GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals - Schneider Electric

Expected in 2-4 weeks
GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals - Schneider Electric - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals - Schneider Electric - 0
GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals - Schneider Electric
288,24 € excl. VAT
357,41 € incl. VAT
Text About:
Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals - Schneider Electric
357,41 €
SPECIFICATIONS
Main
Device short name GV4L
Range TeSys Deca
TeSys Deca
magnetic tripping current 21…49 A
Product Name TeSys GV4
TeSys Deca
Trip unit technology Magnetic
Electronic
[ui] rated insulation voltage 800 V AC 50/60 Hz conforming to IEC 60947-2
motor power kW 0.55 kW at 400...415 V AC 50/60 Hz
0.75 kW at 400...415 V AC 50/60 Hz
0.75 kW at 500 V AC 50/60 Hz
1.1 kW at 500 V AC 50/60 Hz
1.1 kW at 660...690 V AC 50/60 Hz
1.5 kW at 660...690 V AC 50/60 Hz
1.5 kW at 500 V AC 50/60 Hz
2.2 kW at 660...690 V AC 50/60 Hz
1.1 kW at 400...415 V AC 50/60 Hz
Complementary
[in] rated current 3.5 A
[ue] rated operational voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
[ics] rated service breaking capacity 120 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
100 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
70 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
30 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
18 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2
10 kA Icu at 660...690 V AC 50/60 Hz conforming to IEC 60947-2
[ith] conventional thermal current 115 A conforming to IEC 60947-4-1
Control type Toggle
Product certifications IEC
CCC
EAC
EU-RO MR
Connection pitch 27 mm without spreaders
35 mm with spreaders
Handle front plate colour 155 mm
Product or component type Motor circuit breaker
tightening torque 9 N.m for cable 16…95 mm²
5 N.m for cable 1.5…10 mm²
[uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
Connections - terminals Lugs-ring terminals
Device application Motor protection
width (w) 81 mm
mechanical robustness Vibrations: +/- 1 mm 2...13.2 Hz conforming to IEC 60068-2-6
Vibrations: 0.7 gn 13.2...100 Hz conforming to IEC 60068-2-6
Shocks: 15 gn 11 ms conforming to IEC 60068-2-27
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
Net weight 1.5 kg
Operating position Any position
power dissipation per pole 6.1 W
depth 116 mm
mechanical durability 40000 cycles
electrical durability 40000 cycles for AC-3 at 440 V In/2
40000 cycles for AC-3 at 440 V In
Pollution degree 3
Maximum operating rate 25 cyc/h
Rated duty Continuous conforming to IEC 60947-4-1
Suitability for isolation Yes conforming to IEC 60947-1
Poles description 3P
Utilisation category Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
Environment
Ambient air temp for storage/transportation -50…85 °C
Climatic withstand conforming to IACS E10
ip degree of protection IP40 conforming to IEC 60529
operating altitude 5000 m
Range of product TeSys GV4
ambient air temperature for operation -25…70 °C
standards EN/IEC 60947-2
EN/IEC 60947-4-1
fire resistance 960 °C conforming to IEC 60695-2-11
About this product

The GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals is developed to cater to the necessities of specialized professionals, such as panel manufacturers, electrical technicians, facility management firms, and equipment creators. GV4LE03S6 furnishes exceptional reliability and worth for professionals in the electrotechnical industry. This Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals and other TeSyS Deca GV4 Motor Circuit Breaker from Schneider Electric are on offer the best price and delivery schedule through baltelec.eu, a respected reseller helping technicians in their supply needs.

Buyers who have purchased Schneider Electric TeSyS Deca GV4 Motor Circuit Breaker have commonly admired the brand's resilience. It has been noted that the outstanding functionality of GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals extends to a collection of tasks. Its ideal properties make it appropriate for diverse needs, ensuring the success of your industrial, tertiary, and automation projects.

Our professionals focuses in serving industrial and tertiary professionals’ needs. We understand the customized needs and demands of our customers in the realm. By aligning with our professionals, your organization gain access to the finest pricing and delivery period of excellent products like GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals from Schneider Electric at a reasonable price. Registered customers receive added discounts and dedicated support.

Make a move and order GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals at our safe and user-friendly platform. Don't delay in making this prudent selection that secures the supreme quality and covers the targeted specifications of suppliers like yourselves.

Should you have any matters or concerns about GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals or any other Schneider Electric products, contact us or refer to our Frequently Asked Queries section below. We have brought together answers to frequent queries to help you further in making an enlightened decision about industrial and tertiary electrical components.

Remember, GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals from Schneider Electric is dependable, reasonable, and elite to other manufacturers in the TeSyS Deca GV4 Motor Circuit Breaker category. Make it a part of your solution instantly. Procure at BaltElec, your faithful dealer for all your professional electrical equipment and automation needs.

In our Baltelec.eu online store you will locate Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals - GV4LE03S6 worth 351.65 €, which will be a steadfast and modern solution for your preferences. This object is created by the Schneider Electric brand using the current technologies and fulfills the peak standards of well-being and capacity. We propose commodities from the TeSyS Deca GV4 Motor Circuit Breaker category that combine endurance and effectiveness, which is an exceptional choice for various uses. Without consideration of whether you demand machinery for small manufacturing or for qualified industrial exploitation, Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals will be a reliable associate in your endeavor.

Baltelec endeavors to make the buying process as convenient and fast as realizable for our buyers. We offer detailed outlines and high-quality snapshots of Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals so that you can make an educated choice. A team of adepts is always ready to help you with any issues in the TeSyS Deca GV4 Motor Circuit Breaker section tied to the preferment and use of equipment. We are confident that Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals will meet your criteria and become an important element of your gear for just 351.65 €.

Popular Questions about GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals:

  • Why should I order GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals from BALTELEC?

    When you order Schneider Electric GV4LE03S6 from Baltelec, you will receive authentic quality Schneider Electric TeSyS Deca GV4 Motor Circuit Breaker products at the most advantageous pricing and turnaround time. Additionally, loyal buyersreceive additional savings and first-class attention.

  • Can you consult if Schneider Electric GV4LE03S6 is suitable for my needs?

    To confirm that Schneider Electric Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals meets the requirements of your application, we offer thorough details concerning product's specifications, features, and interoperability. You can find this data on the specific page of the device model. If you require further assistance, our customer support representative is available to assist you in making an well-informed decision.

  • What warranty coverage is provided for Schneider Electric GV4LE03S6?

    BALTELEC is committed to the excellence of the products we distribute. The standard warranty coverage for Schneider Electric TeSyS Deca GV4 Motor Circuit Breaker including Schneider Electric Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals is 12 months. Nonetheless, it depends depending on the individual item, product category, and might be extended. You can discover specific guarantee details on the Schneider Electric Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals product page or by reaching out to our support team representatives.

  • Can you arrange global shipping for GV4LE03S6 as well as other Schneider Electric products?

    Certainly. In addition to serving Estonia, Latvia, Lithuania and other European Union countries, we provide global shipping for Schneider Electric Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals. Please be aware that delivery options, fees, and delivery times might differ depending on the shipping location. In the case of complicated purchases, kindly contact BaltElec sales staff.

  • Do Schneider Electric MBC offered by Baltelec.eu comply with global norms for safety and reliability?

    Certainly. All Schneider Electric products available at Baltelec.eu online store conform to global standards such as IEC 60898-1 standard and carry the CE certification. Such norms ensure that the products meet strict security, technological, reliability, and functional requirements.

  • Can BALTELEC offer guidance on incorporating renewable energy solutions, such as solar energy systems or wind power converters, into my projects?

    Definitely!  Baltelec.eu website recognizes the importance of sustainable energy incorporation within community. Our team of professionals can help you in selecting the right Schneider Electric items, to integrate them into your renewable energy solutions}. We can offer recommendations on combining solar energy systems, wind power converters, and additional eco-friendly options to optimize energy generation and effectiveness.

  • Are there eco-friendly options available within the TeSyS Deca GV4 Motor Circuit Breaker category to support green energy initiatives?

    Definitely!Yes! Baltelec.eu online store provides various green solutions in the category of TeSyS Deca GV4 Motor Circuit Breaker that are aligned with energy-saving goals. Our top-quality Schneider Electric products, such as the GV4LE03S6 - Motor circuit breaker, TeSys GV4, 3P, 3.5 A, Icu 100 kA, magnetic, lugs terminals, are crafted with energy efficiency in mind. By using these products into your electrical system, you can optimize energy usage and lower environmental impact. Additionally, we offer affordable pricing for our eco-friendly Schneider Electric products,, making them an budget-friendly choice for promoting sustainability.

  • Is GV4LE03S6 offered by Baltelec.eu original?

    Indeed, we only offer authentic Schneider Electric products, including GV4LE03S6. We obtain our products exclusively through authorized distribution channels to ensure their authenticity and excellent performance.
