C10W3TM080 - Circuit breaker, ComPacT NSX100HB2, 100kA/690VAC, 3 poles, TMD trip unit 80A - Schneider Electric

Expected in 2-4 weeks EAN: 3606482002135

EAN: 3606482002135

543,39 € excl. VAT

662,94 € incl. VAT

Text About:

Circuit breaker, ComPacT NSX100HB2, 100kA/690VAC, 3 poles, TMD trip unit 80A - Schneider Electric

In cart

662,94 €

SPECIFICATIONS

Main

Range ComPacT nouvelle génération

sectioning ability Oui se conformer à EN/CEI 60947-2

job category Catégorie A

name of the device NSX100HB2

type of product or equipment Disjoncteur

Product Name ComPacT NSX nouvelle génération

[ui] rated insulation voltage 800 V CA 50/60 Hz

trigger protection functions LI

circuit breaker installation mode Fixe

performance level HB2 100 kA 690 V CA

trigger name TM-D

type of trigger Thermique-magnétique

ultimate short-circuit breaking capacity [icu] 100 kA Icu à 500 V CA 50/60 Hz se conformer à CEI 60947-2
100 kA Icu à 525 V CA 50/60 Hz se conformer à CEI 60947-2
100 kA Icu à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2

protected poles 3d

Complementary

"no" connection 35 mm

[in] rated operational current 80 A à 40 °C

[ue] rated operational voltage 690 V CA 50/60 Hz

application Distribution

[ics] rated service breaking capacity 100 kA à 500 V CA 50/60 Hz se conformer à CEI 60947-2
100 kA à 525 V CA 50/60 Hz se conformer à CEI 60947-2
100 kA à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2

Handle front plate colour 161 mm

trigger caliber 80 A à 40 °C

[uimp] rated impulse withstand voltage 8 kV

product weight 2,05 kg

electrical life 20000 cycle à 440 V In/2
10000 cycle à 440 V In
10000 cycle à 690 V In/2
5000 cycle à 690 V In

mechanical endurance 20000 cycle

width (w) 105 mm

network frequency 50/60 Hz

long time protection time delay setting range [tr] 120…400 s à 1,5 x In
15 s à 6 x Ir

setting range of the long-time protection threshold [ir] (thermal protection) 0,7 à 1 x In

upstream connection Façade

downstream connection Façade

instantaneous protection threshold setting range [ii] (short-circuit protection) 640 A

number of slots for electrical auxiliaries 5 slot(s)

mounting bracket Plaque arrière

depth (p) 86 mm

Network type CA

differential protection Sans

mounting position Horizontal et vertical
Flat on the back

power loss per pole 8,77 W

tr long time protection time delay setting Fixe

instantaneous protection sensor setting ii (short circuit protection) Fixe

ir long time protection sensor setting (thermal protection) Réglable

order type Par maneton

kind of protection L : for protection surcharge (thermique)
I : for protection (magnétique) court-circuit

Poles description 3P

Environment

degree of pollution 3 se conformer à CEI 60664-1

ip degree of protection IP40 se conformer à CEI 60529

operating altitude 0...2000 m sans réduction de courant
2000 m...5000 m avec réduction de courant

product certificates Marine
EAC
CCC

class of protection against electric shock Classe II

operating ambient temperature -25…70 °C

overvoltage category Classe II

standards EN/CEI 60947

relative humidity 0…95 %

shock resistance ik IK07 se conformer à CEI 62262

storage room temperature -50…85 °C
