GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals - Schneider Electric

Expected in 2-4 weeks
GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals - Schneider Electric - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals - Schneider Electric - 0
GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals - Schneider Electric
254,94 € excl. VAT
316,13 € incl. VAT
Text About:
Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals - Schneider Electric
316,13 €
SPECIFICATIONS
Main
Device short name GV4PE
Range TeSys Deca
TeSys Deca
magnetic tripping current 212 A
Product Name TeSys GV4
TeSys Deca
Trip unit technology Electronic
Thermal-magnetic
[ui] rated insulation voltage 800 V AC 50/60 Hz conforming to IEC 60947-2
motor power kW 3 kW at 400...415 V AC 50/60 Hz
3 kW at 500 V AC 50/60 Hz
4 kW at 500 V AC 50/60 Hz
5.5 kW at 660...690 V AC 50/60 Hz
7.5 kW at 660...690 V AC 50/60 Hz
4 kW at 400...415 V AC 50/60 Hz
5.5 kW at 400...415 V AC 50/60 Hz
5.5 kW at 500 V AC 50/60 Hz
7.5 kW at 500 V AC 50/60 Hz
9 kW at 660...690 V AC 50/60 Hz
11 kW at 660...690 V AC 50/60 Hz
Complementary
[in] rated current 12.5 A
[ue] rated operational voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
[ics] rated service breaking capacity 100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
15 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2
65 kA at 208Y/120 V AC 50/60 Hz conforming to UL 60947
65 kA at 240 V AC 50/60 Hz conforming to UL 60947
35 kA at 480Y/277 V AC 50/60 Hz conforming to UL 60947
8 kA Icu at 660...690 V AC 50/60 Hz conforming to IEC 60947-2
25 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
18 kA at 600Y/347 V AC 50/60 Hz conforming to UL 60947
[ith] conventional thermal current 115 A conforming to IEC 60947-4-1
Control type Toggle
Product certifications IEC
UL
CSA
CCC
EAC
ATEX
EU-RO MR
Handle front plate colour 155 mm
Product or component type Motor circuit breaker
tightening torque 9 N.m for cable 16…95 mm²
5 N.m for cable 1.5…10 mm²
[uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
Connections - terminals EverLink BTR screw connectors (top) 1 cable(s) 1.5…70 mm² - solid
EverLink BTR screw connectors (top) 1 cable(s) 1.5…50 mm² - flexible
EverLink BTR screw connectors (bottom) 1 cable(s) 2.5…95 mm² - solid
EverLink BTR screw connectors (bottom) 1 cable(s) 2.5…70 mm² - flexible
Device application Motor protection
width (w) 81 mm
mechanical robustness Vibrations: +/- 1 mm 2...13.2 Hz conforming to IEC 60068-2-6
Vibrations: 0.7 gn 13.2...100 Hz conforming to IEC 60068-2-6
Shocks: 15 gn 11 ms conforming to IEC 60068-2-27
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
Net weight 1.45 kg
Operating position Any position
power dissipation per pole 4.6 W
depth 116 mm
mechanical durability 40000 cycles
electrical durability 40000 cycles for AC-3 at 440 V In/2
40000 cycles for AC-3 at 440 V In
Pollution degree 3
Maximum operating rate 25 cyc/h
Phase failure sensitivity Yes conforming to IEC 60947-4-1
Rated duty Continuous conforming to IEC 60947-4-1
Suitability for isolation Yes conforming to IEC 60947-1
Poles description 3P
Utilisation category Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
Environment
Ambient air temp for storage/transportation -50…85 °C
Climatic withstand conforming to IACS E10
ip degree of protection IP40 conforming to IEC 60529
operating altitude 5000 m
Range of product TeSys GV4
ambient air temperature for operation -25…70 °C
standards CSA C22.2 No 60947-4-1
UL 60947-4-1
EN/IEC 60947-4-1
EN/IEC 60947-2
fire resistance 960 °C conforming to IEC 60695-2-11
About this product

The GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals is formulated to serve the prerequisites of trade professionals, such as panel builders, circuit experts, service organizations, and OEMs. GV4PE12N provides excellent performance and beneficence for experts in the electromechanical industry. This Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals and other TeSyS Deca GV4 Motor Circuit Breaker from Schneider Electric are available at the most economical price and delivery schedule through BaltElec website, a well-regarded reseller attending to engineers in their purchasing needs.

Consumers who have acquired Schneider Electric TeSyS Deca GV4 Motor Circuit Breaker have regularly approved the creator's dependability. It has been indicated that the impressive operation of GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals extends to a diverse range of operations. Its ideal components make it perfect choice for various requirements, ensuring your industrial, tertiary and automation projects success.

Our professionals centers in fulfilling industrial and tertiary professionals’ needs. We recognize the unique demands and preferences of our customers in the sector. By collaborating with our specialists, your company receive access to the best pricing and availability of superior products like GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals from Schneider Electric at an affordable price. Professional buyers with Baltelec account benefit from extra discounts and top-tier service.

Do not hesitate and obtain GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals at our well-established and simple e-commerce site. Don't delay in making this intelligent move that confirms the top quality and matches the targeted needs of vendors like your outfit.

Should you have any concerns or concerns about GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals or any other Schneider Electric products, call us or refer to our FAQ section section below. We have amassed answers to regular issues to help you further in making an informed decision about industrial and tertiary electrical components.

Remember, GV4PE12N - Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals from Schneider Electric is secure, value-priced, and high-quality to other vendors in the TeSyS Deca GV4 Motor Circuit Breaker category. Don't hesitate to make it a part of your solution right now. Order at Baltelec e-shop, your dependable vendor for all your Schneider Electric.

In our Baltelec.eu cyber store you will identify Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals - GV4PE12N worth 311.03 €, which will be a sure and modern solution for your requirements. This goods is developed by the Schneider Electric brand using the most recent technologies and follows the uppermost standards of well-being and efficacy. We furnish items from the TeSyS Deca GV4 Motor Circuit Breaker category that unite resilience and workability, which is an excellent selection for various objectives. In spite of whether you want instruments for small generation or for experienced industrial application, Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals will be a dependable facilitator in your endeavor.

Baltelec endeavors to make the getting process as simple and fast as doable for our customers. We offer detailed accounts and high-quality snapshots of Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals so that you can make an briefed choice. A team of experts is always ready to help you with any inquiries in the TeSyS Deca GV4 Motor Circuit Breaker section tied to the choice and use of articles. We are certain that Motor circuit breaker, TeSys GV4, 3P, 12.5A, Icu 50kA, thermal magnetic, Everlink terminals will meet your criteria and become an needed element of your apparatus for just 311.03 €.
