A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz - Schneider Electric

Expected in 2-4 weeks EAN: 3606480096891
A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz - Schneider Electric - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz - Schneider Electric - 0
EAN: 3606480096891
A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz - Schneider Electric
66,24 € excl. VAT
80,81 € incl. VAT
Text About:
Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz - Schneider Electric
80,81 €
SPECIFICATIONS
Main
product range Acti9
[uc] control circuit voltage 220...240 V CA 50 Hz
name of the device iCT
type of product or equipment Contacteur
composition of the poles 4F
Product Name Acti9 iCT
[ui] rated insulation voltage 500 V CA 50/60 Hz
poles 4P
Complementary
9 mm pitches 6
associated accessories IACTc
IATEt
IACTs
IACTp
[ie] rated operational current 63 A AC-7A
20 A AC-7B
[ue] rated operational voltage 400 V CA 50 Hz
application Moteur-chauffage-éclairage
compatibility code ICT
control signal type Maintenu
Handle front plate colour 85 mm
tightening torque 0,8 N.m télécommande :
3,5 N.m circuit de puissance :
[uimp] rated impulse withstand voltage 4 kV
market segment Résidentiel
Petit commerce
average fuel consumption when going 6,5 VA
mode d'installation Encliquetable
electrical life 100000 cycle CEI/EN 61095 63 A 50 Hz AC-7A
30000 cycle CEI/EN 61095 20 A 50 Hz AC-7B
30000 cycle CEI/EN 61095 50 Hz AC-7C
100000 cycle EN/CEI 60947-4-1 50 Hz AC-1
30000 cycle EN/CEI 60947-4-1 50 Hz AC-3
30000 cycle EN/CEI 60947-4-1 50 Hz AC-5A
30000 cycle EN/CEI 60947-4-1 50 Hz AC-5B
connection mode Télécommande: borne du type à cage2 câble(s) 1,5 mm² rigide
Télécommande: borne du type à cage1 câble(s) 1,5…2,5 mm² rigide
Circuit de puissance: borne du type à cage1 câble(s) 6…16 mm² souple
Circuit de puissance: borne du type à cage1 câble(s) 6…25 mm² rigide
Télécommande: borne du type à cage2 câble(s) 1,5…2,5 mm² souple
mechanical endurance 1000000 cycle
width (w) 54 mm
network frequency 50 Hz
switching frequency 100 commutations/jour
Colour Blanc
maximum power 2,1 W à 400 V CA
voltage indication Indicateur d'action
depth 60 mm
mounting bracket Rail DIN symétrique 35 mm
Network type CA
calling power goes 53 VA
order type Commande manuelle et à distance
Environment
degree of pollution 2
ip degree of protection IP20
operating altitude 2000 m
operating ambient temperature -5…60 °C
standards CEI/EN 61095
relative humidity 95 % à 55 °C
thermal dissipation 2,1 W à 50/60 Hz
storage room temperature -40…70 °C
sound pressure 30 dB
tropicalization 2 se conformer à EN 60947-4-1
2 se conformer à EN 61095
2 se conformer à CEI 1095
About this product

The A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz is designed to match the wants of professional buyers, such as switchboard fabricators, wiremen, service providers, and industry fabricators. A9C21864 grants superior integrity and beneficence for technicians in the power systems industry. This Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz and other iCT from Schneider Electric can be purchased at the most advantageous pricing and lead time through BaltElec, a well-regarded retailer attending to practitioners in their acquisition needs.

Users who have used Schneider Electric iCT have invariably commended the maker's durability. It has been mentioned that the outstanding competence of A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz extends to a assortment of operations. Its premium specifications make it ideal solution for various requirements, ensuring your industrial, tertiary and automation projects success.

Our experts dedicates in providing for industrial and tertiary professionals’ needs. We grasp the special demands and desires of our consumers in the niche. By working with us, your organization get access to the optimal rates and delivery schedule of high-quality products like A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz from Schneider Electric at an affordable price. Authorized buyers appreciate extra discounts and first-class attention.

Do not hesitate and grab A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz at our well-established and streamlined virtual storefront. Don't delay in making this astute plan that guarantees the supreme quality and satisfies the personalized requirements of clients like your business.

If you encounter any questions or concerns about A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz or any other Schneider Electric products, connect with us or refer to our Frequently Asked Queries section below. We have compiled answers to popular inquiries to support you further in making an well-informed decision about industrial and tertiary electrical components.

Remember, A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz from Schneider Electric is sure, affordable, and superior to other vendors in the iCT category. Feel free to make it a part of your network straight away. Purchase at BALTELEC, your reliable retailer for all your iCT.

In our Baltelec.eu dot-com store you will come across Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz - A9C21864 worth 80.81 €, which will be a trustworthy and innovative solution for your expectations. This product is designed by the Schneider Electric brand using the modern technologies and conforms to the top standards of precaution and capacity. We furnish items from the iCT category that integrate toughness and efficacy, which is an exceptional decision for various intents. In spite of whether you necessitate instruments for small generation or for qualified industrial use, Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz will be a steadfast adjunct in your endeavor.

Baltelec works to make the securing process as manageable and fast as attainable for our consumers. We offer detailed portrayals and high-quality illustrations of Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz so that you can make an briefed choice. A team of connoisseurs is always ready to help you with any enquiries in the iCT section affiliated to the selection and use of goods. We are positive that Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz will meet your demands and become an crucial element of your device for just 80.81 €.

Frequently Asked Questions about A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz:

  • What are the advantages of ordering A9C21864 from Baltelec.eu online store?

    When purchasing Schneider Electric Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz from baltelec.eu, you receive authentic quality Schneider Electric iCT products at competitive prices and turnaround time. Additionally, our partnerstake pleasure in further discounts and preferred assistance.

  • Can you consult if Schneider Electric A9C21864 is the right choice for my needs?

    To ensure that Schneider Electric Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz is suitable for your application, we provide comprehensive details concerning product's technical specifications, technical characteristics, and interoperability. You can find this data on the specific page of the item name. If you require more guidance, our customer support representative is available to assist you in making an educated decision.

  • Which guarantee coverage is provided for A9C21864?

    BALTELEC emphasizes the excellence of the products we sell. The default warranty coverage for Schneider Electric iCT including Schneider Electric Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz is 1 year. Nevertheless, it is subject based on the particular product, product category, and might be extended. You can find comprehensive warranty information on the A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz dedicated page or by reaching out to our customer support representatives.

  • Can you arrange international shipping for Schneider Electric A9C21864 as well as other Schneider Electric products?

    Yes. Besides catering to Estonia, Latvia, Lithuania and other European Union countries, we provide global shipping for Schneider Electric Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz. Please keep in mind that delivery options, costs, and shipping times can differ based on the shipping location. In the case of volume inquiries, please consult Baltelec.eu sales team.

  • Do Schneider Electric MBC offered by Baltelec.eu meet international norms for safety and quality?

    Completely. All Schneider Electric items offered at Baltelec web store conform to global standards such as IEC 60898-1 standard and carry the CE certification. These norms assure that the items meet rigorous security, technical, dependability, and performance criteria.

  • Can BALTELEC provide support on incorporating renewable energy solutions, such as solar energy systems or wind power converters, into my projects?

    Certainly!  Baltelec online store recognizes the significance of clean energy integration within community. Our group of professionals can support you in choosing the right Schneider Electric items, to integrate them into your renewable energy solutions}. We can provide advice on integrating solar power systems, wind power converters, and additional sustainable options to maximize power generation and effectiveness.

  • Do you have green options offered within the iCT category to encourage energy conservation efforts?

    Certainly! BaltElec provides various energy-efficient solutions in the category of iCT that are in line with green energy initiatives. Our Schneider Electric products, like the A9C21864 - Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz, are crafted with environmental friendliness in mind. By using these products into your electrical system, you can optimize energy usage and reduce environmental impact. Additionally, we present competitive pricing for our energy-efficient Schneider Electric products,, making them an budget-friendly choice for advocating sustainability.

  • Are Acti9, iCT manually operated contactor 63A 4NO 220...240VAC 50Hz available by BALTELEC original?

    Absolutely, we exclusively sell original Schneider Electric products, including but not limited to A9C21864. We procure our products solely through official distribution channels to guarantee their authenticity and superior quality.
