A9C15509 - Acti9 iDT40 TL - quick connection impulse relay - 16A - 2P - 230V - Schneider Electric - Acti9 iDT40 TL - quick connection impulse relay - 16A - 2P - 230V - Schneider Electric - 0

Pending restock

A9C15509 – Schneider Electric

EAN: 3606480381218

35,20 € excl. VAT

43,65 € incl. VAT

Acti9 iDT40 TL - quick connection impulse relay - 16A - 2P - 230V - Schneider Electric

In cart

43,65 €

SPECIFICATIONS

Default

Series iC60

Main

product range Acti9

[uc] control circuit voltage 230 V CA 50 Hz

name of the device TL40

type of product or equipment Télérupteur

composition of the poles 2F

Product Name Acti9 TL40

[ui] rated insulation voltage 500 V CA

poles 2P

Complementary

9 mm pitches 2

associated accessories Sans auxiliaire

[in] rated operational current 16 A

[ue] rated operational voltage 250 V CA 50 Hz

application Standard

control signal type Impulsion

Handle front plate colour 87 mm

pulse duration 50 ms

tightening torque 1 N.m

[uimp] rated impulse withstand voltage 2,5 kV

average fuel consumption when going 19 VA

product weight 105 g

mode d'installation Fixe

electrical life AC-22: 200000 cycle

connection mode Circuit de puissance: borne du type à cage 1 câble(s) 1…4 mm² rigide
Circuit de puissance: borne du type à cage 2 câble(s) 1…2,5 mm² rigide
Circuit de puissance: borne du type à cage 1 câble(s) 1…4 mm² souple
Circuit de puissance: borne du type à cage 2 câble(s) 1…2,5 mm² souple
Télécommande: borne du type à cage 1 câble(s) 0,5…1,5 mm² rigide
Télécommande: borne du type à cage 1 câble(s) 0,5…1,5 mm² souple
Circuit de puissance: borne du type à cage 1 câble(s) 1…4 mm² flexible avec embout
Circuit de puissance: borne du type à cage 2 câble(s) 1…2,5 mm² flexible avec embout
Télécommande: borne du type à cage 1 câble(s) 0,5…1,5 mm² flexible avec embout

width (w) 18 mm

network frequency 50 Hz

switching frequency 5 commutations/minute

voltage indication Indication ON/OFF

type of remote control Bouton-poussoir lumineux 3 mA

wire stripping length 9 mm

depth 69 mm

mounting bracket Rail DIN

Network type CA

order type Commande manuelle et à distance

Environment

degree of pollution 3

ip degree of protection IP20 se conformer à CEI 60529 (avec ouverture)
IP40 se conformer à CEI 60529 (en enveloppe)

standards CEI 60669-1
CEI 60669-2-2

quality labels NF

relative humidity 95 % à 55 °C

operating ambient air temperature -20…50 °C

storage room temperature -40…80 °C

sound pressure 60 dB
