GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals - Schneider Electric

Expected in 2-4 weeks
GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals - Schneider Electric - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals - Schneider Electric - 0
GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals - Schneider Electric
239,16 € excl. VAT
296,55 € incl. VAT
Text About:
Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals - Schneider Electric
296,55 €
SPECIFICATIONS
Main
Device short name GV4PE
Range TeSys Deca
TeSys Deca
magnetic tripping current 59 A
Product Name TeSys GV4
TeSys Deca
Trip unit technology Thermal-magnetic
Electronic
[ui] rated insulation voltage 800 V AC 50/60 Hz conforming to IEC 60947-2
motor power kW 0.55 kW at 400...415 V AC 50/60 Hz
0.75 kW at 400...415 V AC 50/60 Hz
0.75 kW at 500 V AC 50/60 Hz
1.1 kW at 500 V AC 50/60 Hz
1.1 kW at 660...690 V AC 50/60 Hz
1.5 kW at 660...690 V AC 50/60 Hz
1.5 kW at 500 V AC 50/60 Hz
2.2 kW at 660...690 V AC 50/60 Hz
1.1 kW at 400...415 V AC 50/60 Hz
1.5 kW at 400...415 V AC 50/60 Hz
Complementary
[in] rated current 3.5 A
[ue] rated operational voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
[ics] rated service breaking capacity 100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
15 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2
65 kA at 208Y/120 V AC 50/60 Hz conforming to UL 60947
65 kA at 240 V AC 50/60 Hz conforming to UL 60947
35 kA at 480Y/277 V AC 50/60 Hz conforming to UL 60947
8 kA Icu at 660...690 V AC 50/60 Hz conforming to IEC 60947-2
25 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
18 kA at 600Y/347 V AC 50/60 Hz conforming to UL 60947
[ith] conventional thermal current 115 A conforming to IEC 60947-4-1
Control type Toggle
Product certifications IEC
UL
CSA
CCC
EAC
ATEX
EU-RO MR
Connection pitch 27 mm without spreaders
35 mm with spreaders
Handle front plate colour 155 mm
Product or component type Motor circuit breaker
tightening torque 9 N.m for cable 16…95 mm²
5 N.m for cable 1.5…10 mm²
[uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
Connections - terminals Lugs-ring terminals
Device application Motor protection
width (w) 81 mm
mechanical robustness Vibrations: +/- 1 mm 2...13.2 Hz conforming to IEC 60068-2-6
Vibrations: 0.7 gn 13.2...100 Hz conforming to IEC 60068-2-6
Shocks: 15 gn 11 ms conforming to IEC 60068-2-27
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
Net weight 1.45 kg
Operating position Any position
power dissipation per pole 4.6 W
depth 116 mm
mechanical durability 40000 cycles
electrical durability 40000 cycles for AC-3 at 440 V In/2
40000 cycles for AC-3 at 440 V In
Pollution degree 3
Maximum operating rate 25 cyc/h
Phase failure sensitivity Yes conforming to IEC 60947-4-1
Rated duty Continuous conforming to IEC 60947-4-1
Suitability for isolation Yes conforming to IEC 60947-1
Poles description 3P
Utilisation category Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
Environment
Ambient air temp for storage/transportation -50…85 °C
Climatic withstand conforming to IACS E10
ip degree of protection IP40 conforming to IEC 60529
operating altitude 5000 m
Range of product TeSys GV4
ambient air temperature for operation -25…70 °C
standards CSA C22.2 No 60947-4-1
UL 60947-4-1
EN/IEC 60947-4-1
EN/IEC 60947-2
fire resistance 960 °C conforming to IEC 60695-2-11
About this product

The GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals is engineered to serve the prerequisites of sector experts, such as switchboard fabricators, wiring specialists, facility management firms, and industry fabricators. GV4PE03N6 provides superb quality and worth for consultants in the power management industry. This Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals and other TeSyS Deca GV4 Motor Circuit Breaker from Schneider Electric are on offer at the most competitive price and procurement time through BALTELEC.EU, a dependable distributor aiding consultants in their obtaining needs.

Contractors who have selected Schneider Electric TeSyS Deca GV4 Motor Circuit Breaker have invariably complimented the maker's sturdiness. It has been mentioned that the superlative performance of GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals extends to a variety of utilizations. Its elite features make it perfect choice to satisfy a wide array of needs, ensuring the success of your industrial, tertiary, and automation projects.

Our company devotes in providing for industrial and tertiary professionals’ needs. We understand the distinct standards and standards of our patrons in the industry. By joining forces with BaltElec, our partners gain access to the top costs and lead time of superior products like GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals from Schneider Electric at the most competitive price. Account holders take pleasure in special savings and exclusive assistance.

Don't wait and secure GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals at our certified and hassle-free virtual storefront. Don't delay in making this sensible action that validates the best quality and meets the special expectations of clients like your outfit.

If you possess any questions or concerns about GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals or any other Schneider Electric products, email us or refer to our Frequently Asked Queries section below. We have brought together answers to standard requests for information to help you further in making an enlightened decision about industrial and tertiary electrical components.

Remember, GV4PE03N6 - Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals from Schneider Electric is consistent, budget-friendly, and top-notch to other manufacturers in the TeSyS Deca GV4 Motor Circuit Breaker category. Make it a part of your electrical system today. Obtain at BALTELEC, your consistent provider for all your TeSyS Deca GV4 Motor Circuit Breaker.

In our Baltelec.eu online store you will detect Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals - GV4PE03N6 worth 291.77 €, which will be a secure and current solution for your necessities. This commodity is invented by the Schneider Electric brand using the up-to-the-minute technologies and satisfies the premier standards of well-being and workmanship. We offer items from the TeSyS Deca GV4 Motor Circuit Breaker category that integrate lastingness and practicality, which is an superb choice for various applications. Not minding of whether you desire machinery for small manufacturing or for competent industrial implementation, Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals will be a faithful aide in your assignment.

Baltelec attempts to make the obtaining process as simple and fast as attainable for our clients. We offer detailed outlines and high-quality pictures of Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals so that you can make an knowledgeable choice. A team of virtuosos is always ready to help you with any wonder in the TeSyS Deca GV4 Motor Circuit Breaker section relevant to the preferment and use of goods. We are convinced that Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic, lugs terminals will meet your hopes and become an indispensable element of your inventory for just 291.77 €.
