A9S70790 - Acti9 iSW NA - switch-disconnector - 3P+N - 100A 415VAC - Schneider Electric

Pending restock EAN: 3606480098970

EAN: 3606480098970

82,08 € excl. VAT

101,78 € incl. VAT

Text About:

Acti9 iSW NA - switch-disconnector - 3P+N - 100A 415VAC - Schneider Electric

In cart

101,78 €

SPECIFICATIONS

Main

Range Acti9

sectioning ability Oui se conformer à EN/CEI 60947-3

job category AC-22A se conformer à EN/CEI 60947-3

name of the device iSW-NA

type of product or equipment Interrupteur-sectionneur

Product Name Acti 9 iSW-NA

[ui] rated insulation voltage 500 V CA 50/60 Hz se conformer à EN/CEI 60947-3

neutral pole position Gauche

Complementary

9 mm pitches 8

associated accessories Déclenchement

[icm] rated short circuit making capacity 5 kA sectionneur seulement

[ie] rated operational current 100 A à 400/415 V CA 50/60 Hz

[ue] rated operational voltage 400/415 V CA 50/60 Hz

application Contrôle
Isolation

[icw] rated short-time withstand current 1,5 kA pendant 1s

Handle front plate colour 85 mm

tightening torque 3,5 N.m

[uimp] rated impulse withstand voltage 6 kV se conformer à EN/CEI 60947-3

compatibility of distributors, combs, busbars Haut ou bas : oui

product weight 0,3 kg

fully apparent cut Oui

mode d'installation Encliquetable

electrical life 10000 cycle

connection mode Borne du type à cage (haut ou bas) 1 câble(s) 1…25 mm² souple avec extrémité de câble
Borne du type à cage (haut ou bas) 1 câble(s) 1…25 mm² souple sans extrémité de câble
Borne du type à cage (haut ou bas) 1 câble(s) 1…35 mm² rigide sans extrémité de câble

mechanical endurance 20000 cycle

width (w) 72 mm

Colour Blanc

voltage indication Indication ON/OFF

wire stripping length 14 mm

depth 74 mm

mounting bracket Rail DIN

order type Par maneton
Déclenchement à distance

Poles description 3P + N

Environment

degree of pollution 3 se conformer à CEI 60947-3

ip degree of protection IP20

standards EN 60947-3
CEI 60947-3

relative humidity 95 % à 55 °C

operating ambient air temperature -35…70 °C

storage room temperature -40…85 °C

tropicalization 2
