C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting - Schneider Electric

Expected in 2-4 weeks EAN: 3606481996237
C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting - Schneider Electric - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting - Schneider Electric - 0
EAN: 3606481996237
C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting - Schneider Electric
245,77 € excl. VAT
299,84 € incl. VAT
Text About:
ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting - Schneider Electric
299,84 €
SPECIFICATIONS
Main
Range ComPacT nouvelle génération
sectioning ability Oui se conformer à EN/CEI 60947-2
job category Catégorie A
name of the device NSX160B
type of product or equipment Disjoncteur
Product Name ComPacT NSX nouvelle génération
[ui] rated insulation voltage 800 V CA 50/60 Hz
trigger protection functions LI
circuit breaker installation mode Fixe
performance level B 25 kA 415 V CA
trigger name TM-D
type of trigger Thermique-magnétique
ultimate short-circuit breaking capacity [icu] 40 kA Icu à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
25 kA Icu à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
20 kA Icu à 440 V CA 50/60 Hz se conformer à CEI 60947-2
15 kA Icu à 500 V CA 50/60 Hz se conformer à CEI 60947-2
protected poles 3d
Complementary
"no" connection 35 mm
[in] rated operational current 125 A à 40 °C
[ue] rated operational voltage 690 V CA 50/60 Hz
application Distribution
[ics] rated service breaking capacity 40 kA à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
25 kA à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
20 kA à 440 V CA 50/60 Hz se conformer à CEI 60947-2
15 kA à 500 V CA 50/60 Hz se conformer à CEI 60947-2
Handle front plate colour 161 mm
trigger caliber 125 A à 40 °C
[uimp] rated impulse withstand voltage 8 kV
product weight 2,2 kg
electrical life 40000 cycle à 440 V In/2
20000 cycle à 440 V In
15000 cycle à 690 V In/2
7500 cycle à 690 V In
mechanical endurance 40000 cycle
width (w) 105 mm
network frequency 50/60 Hz
long time protection time delay setting range [tr] 120…400 s à 1,5 x In
15 s à 6 x Ir
setting range of the long-time protection threshold [ir] (thermal protection) 0,7 à 1 x In
upstream connection Façade
downstream connection Façade
instantaneous protection threshold setting range [ii] (short-circuit protection) 1250 A
number of slots for electrical auxiliaries 5 slot(s)
mounting bracket Plaque arrière
depth (p) 86 mm
Network type CA
differential protection Sans
mounting position Horizontal et vertical
Flat on the back
power loss per pole 10,78 W
tr long time protection time delay setting Fixe
instantaneous protection sensor setting ii (short circuit protection) Fixe
ir long time protection sensor setting (thermal protection) Réglable
order type Par maneton
kind of protection L : for protection surcharge (thermique)
I : for protection (magnétique) court-circuit
Poles description 3P
Environment
degree of pollution 3 se conformer à CEI 60664-1
ip degree of protection IP40 se conformer à CEI 60529
operating altitude 0...2000 m sans réduction de courant
2000 m...5000 m avec réduction de courant
product certificates CCC
EAC
Marine
class of protection against electric shock Classe II
operating ambient temperature -25…70 °C
overvoltage category Classe II
standards EN/CEI 60947
relative humidity 0…95 %
shock resistance ik IK07 se conformer à CEI 62262
storage room temperature -50…85 °C
About this product

The C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting is crafted to fulfill the conditions of sector experts, such as panel manufacturers, electricians, service providers, and primary equipment suppliers. C16B3TM125 grants outstanding efficiency and worth for experts in the automation and control industry. This ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting and other Compact NSX from Schneider Electric can be acquired at the finest pricing and shipment duration through BaltElec, a dependable reseller attending to industry experts in their sourcing needs.

Buyers who have secured Schneider Electric Compact NSX have invariably admired the maker's dependability. It has been highlighted that the outstanding workmanship of C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting extends to a spectrum of functions. Its premium specifications make it proper pick for wide-ranging specifications, assuring the success of your industrial, tertiary, and automation ventures.

Our company commits in catering industrial and tertiary professionals’ needs. We recognize the distinct needs and standards of our partners in the market. By teaming up with Baltelec team, our customers acquire access to the optimal price and inventory of premium products like C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting from Schneider Electric at an economical price. Baltelec account members benefit from added discounts and preferred assistance.

Take action and get C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting at our protected and hassle-free virtual storefront. Don't delay in making this clever option that secures the supreme quality and addresses the individual needs of users like your firm.

Should you experience any inquiries or concerns about C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting or any other Schneider Electric products, message us or refer to our Information center section below. We have gathered answers to frequent requests for information to guide you further in making an considered decision about industrial and tertiary electrical components.

Remember, C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting from Schneider Electric is unfailing, cost-effective, and excellent to other vendors in the Compact NSX category. Make it a part of your configuration promptly. Purchase at Baltelec e-shop, your trusted partner for all your professional electrical equipment and automation needs.

In our Baltelec.eu cyber store you will find ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting - C16B3TM125 worth 299.84 €, which will be a constant and cutting-edge solution for your needs. This thing is constructed by the Schneider Electric brand using the newest technologies and conforms to the highest standards of reliability and performance. We offer merchandise from the Compact NSX category that integrate sturdiness and practicality, which is an excellent choice for various roles. Despite of whether you call for devices for small construction or for specialized industrial employment, ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting will be a steadfast facilitator in your work.

Baltelec tries to make the securing process as smooth and fast as possible for our buyers. We offer detailed reports and high-quality images of ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting so that you can make an conscious choice. A team of pros is always ready to help you with any uncertainties in the Compact NSX section referencing to the opting and use of goods. We are positive that ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting will meet your wishes and become an crucial element of your setup for just 299.84 €.

Common Questions about C16B3TM125 - ComPacT NSX160B - circuit breaker - TM-D 125A - 3P3D - 25kA - fixed mounting:
