LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors - Schneider Electric

Expected in 2-4 weeks
LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors - Schneider Electric - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors - Schneider Electric - 0
LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors - Schneider Electric
219,10 € excl. VAT
271,69 € incl. VAT
Text About:
circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors - Schneider Electric
271,69 €
SPECIFICATIONS
Main
Device short name NSXm 25E
Range ComPact
circuit breaker mounting mode By screws
Clip-on
Neutral position Left
Protected poles description 4D
Product Name ComPact NSXm
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit rating 25 A at 40 °C
[ui] rated insulation voltage 800 V AC 50/60 Hz
Trip unit protection functions LI
performance level E 16 kA 415 V AC
Complementary
9 mm pitches 12 module
[in] rated current 25 A at 40 °C
[ue] rated operational voltage 690 V AC 50/60 Hz
[ics] rated service breaking capacity 25 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
16 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
8 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
[im] magnetic protection pick-up range 600 A
Control type Toggle
depth (d) 80 mm
Product certifications CCC
EAC
Marine
[ir] long-time protection pick-up adjustment range 0.7...1 x In
Connection pitch 35 mm with spreaders
27 mm without spreaders
Handle front plate colour 137 mm
Product or component type Circuit breaker
[uimp] rated impulse withstand voltage 8 kV
connection terminals compression lug/busbar
Device application Distribution
Protection
width (w) 108 mm
network frequency 50/60 Hz
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
long-time pick-up adjustment type ir (thermal protection) Adjustable
Net weight 1.42 kg
long-time protection delay adjustment type tr Fixed
number of slots for electrical auxiliaries 1 slot(s) for auxiliary switch OF
1 slot(s) for alarm switch SD
1 slot(s) for voltage release MN or MX
Earth-leakage protection Without
Mounting support Plate
DIN rail
mechanical durability 20000 cycles
electrical durability 10000 cycles at 440 V In
20000 cycles at 440 V In/2
5000 cycles at 690 V In
10000 cycles at 690 V In/2
Network type AC
Pollution degree 3 conforming to IEC 60664-1
Suitability for isolation Yes conforming to EN/IEC 60947-2
Poles description 4P
Utilisation category Category A
Protection type L : for overload protection (thermal)
I : for short-circuit protection (magnetic)
Environment
Ambient air temp for storage/transportation -50…85 °C
ip degree of protection IP40 conforming to IEC 60529
operating altitude 0...2000 m without derating
2000...5000 m with derating
Range of product ComPact NSXm
ambient air temperature for operation -25…70 °C
standards EN/IEC 60947
relative humidity 0…95 %
About this product

The LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors is formulated to fulfill the requirements of trade buyers, such as switchboard fabricators, electrical fitters, maintenance companies, and Industry suppliers. LV426171 dispenses exceptional integrity and asset for specialists in the automation and control industry. This circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors and other Compact NSXm from Schneider Electric can be obtained at the most competitive price and delivery schedule through baltelec.eu, an independent vendor supporting technicians in their acquisition needs.

Contractors who have purchased Schneider Electric Compact NSXm have regularly commended the brand's trustworthiness. It has been outlined that the notable energy-efficiency of LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors extends to a variety of tasks. Its ideal qualities make it suitable to satisfy a wide array of needs, promoting success in your industrial, tertiary, and automation efforts.

Our professionals devotes in meeting industrial and tertiary professionals’ needs. We comprehend the distinct expectations and preferences of our stakeholders in the niche. By collaborating with our company, our customers receive access to the top price and delivery period of superior products like LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors from Schneider Electric at the most competitive price. Registered users take advantage of extra discounts and dedicated support.

Do not hesitate and secure LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors at our risk-free and accessible website. Don't delay in making this prudent resolution that ensures the highest quality and satisfies the distinct requests of vendors like your company.

In case you have any inquiries or concerns about LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors or any other Schneider Electric products, connect with us or refer to our FAQs section below. We have compiled answers to recurring requests for information to advise you further in making an smart decision about industrial and tertiary electrical components.

Remember, LV426171 - circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors from Schneider Electric is credible, reasonable, and high-quality to other brands in the Compact NSXm category. Make it a part of your infrastructure right now. Snap up at baltele.eu, your consistent provider for all your Compact NSXm.

In our Baltelec.eu digital store you will detect circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors - LV426171 worth 267.31 €, which will be a safe and cutting-edge solution for your wants. This article is constructed by the Schneider Electric brand using the advanced technologies and follows the top standards of reliability and efficacy. We offer produce from the Compact NSXm category that integrate toughness and usefulness, which is an fine possibility for various uses. Independent of whether you require tools for small manufacturing or for qualified industrial exertion, circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors will be a secure assistant in your undertaking.

Baltelec ventures to make the procuring process as accessible and fast as attainable for our patrons. We offer detailed descriptions and high-quality images of circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors so that you can make an informed choice. A team of maestros is always ready to help you with any matter in the Compact NSXm section referencing to the preferment and use of supplies. We are persuaded that circuit breaker ComPact NSXm E (16 kA at 415 VAC), 4P 4d, 25 A rating TMD trip unit, compression lugs and busbar connectors will meet your requirements and become an vital element of your hardware for just 267.31 €.
