C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A - Schneider Electric

Expected in 2-4 weeks
C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A - Schneider Electric - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A - Schneider Electric - 0
C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A - Schneider Electric
2 659,55 € excl. VAT
3 297,84 € incl. VAT
Text About:
Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A - Schneider Electric
3 297,84 €
SPECIFICATIONS
Main
(in) rated current up to 65 °c 800 A at 50 °C
Range ComPacT
[icu] rated ultimate short-circuit breaking capacity 150 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
150 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
130 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
100 kA Icu at 500/525 V AC 50/60 Hz conforming to IEC 60947-2
Protected poles description 3D
Product Name ComPacT NS new generation
Trip unit name MicroLogic 5.0 A
Trip unit technology Electronic
Trip unit rating 800 A at 50 °C
[ui] rated insulation voltage 800 V AC 50/60 Hz conforming to IEC 60947-2
number of poles 3P
Trip unit protection functions LSI
performance level L 150 kA 415 V AC
Complementary
[ics] rated service short-circuit breaking capacity 150 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
150 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
130 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
100 kA at 500/525 V AC 50/60 Hz conforming to IEC 60947-2
[ue] rated operational voltage 690 V AC 50/60 Hz
[icw] rated short-time withstand current 19.2 kA 1 s conforming to IEC 60947-2
Control type Manually operated
depth (d) 147 mm
Product certifications IECEE CB Scheme
[ii] instantaneous protection pick-up adjustment range Off
2...15 x In
[ir] long-time protection pick-up adjustment range 0.4...1 x In
Connection pitch 70 mm
Product or component type Circuit breaker
[isd] short-time protection pick-up adjustment range 1.5...10 x Ir
[uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
Auxiliary contact composition 1 NO/NC
height (h) 327 mm
[tr] long-time protection delay adjustment range 12.5…600 s at 1.5 x Ir
0.5…24 s at 6 x Ir
0.7…16.6 s at 7.2 x Ir
[tsd] short-time protection delay adjustment range 0.1…0.4 s I²t=on
0…0.4 s I²t=off
Device application Distribution
type of measurement Ammeter
width (w) 210 mm
network frequency 50/60 Hz
thermal memory 20 mn
Ik degree of protection IK07 conforming to EN 50102
Local signalling 4 LEDs (red) for fault indication
1 LED (yellow) for overload
Mounting mode Fixed
power losses 20 W
long-time pick-up adjustment type ir (thermal protection) Adjustable 9 settings
Net weight 14 kg
long-time protection delay adjustment type tr Adjustable 9 settings
Downside connection Front
Display type LCD display
Earth-leakage protection Without
Mounting support Backplate
mechanical durability 10000 cycles
electrical durability 2000 cycles at 690 V In
3000 cycles at 690 V In/2
3000 cycles at 440 V In
4000 cycles at 440 V In/2
Network type AC
instantaneous protection pick-up adjustment type ii Adjustable
Pollution degree 3 conforming to IEC 60947
short-time protection delay adjustment type tsd Adjustable
short-time protection pick-up adjustment type isd Adjustable 9 settings
Suitability for isolation Yes conforming to EN/IEC 60947-2
Upside connection Front
Utilisation category Category A
Protection type L : for overload protection (long time)
S : for short time short-circuit protection
I : for instantaneous short-circuit protection
Zone selective interlocking zsi With
Environment
ip degree of protection IP40 conforming to IEC 60529
operating altitude 0...2000 m without derating
2000 m...5000 m with derating
Range of product ComPacT NS630b...1600 new generation
ambient air temperature for operation -25…70 °C
ambient air temperature for storage -40…85 °C
standards EN/IEC 60947-2
relative humidity 0…95 %
About this product

The C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A is conceived to cover the necessities of trade buyers, such as electrical contractors, electrical installers, upkeep firms, and primary equipment suppliers. C080L35AFM delivers superb reliability and benefits for engineers in the automation and control industry. This Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A and other ComPacT NS new generation from Schneider Electric are procurable the best price and shipping time through baltelec.eu, a well-regarded merchant meeting the needs of industry experts in their supply needs.

Professionals who have adopted Schneider Electric ComPacT NS new generation have repeatedly appreciated the maker's sturdiness. It has been remarked that the superlative effectiveness of C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A extends to a assortment of utilizations. Its elite characteristics make it ideal solution to cater to varied requirements, guaranteeing the success of your industrial, tertiary, and automation contracts.

Our experts focuses in fulfilling industrial and tertiary professionals’ needs. We grasp the individual standards and standards of our consumers in the market. By working with BALTELEC, our customers get access to the best rates and delivery schedule of the top-of-the-line products like C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A from Schneider Electric at an economical price. Registered customers take pleasure in added discounts and preferred assistance.

Begin today and acquire C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A at our secure and easy-to-use virtual storefront. Don't delay in making this astute option that affirms the utmost quality and addresses the specific expectations of vendors like your firm.

Should there be any questions or concerns about C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A or any other Schneider Electric products, get in touch with us or refer to our Information center section below. We have gathered answers to routine inquiries to help you further in making an wise decision about industrial and tertiary electrical components.

Remember, C080L35AFM - Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A from Schneider Electric is consistent, reasonable, and top-notch to other producers in the ComPacT NS new generation category. Make it a part of your setup immediately. Acquire at Baltelec e-shop, your preferred supplier for all your Schneider Electric.

In our Baltelec.eu cyber store you will locate Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A - C080L35AFM worth 3,244.64 €, which will be a secure and up-to-date solution for your demands. This thing is developed by the Schneider Electric brand using the state-of-the-art technologies and conforms to the maximum standards of reliability and competence. We offer goods from the ComPacT NS new generation category that blend resilience and operability, which is an first-rate pick for various objectives. Not minding of whether you seek equipment for small creation or for professional industrial exertion, Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A will be a sure adjunct in your occupation.

Baltelec endeavors to make the shopping process as effortless and fast as achievable for our customers. We offer detailed depictions and high-quality photographs of Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A so that you can make an conscious choice. A team of specialists is always ready to help you with any matter in the ComPacT NS new generation section linked to the deciding and use of wares. We are affirmed that Circuit breaker, ComPacT NS800L, 150kA at 415VAC, 3P, fixed, manually operated, MicroLogic 5.0A control unit, 800A will meet your expectations and become an vital element of your hardware for just 3,244.64 €.
