K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle - Schneider Electric

Pending restock
K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle - Schneider Electric - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle - Schneider Electric - 0
K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle - Schneider Electric
27,41 € excl. VAT
33,98 € incl. VAT
Text About:
Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle - Schneider Electric
33,98 €
SPECIFICATIONS
Main
Cam switch function Changeover switch
[ithe] thermal current under enclosure 16 A
Cam switch head type With front plate 45 x 45 mm
Off position With Off position
Presentation of legend With metallic legend, 2 - 0 - 1 black marking
[ui] rated insulation voltage 690 V (pollution degree 3) conforming to IEC 60947-1
Switching positions Left: 0° - 315°
Right: 0° - 45°
component name K2
Complementary
[ith] conventional thermal current 20 A
Product certifications CSA 240 V 3 hp 3 phases 2 pole(s)
UL 240 V 0.33 hp 1 phase 2 pole(s)
CSA 240 V 1 hp 1 phase
UL 240 V 1 hp 3 phases
Product or component type Complete cam switch
[uimp] rated impulse withstand voltage 4 kV in isolating function
6 kV conforming to IEC 947-1
switching angle 45 °
Product mounting Front mounting
Cad overall depth 77 mm
Cad overall height 45 mm
contact operation Slow-break
Electrical shock protection class Class II conforming to IEC 536
Class II conforming to NF C 20-030
Fixing mode Multifixing
Cad overall width 45 mm
Rotary handle padlocking Without
Type of operator Black handle, length = 35 mm
Net weight 0.115 kg
mechanical durability 1000000 cycles
return Without
electrical durability 200000 cycles AC-23
200000 cycles AC-3
600000 cycles AC-15
600000 cycles AC-21
Positive opening With
electrical connection Captive screw clamp terminals flexible, clamping capacity: 2 x 1.5 mm²
Captive screw clamp terminals solid, clamping capacity: 1 x 2.5 mm²
Maximum operating rate 2.5 cyc/mn AC-21
2.5 cyc/mn AC-23
2.5 cyc/mn AC-3
8.333 cyc/mn AC-15
Short-circuit current 10000 A
Shock resistance 30 gn conforming to IEC 68-2-27
Poles description 1P
Short-circuit protection 20 A cartridge fuse, type gG
Environment
Ambient air temp for storage/transportation -40…70 °C
ip degree of protection IP40 conforming to IEC 529
IP40 conforming to NF C 20-010
Range of product Harmony K
ambient air temperature for operation -25…55 °C
standards EN 60947-3 for power circuit
EN 60947-5-1 for control circuit
IEC 60947-3 for power circuit
IEC 60947-5-1 for control circuit
CENELEC EN 50013
vibration resistance 5 gn conforming to IEC 68-2-6 (f = 10…150 Hz)
protective treatment TC
About this product

The K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle is created to cater to the needs of business buyers, such as switchboard fabricators, wiring experts, maintenance companies, and original manufacturers. K2B001ULH affords excellent quality and merit for designers in the electromechanical industry. This Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle and other Harmony K from Schneider Electric can be purchased at the finest pricing and distribution time through baltelec.eu, a reliable reseller meeting the needs of industry experts in their supply needs.

Users who have selected Schneider Electric Harmony K have frequently complimented the brand's dependability. It has been stated that the superlative efficiency of K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle extends to a extensive scope of applications. Its premium elements make it well-suited solution for diverse needs, guaranteeing the success of your industrial, tertiary, and automation contracts.

Our company dedicates in accommodating industrial and tertiary professionals’ needs. We grasp the special requirements and preferences of our buyers in the domain. By cooperating with BALTELEC, your team secure access to the superior price lists and delivery schedule of the top-of-the-line products like K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle from Schneider Electric at a competitive price. Authorized buyers appreciate further discounts and priority service.

Move quickly and purchase K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle at our secure and straightforward virtual storefront. Don't delay in making this thoughtful decision that warrants the ultimate quality and complies with the targeted needs of vendors like yourselves.

In the event of any matters or concerns about K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle or any other Schneider Electric products, call us or refer to our FAQ section section below. We have gathered answers to popular requests for information to back you further in making an enlightened decision about industrial and tertiary electrical components.

Remember, K2B001ULH - Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle from Schneider Electric is consistent, cost-effective, and first-rate to industry peers in the Harmony K category. Make it a part of your solution without delay. Shop with confidence at Baltelec e-shop, your reliable retailer for all your professional electrical equipment and automation needs.

In our Baltelec.eu web store you will detect Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle - K2B001ULH worth 33.43 €, which will be a dependable and new solution for your necessities. This goods is invented by the Schneider Electric brand using the up-to-the-minute technologies and meets the uppermost standards of security and competence. We give commodities from the Harmony K category that associate longevity and workability, which is an outstanding preference for various applications. Regardless of whether you crave gear for small manufacturing or for qualified industrial application, Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle will be a constant aide in your assignment.

Baltelec attempts to make the obtaining process as effortless and fast as attainable for our clients. We offer detailed depictions and high-quality portrayals of Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle so that you can make an knowledgeable choice. A team of pros is always ready to help you with any questions in the Harmony K section associated to the nomination and use of items. We are sure that Cam changeover switch, Harmony K, multifixing, plastic, 1 pole, position 0, 45°, 20A, 45x45mm, metallic legend, marked 2/0/1, 35mm black handle will meet your wishes and become an indispensable element of your equipment for just 33.43 €.
