C10N6TM016 - Circuit breaker, ComPacT NSX100N, 50kA/415VAC, 4 poles 3D (neutral not protected), TMD trip unit 16A - Schneider Electric

Expected in 2-4 weeks EAN: 3606481997876

EAN: 3606481997876

242,01 € excl. VAT

295,25 € incl. VAT

Text About:

Circuit breaker, ComPacT NSX100N, 50kA/415VAC, 4 poles 3D (neutral not protected), TMD trip unit 16A - Schneider Electric

In cart

295,25 €

SPECIFICATIONS

Main

Range ComPacT nouvelle génération

sectioning ability Oui se conformer à EN/CEI 60947-2

job category Catégorie A

name of the device NSX100N

type of product or equipment Disjoncteur

Product Name ComPacT NSX nouvelle génération

[ui] rated insulation voltage 800 V CA 50/60 Hz

trigger protection functions LI

circuit breaker installation mode Fixe

performance level N 50 kA 415 V CA

neutral pole position Gauche

trigger name TM-D

type of trigger Thermique-magnétique

ultimate short-circuit breaking capacity [icu] 90 kA Icu à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA Icu à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA Icu à 440 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA Icu à 500 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA Icu à 525 V CA 50/60 Hz se conformer à CEI 60947-2
10 kA Icu à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2

protected poles 3d

Complementary

"no" connection 35 mm

[in] rated operational current 16 A à 40 °C

[ue] rated operational voltage 690 V CA 50/60 Hz

application Distribution

[ics] rated service breaking capacity 90 kA à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA à 380/415 V CA 50/60 Hz se conformer à CEI 60947-2
50 kA à 440 V CA 50/60 Hz se conformer à CEI 60947-2
36 kA à 500 V CA 50/60 Hz se conformer à CEI 60947-2
35 kA à 525 V CA 50/60 Hz se conformer à CEI 60947-2
10 kA à 660/690 V CA 50/60 Hz se conformer à CEI 60947-2

Handle front plate colour 161 mm

trigger caliber 16 A à 40 °C

[uimp] rated impulse withstand voltage 8 kV

product weight 2,4 kg

electrical life 50000 cycle à 440 V In/2
30000 cycle à 440 V In
20000 cycle à 690 V In/2
10000 cycle à 690 V In

mechanical endurance 50000 cycle

width (w) 140 mm

network frequency 50/60 Hz

long time protection time delay setting range [tr] 120…400 s à 1,5 x In
15 s à 6 x Ir

setting range of the long-time protection threshold [ir] (thermal protection) 0,7 à 1 x In

upstream connection Façade

downstream connection Façade

instantaneous protection threshold setting range [ii] (short-circuit protection) 190 A

number of slots for electrical auxiliaries 5 slot(s)

mounting bracket Plaque arrière

neutral protection setting Aucune protection (3d)

depth (p) 86 mm

Network type CA

differential protection Sans

mounting position Horizontal et vertical
Flat on the back

power loss per pole 2,92 W

tr long time protection time delay setting Fixe

instantaneous protection sensor setting ii (short circuit protection) Fixe

ir long time protection sensor setting (thermal protection) Réglable

order type Par maneton

kind of protection L : for protection surcharge (thermique)
I : for protection (magnétique) court-circuit

Poles description 4P

Environment

degree of pollution 3 se conformer à CEI 60664-1

ip degree of protection IP40 se conformer à CEI 60529

operating altitude 0...2000 m sans réduction de courant
2000 m...5000 m avec réduction de courant

product certificates CCC
EAC
Marine

class of protection against electric shock Classe II

operating ambient temperature -25…70 °C

overvoltage category Classe II

standards EN/CEI 60947

relative humidity 0…95 %

shock resistance ik IK07 se conformer à CEI 62262

storage room temperature -50…85 °C
