LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors - Schneider Electric

Pending restock EAN: 3606481174925
LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors - Schneider Electric - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors - Schneider Electric - 0
EAN: 3606481174925
LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors - Schneider Electric
290,57 € excl. VAT
360,30 € incl. VAT
Text About:
circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors - Schneider Electric
360,30 €
SPECIFICATIONS
Main
product range ComPacT NSXm
Range ComPacT
sectioning ability Oui se conformer à EN/CEI 60947-2
job category Catégorie A
name of the device NSXm 80F
type of product or equipment Disjoncteur
Product Name ComPacT NSXm
[ui] rated insulation voltage 800 V CA 50/60 Hz
trigger protection functions LI
circuit breaker mounting method Par vis
Encliquetable
performance level F 36 kA 415 V CA
neutral pole position Gauche
trigger name TM-D
type of trigger Thermique-magnétique
ultimate short-circuit breaking capacity [icu] 85 kA Icu à 220...240 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA Icu à 380...415 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA Icu à 440 V CA 50/60 Hz se conformer à CEI 60947-2
protected poles 4d
Complementary
"no" connection 35 mm avec épanouisseurs
27 mm sans épanouisseurs
9 mm pitches 12 module
[in] rated operational current 80 A à 40 °C
[ue] rated operational voltage 690 V CA 50/60 Hz
application Protection
Distribution
[ics] rated service breaking capacity 85 kA à 220...240 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA à 380...415 V CA 50/60 Hz se conformer à CEI 60947-2
30 kA à 500 V CA 50/60 Hz se conformer à CEI 60947-2
[im] magnetic protection pick-up range 1000 A
[ir] long-time protection pick-up adjustment range 0,7 à 1 x In
Handle front plate colour 137 mm
trigger caliber 80 A à 40 °C
[uimp] rated impulse withstand voltage 8 kV
product weight 1,42 kg
connection terminals 1 cosse Everlink taille de fil2,5…95 mm², rigide ou semi-rigide aluminium / cuivre
1 cosse Everlink taille de fil2,5…70 mm², souple cuivre
electrical life 10000 cycle à 440 V In
20000 cycle à 440 V In/2
5000 cycle à 690 V In
10000 cycle à 690 V In/2
mechanical endurance 20000 cycle
width (w) 108 mm
network frequency 50/60 Hz
Colour Gris (RAL 7016)
long-time pick-up adjustment type ir (thermal protection) Réglable
long-time protection delay adjustment type tr Fixe
number of slots for electrical auxiliaries 1 slot(s) pour interrupteur secondaire OF
1 slot(s) pour commutateur de relais avertisseur SD
1 slot(s) pour libération de tension MN or MX
mounting bracket Platine
Rail DIN
depth (p) 80 mm
Network type CA
differential protection Sans
order type Par maneton
kind of protection L : for protection surcharge (thermique)
I : for protection (magnétique) court-circuit
Poles description 4P
Environment
degree of pollution 3 se conformer à CEI 60664-1
ip degree of protection IP40 se conformer à CEI 60529
operating altitude 0...2000 m sans réduction de courant
2000...5000 m avec réduction de courant
product certificates CCC
EAC
Marine
operating ambient temperature -25…70 °C
standards EN/CEI 60947
relative humidity 0…95 %
shock resistance ik IK07 se conformer à CEI 62262
storage room temperature -50…85 °C
About this product

The LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors is developed to satisfy the wants of trade buyers, such as panel manufacturers, wiring specialists, maintenance companies, and Industry suppliers. LV426326 offers superb quality and profit for developers in the power systems industry. This circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors and other Compact NSXm from Schneider Electric are available at the most economical price and shipment duration through BaltElec online store, a respected reseller helping contractors in their provision needs.

Engineers who have chosen Schneider Electric Compact NSXm have continuously complimented the producer's soundness. It has been specified that the extraordinary effectiveness of LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors extends to a wide range of operations. Its high-end aspects make it proper pick to cater to varied requirements, guaranteeing the success of your industrial, tertiary, and automation contracts.

Our professionals devotes in serving industrial and tertiary professionals’ needs. We comprehend the distinct requirements and expectations of our patrons in the market. By cooperating with our experts, you receive access to the superior fees and availability of top-tier products like LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors from Schneider Electric at the most competitive price. Professional buyers with Baltelec account get more savings and priority service.

Do not hesitate and secure LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors at our protected and simple virtual storefront. Don't delay in making this clever option that affirms the ultimate quality and covers the particular requirements of professionals like yourselves.

Should there be any problems or concerns about LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors or any other Schneider Electric products, reach out to us or refer to our Common Questions section below. We have consolidated answers to recurring concerns to facilitate you further in making an wise decision about industrial and tertiary electrical components.

Remember, LV426326 - circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors from Schneider Electric is reliable, budget-friendly, and better to its rivals in the Compact NSXm category. Don't hesitate to make it a part of your electrical system today. Obtain at BALTELEC, your preferred supplier for all your Compact NSXm.

In our Baltelec.eu digital store you will discover circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors - LV426326 worth 354.49 €, which will be a dependable and up-to-date solution for your desires. This product is developed by the Schneider Electric brand using the up-to-the-minute technologies and conforms to the uppermost standards of assurance and workmanship. We furnish objects from the Compact NSXm category that amalgamate lastingness and operability, which is an top-notch pick for various purposes. Regardless of whether you desire appliances for small formation or for skilled industrial employment, circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors will be a steadfast helper in your task.

Baltelec aims to make the procuring process as comfortable and fast as doable for our shoppers. We offer detailed narratives and high-quality images of circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors so that you can make an knowledgeable choice. A team of virtuosos is always ready to help you with any inquiries in the Compact NSXm section linked to the determining and use of goods. We are trusting that circuit breaker ComPact NSXm F (36 kA at 415 VAC), 4P 4d, 80 A rating TMD trip unit, EverLink connectors will meet your requirements and become an key element of your hardware for just 354.49 €.
