C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting - Schneider Electric

Expected in 2-4 weeks EAN: 3606481997173
C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting - Schneider Electric - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting - Schneider Electric - 0
EAN: 3606481997173
C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting - Schneider Electric
312,89 € excl. VAT
381,72 € incl. VAT
Text About:
ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting - Schneider Electric
381,72 €
SPECIFICATIONS
Main
Range ComPacT nouvelle génération
sectioning ability Oui se conformer à EN/CEI 60947-2
job category Catégorie A
name of the device NSX160F
type of product or equipment Disjoncteur
Product Name ComPacT NSX nouvelle génération
[ui] rated insulation voltage 800 V CA 50/60 Hz
trigger protection functions LSoI
circuit breaker installation mode Fixe
performance level F 36 kA 415 V CA
trigger name Micrologic 2.2
type of trigger Électronique
ultimate short-circuit breaking capacity [icu] 85 kA Icu à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA Icu à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA Icu à 440 V CA 50/60 Hz se conformer à CEI 60947-2
30 kA Icu à 500 V CA 50/60 Hz se conformer à CEI 60947-2
22 kA Icu à 525 V CA 50/60 Hz se conformer à CEI 60947-2
8 kA Icu à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA à 480 V CA 50/60 Hz se conformer à UL 508
protected poles 3d
Complementary
"no" connection 35 mm
[in] rated operational current 100 A à 40 °C
[ue] rated operational voltage 690 V CA 50/60 Hz
application Distribution
[ics] rated service breaking capacity 85 kA à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA à 440 V CA 50/60 Hz se conformer à CEI 60947-2
30 kA à 500 V CA 50/60 Hz se conformer à CEI 60947-2
22 kA à 525 V CA 50/60 Hz se conformer à CEI 60947-2
8 kA à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2
short-time protection threshold setting range [isd] 1,5...10 x Ir
Handle front plate colour 161 mm
trigger caliber 100 A à 40 °C
[uimp] rated impulse withstand voltage 8 kV
product weight 2,2 kg
tsd short time protection time delay setting Fixe
electrical life 40000 cycle à 440 V In/2
20000 cycle à 440 V In
15000 cycle à 690 V In/2
7500 cycle à 690 V In
setting the differential protection time delay δt Réglable 9 positions
mechanical endurance 40000 cycle
width (w) 105 mm
network frequency 50/60 Hz
thermal memory 20 minutes avant et après le déclenchement
Local signalling pourprêt à fonctionner DEL clignotante (vert)
poursurcharge DEL 105 % Ir (rouge)
poursurcharge DEL 90 % Ir (orange)
long time protection time delay setting range [tr] 400 s à 1,5 x Ir
16 s à 6 x Ir
11 s à 7,2 x Ir
setting range of the long-time protection threshold [ir] (thermal protection) 40...100 A
upstream connection Façade
downstream connection Façade
instantaneous protection threshold setting range [ii] (short-circuit protection) 1500 A
number of slots for electrical auxiliaries 5 slot(s)
mounting bracket Plaque arrière
depth (p) 86 mm
Network type CA
differential protection Sans
mounting position Horizontal et vertical
Flat on the back
power loss per pole 3,6 W
tr long time protection time delay setting Fixe
instantaneous protection sensor setting ii (short circuit protection) Fixe
ir long time protection sensor setting (thermal protection) Réglable 9 positions
order type Par maneton
kind of protection L : for protection surcharge (long retard)
So : for protection court retard avec retard fixe
I : for protection instantanée contre court-circuit
zsi logic selective latch area Sans
Poles description 3P
Environment
degree of pollution 3 se conformer à CEI 60664-1
ip degree of protection IP40 se conformer à CEI 60529
operating altitude 0...2000 m sans réduction de courant
2000 m...5000 m avec réduction de courant
product certificates CCC
EAC
Marine
class of protection against electric shock Classe II
operating ambient temperature -25…70 °C
overvoltage category Classe II
standards EN/CEI 60947
relative humidity 0…95 %
shock resistance ik IK07 se conformer à CEI 62262
storage room temperature -50…85 °C
About this product

The C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting is engineered to respond to the prerequisites of sector experts, such as system integrators, electric engineers, facility management firms, and industry fabricators. C16F32D100 offers superb standards and gain for technicians in the energy management industry. This ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting and other Compact NSX from Schneider Electric can be obtained at the most favorable cost and lead time through BALTELEC website, a trustworthy provider attending to tradesmen in their procurement needs.

Professionals who have secured Schneider Electric Compact NSX have invariably appreciated the producer's reliability. It has been outlined that the superlative capability of C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting extends to a variety of applications. Its ideal qualities make it great selection for wide-ranging specifications. Your developed solution will excel in quality, energy-efficiency and price.

BaltElec team focuses in meeting industrial and tertiary professionals’ needs. We grasp the customized demands and desires of our clients in the sector. By collaborating with Baltelec.eu, our customers acquire access to the finest price lists and delivery period of superior products like C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting from Schneider Electric at an affordable price. Registered users enjoy exclusive discounts and priority service.

Start immediately and request C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting at our reliable and user-friendly webshop. Don't delay in making this shrewd resolution that secures the highest quality and complies with the specific expectations of contractors like your team.

In case you have any questions or concerns about C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting or any other Schneider Electric products, connect with us or refer to our Common Questions section below. We have assembled answers to standard matters to benefit you further in making an considered decision about industrial and tertiary electrical components.

Remember, C16F32D100 - ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting from Schneider Electric is safe, economical, and high-quality to other vendors in the Compact NSX category. Make it a part of your arrangement straight away. Purchase at BaltElec, your preferred supplier for all your Schneider Electric.

In our Baltelec.eu electronic store you will come across ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting - C16F32D100 worth 381.72 €, which will be a steadfast and state-of-the-art solution for your requirements. This product is designed by the Schneider Electric brand using the latest technologies and meets the leading standards of reliability and productivity. We provide articles from the Compact NSX category that mix sturdiness and usefulness, which is an first-rate election for various purposes. In spite of whether you desire gear for small generation or for professional industrial exploitation, ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting will be a faithful aide in your work.

Baltelec tries to make the getting process as smooth and fast as feasible for our clients. We offer detailed explanations and high-quality photos of ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting so that you can make an knowledgeable choice. A team of pros is always ready to help you with any uncertainties in the Compact NSX section pertaining to the determining and use of materials. We are certain that ComPacT NSX160F - circuit breaker - MicroLogic 2.2 100A - 3P3D - 36kA - fixed mounting will meet your hopes and become an crucial element of your gear for just 381.72 €.
