 50/60 Hz se conformer à EN/CEI 60947-3

application Distribution

[icw] rated short-time withstand current 20 kA pendant 3 s se conformer à EN/CEI 60947-3
36 kA pendant 0,5 s se conformer à EN/CEI 60947-3
36 kA pendant 1s

Handle front plate colour 322 mm

[uimp] rated impulse withstand voltage 12 kV se conformer à EN/CEI 60947-3

mechanical life 12500 cycle avec maintenance préventive périodique se conformer à EN/CEI 60947-3

product weight 30 kg

fully apparent cut Oui

mode d'installation Extraire

electrical life AC-23A: 6000 cycle 440 V CA 50/60 Hz se conformer à EN/CEI 60947-3
AC-23A: 3000 cycle 690 V CA 50/60 Hz se conformer à EN/CEI 60947-3
AC-3: 6000 cycle 440 V CA 50/60 Hz se conformer à EN/CEI 60947-3

width (w) 288 mm

network frequency 50/60 Hz

upstream connection Façade

downstream connection Façade

depth 291 mm

mounting bracket Châssis

Network type CA

order type Bouton-poussoir

Poles description 3P

Environment

degree of pollution 3 se conformer à EN/CEI 60947-4-1

ip degree of protection IP30

product certificates certificat CEI CE

operating ambient temperature -25…70 °C

standards EN/CEI 60947-3

storage room temperature -40…85 °C
