C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs - Schneider Electric

Pending restock
C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs - Schneider Electric - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs - Schneider Electric - 0
C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs - Schneider Electric
180,40 € excl. VAT
223,69 € incl. VAT
Text About:
Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs - Schneider Electric
223,69 €
SPECIFICATIONS
Main
Device short name NSXm 63E
Range ComPacT new generation
circuit breaker mounting mode Fixed
Neutral position Left
Protected poles description 4D
Product Name ComPacT NSXm new generation
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit rating 25 A at 40 °C
[ui] rated insulation voltage 800 V AC 50/60 Hz
Trip unit protection functions LI
performance level E 16 kA 415 V AC
Complementary
9 mm pitches 12 module
[ii] instantaneous pick-up adjustment range 600 A
[in] rated current 25 A at 40 °C
[ue] rated operational voltage 690 V AC 50/60 Hz
[ics] rated service breaking capacity 25 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
16 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
8 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
Control type Toggle
depth (d) 80 mm
[ir] long-time protection pick-up adjustment range 0.7...1 x In
Connection pitch 35 mm with spreaders
27 mm without spreaders
Handle front plate colour 137 mm
Product or component type Circuit breaker
[uimp] rated impulse withstand voltage 8 kV
connection terminals 1 Everlink lug wire size 2.5…95 mm², rigid or stranded aluminium/copper
1 Everlink lug wire size 2.5…70 mm², flexible copper
Device application Distribution
width (w) 108 mm
network frequency 50/60 Hz
Colour Grey (RAL 7016)
Ik degree of protection IK07 conforming to IEC 62262
Local signalling Flag (green) for presence of auxiliary contacts
long-time pick-up adjustment type ir (thermal protection) Adjustable
Net weight 1.42 kg
long-time protection delay adjustment type tr Fixed
Downside connection Front
number of slots for electrical auxiliaries 1 slot(s) for auxiliary switch OF
1 slot(s) for alarm switch SD
1 slot(s) for voltage release MN or MX
Earth-leakage protection Without
Mounting support Backplate
power dissipation per pole 2.83 W
mechanical durability 20000 cycles
neutral protection setting 1 x Ir (4D)
electrical durability 20000 cycles at 440 V In/2
10000 cycles at 440 V In
10000 cycles at 690 V In/2
5000 cycles at 690 V In
Network type AC
instantaneous protection pick-up adjustment type ii Fixed
Pollution degree 3 conforming to IEC 60664-1
mounting position Horizontal and vertical
Flat on the back
Suitability for isolation Yes conforming to IEC 60947-2
Poles description 4P
Upside connection Front
Utilisation category Category A
Environment
Ambient air temp for storage/transportation -50…85 °C
ip degree of protection IP40 conforming to IEC 60529
operating altitude 2000 m without derating
5000 m with derating
Range of product ComPacT NSXm new generation
ambient air temperature for operation -25…70 °C
standards EN/IEC 60947
relative humidity 0…95 %
About this product

The C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs is developed to respond to the demands of industry experts, such as panel manufacturers, circuit experts, repair companies, and original manufacturers. C11E4TM025L delivers impressive integrity and worth for professionals in the power management industry. This Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs and other Compact NSXm from Schneider Electric can be bought at the lowest cost and distribution time through BaltElec website, a respected reseller supporting practitioners in their gathering needs.

Technicians who have adopted Schneider Electric Compact NSXm have steadily admired the creator's sturdiness. It has been emphasized that the remarkable productivity of C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs extends to a multitude of use. Its supreme specifications make it proper pick to cater to varied requirements, ensuring the success of your industrial, tertiary, and automation projects.

Our specialists commits in meeting industrial and tertiary professionals’ needs. We comprehend the distinct criteria and anticipations of our consumers in the market. By teaming up with our professionals, your organization get access to the premier charges and supply timeline of first-rate products like C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs from Schneider Electric at an economical price. Authorized buyers receive added discounts and premium support.

Take action and grab C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs at our dependable and efficient e-commerce site. Don't delay in making this thoughtful plan that promises the highest quality and meets the targeted expectations of suppliers like your group.

In the event of any uncertainties or concerns about C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs or any other Schneider Electric products, message us or refer to our Help section section below. We have put together answers to standard concerns to back you further in making an informed decision about industrial and tertiary electrical components.

Remember, C11E4TM025L - Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs from Schneider Electric is secure, thrifty, and high-quality to its counterparts in the Compact NSXm category. Don't hesitate to make it a part of your apparatus now. Acquire at Baltelec e-shop, your reliable source for all your Compact NSXm.

In our Baltelec.eu virtual store you will come across Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs - C11E4TM025L worth 220.08 €, which will be a trustworthy and new solution for your demands. This merchandise is produced by the Schneider Electric brand using the latest technologies and aligns with the pinnacle standards of guarding and capability. We give produce from the Compact NSXm category that unite longevity and utility, which is an superior choice for various purposes. Without consideration of whether you demand machinery for small manufacturing or for adept industrial application, Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs will be a sure companion in your occupation.

Baltelec endeavors to make the attaining process as accessible and fast as doable for our customers. We offer detailed summaries and high-quality portrayals of Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs so that you can make an advised choice. A team of maestros is always ready to help you with any uncertainties in the Compact NSXm section involved to the determining and use of wares. We are persuaded that Circuit breaker, ComPacT NSXm 63E, 16kA/415VAC, 4 poles 4D (neutral fully protected), TMD trip unit 25A, EverLink lugs will meet your requirements and become an needed element of your hardware for just 220.08 €.
