SPECIFICATIONS
Main
product specific application
Background suppression laser
Series name
Application packagingApplication assemblyapplication, high performance
sensor name
XUM
detection system
Diffuse with background suppression
electronic sensor type
Photo-electric sensor
Complementary
Add on output
, 35 mA
Output type
Discrete
Discrete output function
1 NO or 1 NC programmable
Enclosure material
Glass filled technopolymer
lens material
PMMA
Discrete output type
PNP
electrical connection
M8, 4 pins
Voltage drop
<2V
Shock resistance
30 gn (duration = 11ms) for 6 shocks on each axis conforming to EN/IEC 60068-2-27
Setting-up
Sensitivity adjustment by potentiometer
Sensor design
Miniature
Supply circuit type
DC
Environment
Emission
Red laser diffuse with background suppression class 1 650nm conforming to EN/IEC 60825-1
ip degree of protection
IP65
vibration resistance
+/-0.5 mm, amplitude = +/- 0.5 mm (f= 10-55Hz) for every axis conforming to EN 60068-2-6
