C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting - Schneider Electric

Expected in 2-4 weeks EAN: 3606481998408
C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting - Schneider Electric - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting - Schneider Electric - 0
EAN: 3606481998408
C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting - Schneider Electric
322,74 € excl. VAT
393,74 € incl. VAT
Text About:
ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting - Schneider Electric
393,74 €
SPECIFICATIONS
Main
Range ComPacT nouvelle génération
sectioning ability Oui se conformer à EN/CEI 60947-2
job category Catégorie A
name of the device NSX160N
type of product or equipment Disjoncteur
Product Name ComPacT NSX nouvelle génération
[ui] rated insulation voltage 800 V CA 50/60 Hz
trigger protection functions I
circuit breaker installation mode Fixe
performance level N 50 kA 415 V CA
trigger name MA
type of trigger Magnétique
ultimate short-circuit breaking capacity [icu] 90 kA Icu à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA Icu à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA Icu à 440 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA Icu à 500 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA Icu à 525 V CA 50/60 Hz se conformer à CEI 60947-2
10 kA Icu à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2
protected poles 3d
Complementary
"no" connection 35 mm
[in] rated operational current 150 A à 65 °C
[ue] rated operational voltage 690 V CA 50/60 Hz
application Protection moteur
[ics] rated service breaking capacity 90 kA à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA à 440 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA à 500 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA à 525 V CA 50/60 Hz se conformer à CEI 60947-2
10 kA à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2
short-time protection threshold setting range [isd] 9...14 x In
Handle front plate colour 161 mm
trigger caliber 150 A à 65 °C
[uimp] rated impulse withstand voltage 8 kV
product weight 2,2 kg
electrical life 40000 cycle à 440 V In/2
20000 cycle à 440 V In
15000 cycle à 690 V In/2
7500 cycle à 690 V In
setting the differential protection time delay δt Réglable
mechanical endurance 40000 cycle
width (w) 105 mm
network frequency 50/60 Hz
upstream connection Façade
downstream connection Façade
instantaneous protection threshold setting range [ii] (short-circuit protection) 9...14 x In
number of slots for electrical auxiliaries 5 slot(s)
mounting bracket Plaque arrière
depth (p) 86 mm
Network type CA
differential protection Sans
mounting position Horizontal et vertical
Flat on the back
power loss per pole 8,55 W
instantaneous protection sensor setting ii (short circuit protection) Réglable 9 positions
order type Par maneton
kind of protection I : for protection (magnétique) court-circuit
Poles description 3P
Environment
degree of pollution 3 se conformer à CEI 60664-1
ip degree of protection IP40 se conformer à CEI 60529
operating altitude 0...2000 m sans réduction de courant
2000 m...5000 m avec réduction de courant
product certificates CCC
EAC
Marine
class of protection against electric shock Classe II
operating ambient temperature -25…70 °C
overvoltage category Classe II
standards EN/CEI 60947
relative humidity 0…95 %
shock resistance ik IK07 se conformer à CEI 62262
storage room temperature -50…85 °C
About this product

The C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting is engineered to accommodate the needs of specialized professionals, such as electrical contractors, wiring specialists, management services, and primary equipment suppliers. C16N3MA150 offers unmatched performance and worth for engineers in the electrical and automation industry. This ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting and other Compact NSX from Schneider Electric are procurable at the most favorable cost and supply period through BaltElec online store, a reputable reseller assisting practitioners in their purchasing needs.

Contractors who have used Schneider Electric Compact NSX have invariably commended the brand's resilience. It has been stated that the unmatched performance of C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting extends to a broad spectrum of use. Its elite aspects make it appropriate for different applications, ensuring the success of your industrial, tertiary, and automation projects.

Our team commits in serving industrial and tertiary professionals’ needs. We get the specific expectations and desires of our partners in the realm. By partnering with BaltElec, your company access access to the finest charges and lead time of the top-of-the-line products like C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting from Schneider Electric at a value-for-money price. Registered users take pleasure in added discounts and exclusive assistance.

Don't wait and obtain C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting at our secure and efficient e-commerce site. Don't delay in making this thoughtful move that confirms the supreme quality and meets the special necessities of purchasers like yourselves.

If there are any inquiries or concerns about C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting or any other Schneider Electric products, send us a note or refer to our Common Questions section below. We have amassed answers to regular concerns to benefit you further in making an informed decision about industrial and tertiary electrical components.

Remember, C16N3MA150 - ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting from Schneider Electric is unfailing, cost-effective, and elite to other manufacturers in the Compact NSX category. Make it a part of your configuration immediately. Take advantage of at BaltElec, your faithful dealer for all your Schneider Electric.

In our Baltelec.eu digital store you will uncover ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting - C16N3MA150 worth 393.74 €, which will be a trustworthy and up-to-date solution for your wishes. This object is formulated by the Schneider Electric brand using the current technologies and satisfies the highest standards of safety and capacity. We propose goods from the Compact NSX category that associate durability and utility, which is an excellent possibility for various applications. Despite of whether you want apparatus for small generation or for adept industrial exertion, ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting will be a secure associate in your endeavor.

Baltelec tries to make the obtaining process as simple and fast as achievable for our buyers. We offer detailed descriptions and high-quality illustrations of ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting so that you can make an advised choice. A team of authorities is always ready to help you with any questions in the Compact NSX section involved to the selection and use of items. We are persuaded that ComPacT NSX160N - circuit breaker - MA 150A - 3P3D - 50kA - fixed mounting will meet your expectations and become an key element of your apparatus for just 393.74 €.
