LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors - Schneider Electric

Expected in 2-4 weeks
LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors - Schneider Electric - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors - Schneider Electric - 0
LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors - Schneider Electric
235,13 € excl. VAT
291,56 € incl. VAT
Text About:
circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors - Schneider Electric
291,56 €
SPECIFICATIONS
Main
Device short name NSXm 40B
Range ComPact
circuit breaker mounting mode By screws
Clip-on
Neutral position Left
Protected poles description 4D
Product Name ComPact NSXm
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit rating 40 A at 40 °C
[ui] rated insulation voltage 800 V AC 50/60 Hz
Trip unit protection functions LI
performance level B 25 kA 415 V AC
Complementary
9 mm pitches 12 module
[in] rated current 40 A at 40 °C
[ue] rated operational voltage 690 V AC 50/60 Hz
[ics] rated service breaking capacity 50 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
25 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
20 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
10 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
[im] magnetic protection pick-up range 600 A
Control type Toggle
depth (d) 80 mm
Product certifications CCC
EAC
Marine
[ir] long-time protection pick-up adjustment range 0.7...1 x In
Connection pitch 35 mm with spreaders
27 mm without spreaders
Handle front plate colour 137 mm
Product or component type Circuit breaker
[uimp] rated impulse withstand voltage 8 kV
connection terminals 1 Everlink lug wire size 2.5…95 mm², rigid or stranded aluminium/copper
1 Everlink lug wire size 2.5…70 mm², flexible copper
Device application Protection
Distribution
width (w) 108 mm
network frequency 50/60 Hz
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
long-time pick-up adjustment type ir (thermal protection) Adjustable
Net weight 1.42 kg
long-time protection delay adjustment type tr Fixed
number of slots for electrical auxiliaries 1 slot(s) for auxiliary switch OF
1 slot(s) for alarm switch SD
1 slot(s) for voltage release MN or MX
Earth-leakage protection Without
Mounting support Plate
DIN rail
mechanical durability 20000 cycles
electrical durability 10000 cycles at 440 V In
20000 cycles at 440 V In/2
5000 cycles at 690 V In
10000 cycles at 690 V In/2
Network type AC
Pollution degree 3 conforming to IEC 60664-1
Suitability for isolation Yes conforming to EN/IEC 60947-2
Poles description 4P
Utilisation category Category A
Protection type L : for overload protection (thermal)
I : for short-circuit protection (magnetic)
Environment
Ambient air temp for storage/transportation -50…85 °C
ip degree of protection IP40 conforming to IEC 60529
operating altitude 0...2000 m without derating
2000...5000 m with derating
Range of product ComPact NSXm
ambient air temperature for operation -25…70 °C
standards EN/IEC 60947
relative humidity 0…95 %
About this product

The LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors is conceived to fulfill the conditions of professional purchasers, such as switchgear manufacturers, electrical fitters, maintenance service providers, and Original Equipment manufacturers. LV426223 presents exceptional integrity and worth for technicians in the energy management industry. This circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors and other Compact NSXm from Schneider Electric are available at the optimal price and fulfillment period through BALTELEC.EU, a well-regarded reseller catering to technicians in their sourcing needs.

Technicians who have secured Schneider Electric Compact NSXm have steadily admired the manufacturer’s resilience. It has been pointed out that the excellent competence of LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors extends to a multitude of scenarios. Its exceptional components make it appropriate to cater to varied requirements, assuring the success of your industrial, tertiary, and automation ventures.

BaltElec team centers in addressing industrial and tertiary professionals’ needs. We recognize the distinct criteria and expectations of our partners in the industry. By aligning with our professionals, you obtain access to the premier rates and availability of superior products like LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors from Schneider Electric at an affordable price. Professional buyers with Baltelec account get additional savings and top-tier service.

Seize the moment and obtain LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors at our verified and streamlined online portal. Don't delay in making this savvy pick that ensures the supreme quality and matches the distinct standards of suppliers like your company.

Should you have any concerns or concerns about LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors or any other Schneider Electric products, reach out to us or refer to our FAQs section below. We have brought together answers to common issues to benefit you further in making an smart decision about industrial and tertiary electrical components.

Remember, LV426223 - circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors from Schneider Electric is steady, value-priced, and excellent to industry peers in the Compact NSXm category. Make it a part of your apparatus immediately. Purchase at baltele.eu, your steady distributor for all your Compact NSXm.

In our Baltelec.eu digital store you will encounter circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors - LV426223 worth 286.85 €, which will be a trustworthy and fashionable solution for your expectations. This goods is designed by the Schneider Electric brand using the advanced technologies and conforms to the maximum standards of reliability and performance. We furnish articles from the Compact NSXm category that unite endurance and operability, which is an top-notch election for various roles. Not minding of whether you call for hardware for small fabrication or for qualified industrial utilization, circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors will be a trustworthy helper in your job.

Baltelec tries to make the procuring process as simple and fast as achievable for our clients. We offer detailed descriptions and high-quality snapshots of circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors so that you can make an enlightened choice. A team of authorities is always ready to help you with any enquiries in the Compact NSXm section associated to the picking and use of products. We are assured that circuit breaker ComPact NSXm B (25 kA at 415 VAC), 4P 4d, 40 A rating TMD trip unit, EverLink connectors will meet your standards and become an crucial element of your tools for just 286.85 €.
