Complementary
bottom removability for modular devices
No
concurrently switching n-neutral
Yes
connection cross section of access and exit with screws, for flexible conductor
1 / 16 mm²
connection cross-sect. flexible conductor
16mm²
construction size (din 43880)
1
depth of installed product
70 mm
electric endurance in number of cycles
2000
power loss per pole at in
0.8 W
protected against nuisance tripping
No
rating current -10°c
25 A
[in] rated current
25 A
connection cross-sect. rigid cable
25mm²
degree of pollution according to iec 60664 / iec 60947-2
2
height of installed product
83 mm
number of mechanical operations
4000
rated conditional short-circuit current inc according to en 61008-1
6 kA
rating current -15°c
25 A
short-time delayed tripping
No
total power loss under in
2.6 W
[ics] rated service breaking capacity
1.5 kA
rating current -20°c
25 A
top removability for modular devices
No
type of connection
with screw
width of installed product
70 mm
connection cross-section at output with screw, for massive conductor
1 / 25 mm²
rating current -25°c
25 A
storage/transport temperature
-55…70 °C
tightening torque
2,8Nm
type of bottom connection for modular devices
BIconnect
connection cross-section for rigid conductor, upstream terminals with screws
1 / 25 mm²
rating current -5°c
25 A
type of bottom rail clip for modular devices
metallic
withstand not tripping on 8-20 μs wave
0.25 kA
connection cross-section of the access with screws, with flexible conductor
1 / 16 mm²
Rated insulation voltage
500 V
rating current 0°c
25 A
type of top connection for modular devices
with screw
rating current 10°c
25 A
type of top rail clip for modular devices
NA
rating current 15°c
25 A
Fixing mode
DIN rail type O (symmetrical)
rating current 20°c
25 A
rating current 25°c
25 A
rating current 30°c
25 A
rating current 35°c
25 A
rating current 40°c
25 A
rating current 45°c
25 A
rating current 50°c
25 A
rating current 55°c
25 A
rating current 5°c
25 A
frequency
50 Hz
Network type
AC
rating current 60°c
25 A
rating current 65°c
22 A
rating current 70°c
18 A
rated impulse withstand voltage
4000 V
Poles description
4 P
