LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil - Schneider Electric
Motor control
TeSys Deca
48...130 V DC
TeSys Deca
1 hp at 230/240 V AC 60 Hz for 1 phase motors
2 hp at 200/208 V AC 60 Hz for 3 phases motors
2 hp at 230/240 V AC 60 Hz for 3 phases motors
5 hp at 460/480 V AC 60 Hz for 3 phases motors
7.5 hp at 575/600 V AC 60 Hz for 3 phases motors
Signalling circuit: 690 V conforming to IEC 60947-1
DC AC/DC electronic
4 kW at 380...400 V AC 50 Hz
4 kW at 415 V AC 50 Hz
4 kW at 440 V AC 50 Hz
5.5 kW at 500 V AC 50 Hz
5.5 kW at 660...690 V AC 50 Hz
25 A (at <60 °C) at <= 440 V AC AC-1 for power circuit
210 A 40 °C - 1 s for power circuit
30 A 40 °C - 10 min for power circuit
61 A 40 °C - 1 min for power circuit
100 A - 1 s for signalling circuit
120 A - 500 ms for signalling circuit
140 A - 100 ms for signalling circuit
25 A (at 60 °C) for power circuit
CSA
EAC
UL
KC
DNV-GL
LROS (Lloyds register of shipping)
UKCA
Power circuit: 1.7 N.m - on screw clamp terminals - with screwdriver Philips No 2
Control circuit: 1.7 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm
Control circuit: 1.7 N.m - on screw clamp terminals - with screwdriver Philips No 2
Power circuit: 1.7 N.m - on screw clamp terminals - with screwdriver pozidriv No 2
Control circuit: 1.7 N.m - on screw clamp terminals - with screwdriver pozidriv No 2
Power circuit: screw clamp terminals 2 cable(s) 1…4 mm²flexible without cable end
Power circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible with cable end
Power circuit: screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end
Power circuit: screw clamp terminals 1 cable(s) 1…4 mm²solid
Power circuit: screw clamp terminals 2 cable(s) 1…4 mm²solid
Control circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible without cable end
Control circuit: screw clamp terminals 2 cable(s) 1…4 mm²flexible without cable end
Control circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible with cable end
Control circuit: screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end
Control circuit: screw clamp terminals 1 cable(s) 1…4 mm²solid
Control circuit: screw clamp terminals 2 cable(s) 1…4 mm²solid
25 A gG at <= 690 V coordination type 1 for power circuit
20 A gG at <= 690 V coordination type 2 for power circuit
type mirror contact 1 NC conforming to IEC 60947-4-1
0.85...1.1 Uc (-40…60 °C):operational AC/DC
1...1.1 Uc (60…70 °C):operational AC/DC
Vibrations contactor closed: 4 Gn, 5...300 Hz
Shocks contactor open: 10 Gn for 11 ms
Shocks contactor closed: 15 Gn for 11 ms
Green (SE GREEN 2)
Plate
0.2 W AC-3
0.6 Mcycles 25 A AC-1 at Ue <= 440 V
140 A AC for signalling circuit conforming to IEC 60947-5-1
250 A DC for signalling circuit conforming to IEC 60947-5-1
20...90 ms opening
1.5 ms on energisation between NC and NO contact
AC-3
B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1
conforming to IEC 60947-1 Annex Q category D
60…70 °C with derating
EN/IEC 60947-5-1
UL 60947-4-1
CSA C22.2 No 60947-4-1
IEC 60335-1
The LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil is formulated to fulfill the requirements of specialized professionals, such as circuit designers, electric engineers, support service firms, and equipment creators. LC2D09EHE delivers outstanding standards and worth for developers in the electrical engineering industry. This TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil and other TeSyS Deca Contactors from Schneider Electric are on offer at the most favorable cost and shipment duration through BaltElec website, a well-regarded distributor aiding professionals in their obtaining needs.
Technicians who have chosen Schneider Electric TeSyS Deca Contactors have frequently approved the brand's dependability. It has been mentioned that the excellent competence of LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil extends to a diverse range of deployments. Its excellent attributes make it optimal for wide-ranging specifications, guaranteeing the success of your industrial, tertiary, and automation contracts.
Our team concentrates in addressing industrial and tertiary professionals’ needs. We understand the special standards and expectations of our stakeholders in the field. By joining forces with BALTELEC, your business gain access to the premier charges and availability of top-tier products like LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil from Schneider Electric at an attractive price. Registered customers take advantage of additional savings and preferred assistance.
Do not hesitate and obtain LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil at our secure and easy-to-use online portal. Don't delay in making this clever pick that assures the greatest quality and covers the specific expectations of professionals like your organization.
If you encounter any problems or concerns about LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil or any other Schneider Electric products, communicate with us or refer to our Information center section below. We have amassed answers to habitual doubts to facilitate you further in making an informed decision about industrial and tertiary electrical components.
Remember, LC2D09EHE - TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil from Schneider Electric is unfailing, cost-effective, and exceptional to industry peers in the TeSyS Deca Contactors category. Make it a part of your apparatus straight away. Snap up at BALTELEC, your dependable vendor for all your professional electrical equipment and automation needs.
In our Baltelec.eu web store you will encounter TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil - LC2D09EHE worth 178.47 €, which will be a secure and state-of-the-art solution for your necessities. This object is created by the Schneider Electric brand using the current technologies and conforms to the highest standards of defense and capacity. We provide merchandise from the TeSyS Deca Contactors category that integrate longevity and effectiveness, which is an outstanding preference for various roles. Irrespective of whether you need machinery for small generation or for professional industrial purpose, TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil will be a safe companion in your undertaking.
Baltelec strives to make the procuring process as comfortable and fast as doable for our clients. We offer detailed depictions and high-quality photos of TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil so that you can make an aware choice. A team of adepts is always ready to help you with any questions in the TeSyS Deca Contactors section connected to the deciding and use of products. We are convinced that TeSys Deca reversing contactor 3P <= 440 V 9 A AC3 48...130 V AC/DC coil will meet your standards and become an imperative element of your hardware for just 178.47 €.
