C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting - Schneider Electric

Expected in 2-4 weeks EAN: 3606481995773
C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting - Schneider Electric - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting - Schneider Electric - 0
EAN: 3606481995773
C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting - Schneider Electric
127,31 € excl. VAT
155,32 € incl. VAT
Text About:
ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting - Schneider Electric
155,32 €
SPECIFICATIONS
Main
Range ComPacT nouvelle génération
sectioning ability Oui se conformer à EN/CEI 60947-2
job category Catégorie A
name of the device NSX100M
type of product or equipment Disjoncteur
Product Name ComPacT NSX nouvelle génération
[ui] rated insulation voltage 750 V CA 50/60 Hz se conformer à CEI 60947-2
trigger protection functions LI
circuit breaker installation mode Fixe
performance level M 40 kA 240 V CA
trigger name TM-D
type of trigger Thermique-magnétique
ultimate short-circuit breaking capacity [icu] 40 kA Icu à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
85 kA Icu à 250 V CC se conformer à CEI 60947-2
protected poles 1D
Complementary
"no" connection 35 mm
[in] rated operational current 50 A à 40 °C
[ue] rated operational voltage 277 V CA 50/60 Hz
250 V CC 50/60 Hz
application Distribution
[ics] rated service breaking capacity 40 kA à 220/240 V CA 50/60 Hz se conformer à CEI 60947-2
85 kA à 250 V CC se conformer à CEI 60947-2
Handle front plate colour 161 mm
trigger caliber 50 A à 40 °C
[uimp] rated impulse withstand voltage 8 kV se conformer à CEI 60947-2
product weight 0,7 kg
electrical life 20000 cycle à 277 V In/2
10000 cycle à 277 V In
mechanical endurance 20000 cycle
width (w) 35 mm
network frequency 50/60 Hz
setting range of the long-time protection threshold [ir] (thermal protection) 1 x In
upstream connection Façade
downstream connection Façade
instantaneous protection threshold setting range [ii] (short-circuit protection) 500 A
mounting bracket Plaque arrière
depth (p) 86 mm
Network type CA
CC
differential protection Sans
mounting position Horizontal et vertical
Flat on the back
power loss per pole 4,11 W
tr long time protection time delay setting Fixe
instantaneous protection sensor setting ii (short circuit protection) Fixe
ir long time protection sensor setting (thermal protection) Fixe
order type Par maneton
kind of protection L : for protection surcharge (thermique)
I : for protection (magnétique) court-circuit
Poles description 1P
Environment
degree of pollution 3 se conformer à CEI 60664-1
ip degree of protection IP40 se conformer à CEI 60529
operating altitude 0...2000 m sans réduction de courant
2000 m...5000 m avec réduction de courant
product certificates CCC
EAC
Marine
class of protection against electric shock Classe II
operating ambient temperature -25…70 °C
overvoltage category Classe II
standards EN/CEI 60947
relative humidity 0…95 %
shock resistance ik IK07 se conformer à CEI 62262
storage room temperature -50…85 °C
About this product

The C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting is developed to satisfy the conditions of industry experts, such as electrical contractors, circuit experts, maintenance service providers, and industry fabricators. C10M1TM050 yields unmatched capability and profit for specialists in the automation and control industry. This ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting and other Compact NSX from Schneider Electric can be bought at the most advantageous pricing and shipping time through BALTELEC, a trustworthy vendor catering to consultants in their buying needs.

Clients who have used Schneider Electric Compact NSX have repeatedly commended the brand's trustworthiness. It has been specified that the excellent efficiency of C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting extends to a array of tasks. Its high-end traits make it appropriate for assorted uses, securing success in your industrial, tertiary, and automation endeavors.

BALTELEC focuses in meeting industrial and tertiary professionals’ needs. We get the distinct needs and expectations of our stakeholders in the domain. By working with our specialists, your business acquire access to the top rates and stock of high-quality products like C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting from Schneider Electric at a competitive price. Our registered accounts enjoy additional savings and preferred assistance.

Move quickly and purchase C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting at our protected and hassle-free virtual storefront. Don't delay in making this wise investment that guarantees the greatest quality and matches the specific specifications of buyers like your group.

In case you have any doubts or concerns about C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting or any other Schneider Electric products, get in touch with us or refer to our Help section section below. We have provided answers to popular queries to support you further in making an well-considered decision about industrial and tertiary electrical components.

Remember, C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting from Schneider Electric is unfailing, reasonable, and better to other manufacturers in the Compact NSX category. Make it a part of your arrangement today. Shop with confidence at BaltElec, your reliable retailer for all your Compact NSX.

In our Baltelec.eu cyber store you will come across ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting - C10M1TM050 worth 155.32 €, which will be a sure and modern solution for your expectations. This merchandise is constructed by the Schneider Electric brand using the latest technologies and obeys the optimal standards of well-being and performance. We extend produce from the Compact NSX category that integrate lastingness and operability, which is an excellent possibility for various operations. Not minding of whether you desire equipment for small construction or for competent industrial application, ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting will be a dependable helper in your project.

Baltelec labors to make the buying process as accessible and fast as practicable for our customers. We offer detailed accounts and high-quality photographs of ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting so that you can make an knowledgeable choice. A team of authorities is always ready to help you with any questions in the Compact NSX section referencing to the nomination and use of wares. We are confident that ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting will meet your standards and become an essential element of your setup for just 155.32 €.

What People Ask about Schneider Electric C10M1TM050:

  • Why should I buy C10M1TM050 from BALTELEC?

    When your purchase C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting from Baltelec website, you get authentic quality Schneider Electric Compact NSX products at the finest pricing and lead time. Furthermore, our buyersget further discounts and expedited requests handling.

  • Can BaltElec advise if C10M1TM050 is suitable for my project?

    To confirm that C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting is appropriate for your use case, we offer comprehensive information concerning product's specifications, technical characteristics, and applicable standards. You can access this information on the specific page of the item model. If you seek further assistance, our customer support team stands ready to assist you in reaching an informed decision.

  • What warranty coverage is provided for C10M1TM050?

    Baltelec.eu team emphasizes the reliability of the products we sell. The standard warranty coverage for Schneider Electric Compact NSX including C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting is 1 year. Nonetheless, it varies according to the individual item, category, and may even be extended. You can find comprehensive warranty information on the C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting dedicated page or by contacting our support team representatives.

  • Can you provide global shipping for Schneider Electric C10M1TM050 as well as other Schneider Electric products?

    Absolutely. In addition to catering to Estonia, Latvia, Lithuania and other European Union countries, we provide international shipping for Schneider Electric C10M1TM050. Please keep in mind that delivery options, fees, and delivery schedule might differ based on the destination. For complex requests, kindly contact BALTELEC sales representatives.

  • Do Schneider Electric MBC offered by Baltelec.eu adhere to international standards for safety and quality?

    Certainly. All Schneider Electric items available at BALTELEC online store adhere to global norms such as IEC 60898-1 and carry the CE certification. Such norms assure that the items fulfill stringent safety, technical, reliability, and functional criteria.

  • Can BALTELEC provide support on incorporating renewable energy solutions, such as solar energy systems or wind energy converters, into my projects?

    Absolutely!  Baltelec website acknowledges the significance of sustainable energy integration within community. Our team of specialists can support you in selecting the appropriate Schneider Electric products, to integrate them into your renewable energy projects}. We can offer advice on combining solar energy systems, wind power converters, and additional eco-friendly options to optimize power generation and effectiveness.

  • Are there eco-friendly options offered within the Compact NSX category to promote environmental sustainability?

    Definitely!Yes! BaltElec provides a wide range of eco-friendly solutions in the category of Compact NSX that align with green energy initiatives. Our top-quality Schneider Electric products, including the C10M1TM050 - ComPacT NSX100M - circuit breaker - TM-D 50A - 1P1D - 85kA - fixed mounting, are designed with energy efficiency in mind. By incorporating these products into your electrical system, you can enhance energy usage and lower environmental impact. Additionally, we present affordable pricing for our eco-friendly Schneider Electric products,, making them an cost-effective choice for promoting sustainability.

  • Is C10M1TM050 available by Baltelec online store legitimate?

    Absolutely, we exclusively sell original Schneider Electric products, including C10M1TM050. We obtain our products only through official distribution channels to ensure their authenticity and excellent quality.
