GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals - Schneider Electric

Expected in 2-4 weeks
GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals - Schneider Electric - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals - Schneider Electric - 0
GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals - Schneider Electric
219,02 € excl. VAT
271,59 € incl. VAT
Text About:
Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals - Schneider Electric
271,59 €
SPECIFICATIONS
Main
Device short name GV4L
Range TeSys Deca
TeSys Deca
magnetic tripping current 12…28 A
Product Name TeSys GV4
TeSys Deca
Trip unit technology Magnetic
Electronic
[ui] rated insulation voltage 800 V AC 50/60 Hz conforming to IEC 60947-2
motor power kW 0.25 kW at 400...415 V AC 50/60 Hz
0.37 kW at 400...415 V AC 50/60 Hz
0.55 kW at 400...415 V AC 50/60 Hz
0.75 kW at 400...415 V AC 50/60 Hz
0.37 kW at 500 V AC 50/60 Hz
0.55 kW at 500 V AC 50/60 Hz
0.75 kW at 500 V AC 50/60 Hz
1.1 kW at 500 V AC 50/60 Hz
0.55 kW at 660...690 V AC 50/60 Hz
0.75 kW at 660...690 V AC 50/60 Hz
1.1 kW at 660...690 V AC 50/60 Hz
1.5 kW at 660...690 V AC 50/60 Hz
Complementary
[in] rated current 2 A
[ue] rated operational voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
[ics] rated service breaking capacity 100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
15 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2
8 kA Icu at 660...690 V AC 50/60 Hz conforming to IEC 60947-2
25 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2
[ith] conventional thermal current 115 A conforming to IEC 60947-4-1
Control type Toggle
Product certifications IEC
CCC
EAC
EU-RO MR
Handle front plate colour 155 mm
Product or component type Motor circuit breaker
tightening torque 9 N.m for cable 16…95 mm²
5 N.m for cable 1.5…10 mm²
[uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
Connections - terminals EverLink BTR screw connectors (top) 1 cable(s) 1.5…70 mm² - solid
EverLink BTR screw connectors (top) 1 cable(s) 1.5…50 mm² - flexible
EverLink BTR screw connectors (bottom) 1 cable(s) 2.5…95 mm² - solid
EverLink BTR screw connectors (bottom) 1 cable(s) 2.5…70 mm² - flexible
Device application Motor protection
width (w) 81 mm
mechanical robustness Vibrations: +/- 1 mm 2...13.2 Hz conforming to IEC 60068-2-6
Vibrations: 0.7 gn 13.2...100 Hz conforming to IEC 60068-2-6
Shocks: 15 gn 11 ms conforming to IEC 60068-2-27
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
Net weight 1.5 kg
Operating position Any position
power dissipation per pole 6.1 W
depth 116 mm
mechanical durability 40000 cycles
electrical durability 40000 cycles for AC-3 at 440 V In/2
40000 cycles for AC-3 at 440 V In
Pollution degree 3
Maximum operating rate 25 cyc/h
Rated duty Continuous conforming to IEC 60947-4-1
Suitability for isolation Yes conforming to IEC 60947-1
Poles description 3P
Utilisation category Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
Environment
Ambient air temp for storage/transportation -50…85 °C
Climatic withstand conforming to IACS E10
ip degree of protection IP40 conforming to IEC 60529
operating altitude 5000 m
Range of product TeSys GV4
ambient air temperature for operation -25…70 °C
standards EN/IEC 60947-2
EN/IEC 60947-4-1
fire resistance 960 °C conforming to IEC 60695-2-11
About this product

The GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals is created to match the demands of technical experts, such as panel builders, circuit experts, management services, and OEMs. GV4LE02N furnishes outstanding excellence and value for designers in the automation and control industry. This Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals and other TeSyS Deca GV4 Motor Circuit Breaker from Schneider Electric can be ordered at the optimal price and shipping time through BaltElec, a trustworthy wholesaler helping tradesmen in their provision needs.

Contractors who have bought Schneider Electric TeSyS Deca GV4 Motor Circuit Breaker have steadily complimented the manufacturer’s dependability. It has been pointed out that the exceptional productivity of GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals extends to a wide range of use. Its elite aspects make it perfect choice to suit a variety of needs, ensuring your industrial, tertiary and automation projects success.

Our specialists commits in addressing industrial and tertiary professionals’ needs. We comprehend the specific criteria and standards of our partners in the realm. By working with our specialists, your enterprise receive access to the optimal costs and lead time of premium products like GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals from Schneider Electric at a competitive price. Baltelec account members get extra discounts and top-tier service.

Move quickly and buy GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals at our safe and straightforward online store. Don't delay in making this intelligent selection that promises the top quality and matches the customized requirements of users like your organization.

Should you have any inquiries or concerns about GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals or any other Schneider Electric products, reach out to us or refer to our Common Questions section below. We have curated answers to typical requests for information to back you further in making an well-informed decision about industrial and tertiary electrical components.

Remember, GV4LE02N - Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals from Schneider Electric is secure, economical, and exceptional to other manufacturers in the TeSyS Deca GV4 Motor Circuit Breaker category. Make it a part of your arrangement immediately. Acquire at BaltElec, your dependable vendor for all your TeSyS Deca GV4 Motor Circuit Breaker.

In our Baltelec.eu web store you will spot Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals - GV4LE02N worth 267.21 €, which will be a dependable and modern solution for your preferences. This object is fabricated by the Schneider Electric brand using the freshest technologies and adheres to the pinnacle standards of security and capability. We give commodities from the TeSyS Deca GV4 Motor Circuit Breaker category that mix resilience and usability, which is an premium election for various objectives. In defiance of whether you necessitate apparatus for small manufacturing or for specialized industrial employment, Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals will be a secure facilitator in your task.

Baltelec labors to make the purchasing process as uncomplicated and fast as viable for our shoppers. We offer detailed accounts and high-quality snapshots of Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals so that you can make an conscious choice. A team of virtuosos is always ready to help you with any concerns in the TeSyS Deca GV4 Motor Circuit Breaker section referencing to the determining and use of items. We are positive that Motor circuit breaker, TeSys GV4, 3P, 2 A, Icu 50 kA, magnetic, EverLink terminals will meet your anticipations and become an key element of your inventory for just 267.21 €.
