ZCKJ404 - Limit switch body with spring return rotary head, Limit switches XC Standard, ZCKJ, w/o lever, fixed, 2C/O, snap, Pg13 - Schneider Electric - Limit switch body with spring return rotary head, Limit switches XC Standard, ZCKJ, w/o lever, fixed, 2C/O, snap, Pg13 - Schneider Electric - 0

Pending restock

ZCKJ404 – Schneider Electric

EAN: 3389110646658

64,32 € excl. VAT

79,76 € incl. VAT

Limit switch body with spring return rotary head, Limit switches XC Standard, ZCKJ, w/o lever, fixed, 2C/O, snap, Pg13 - Schneider Electric

In cart

79,76 €

SPECIFICATIONS

Main

product range Fins de course Telemecanique XC Standard

[ithe] thermal current under enclosure 10 A

name of the device ZCKJ

type of product or equipment Corps de commutateur de fin de course avec tête rotative à ressort de rappel

range name Format standard

[ui] rated insulation voltage 500 V (degré de pollution 3) se conformer à CEI 60947-1 pour bloc de contacts
300 V se conformer à CSA C22.2 No 14 pour bloc de contacts
300 V se conformer à UL 508 pour bloc de contacts

type of engagement 2 3 positions

Complementary

associated accessories XCKJ

[ie] rated operational current 3 A à 240 V, AC-15, A300 se conformer à EN/CEI 60947-5-1 appendix A
0,27 A à 250 V, DC-13, Q300 se conformer à EN/CEI 60947-5-1 appendix A

contact description 2 "O/F"

local display Sans

Handle front plate colour 102 mm

[uimp] rated impulse withstand voltage 6 kV se conformer à CEI 60664
6 kV se conformer à CEI 60947-1

cable entry 1 entrée filetée pour presse-étoupe Pg 13,5

product weight 0,455 kg

description of iso n°1 terminals (23-24)NON
(11-12)NC
(13-14)NON
(21-22)NC

contact operation À action brusque

body material Métal

contact material Contacts plaqués argent

width (w) 40 mm

crankcase type Fixe

attack move De gauche et de droite

depth 60 mm

minimum attack speed 0,01 m/min

positive aperture Sans

electrical connection Borniers à vis-étrier, capacité de serrage: 1 x 0,75…2 x 1,5 mm²

maximum resistance between terminals 0,25 mOhm se conformer à CEI 60255-7 catégorie 3

short circuit protection 10 A cartouche fusible, type gG

Poles description 2

Environment

degree of protection (ip) IP66

environment characteristic Standard

operating temperature -25…70 °Cpourstandard

shock resistance (ik) IK07

storage room temperature -40…70 °C

Q&A and product info

Contact Us

Professional sales of electrical equipment in Estonia, Latvia, Lithuania, and Finland. Certified low-voltage components, circuit breakers, contactors, and industrial automation solutions. Same-day quotations and fast delivery across the Baltics and Finland.

+372 5326 4976

Mon–Fri 9:00–17:00

info@baltelec.eu

Response within 2 hours

ZCKJ404 is a industrial Limit Switches XC product designed for enterprises. BaltElec specializes in wholesale and product distribution in Estonia, Latvia, Lithuania, and Finland.

Original Schneider Electric product, certificates and compliance documents available.
Project pricing – request a quote for larger quantities (MOQ may apply).
Fast delivery across the Baltics and Finland; cooperation with trusted couriers.
Technical support and application suitability advice based on your requirements.

Pricing: Request a special offer. The price depends on quantity, delivery, and payment terms.

Limit Switches XC specifications may vary by configuration. For an exact match, please send us your application details or check the technical data sheet.
