83196 - Unika interlocked socket 32 A 3P + E 380...415 V AC IP65 wall - Schneider Electric

Expected in 2-4 weeks

64,55 € excl. VAT

78,76 € incl. VAT

Text About:

Unika interlocked socket 32 A 3P + E 380...415 V AC IP65 wall - Schneider Electric

In cart

78,76 €

SPECIFICATIONS

Main

Device short name Unika socket

Outlet standard Industrial

Range PratiKa

Plug, socket category Low voltage

Complementary

[in] rated current 32 A

[ue] rated operational voltage 380...415 V

Base dimension 103 x 255 mm

Handle front plate colour 255 mm

Product or component type Interlocked socket

cable entry Cable gland

Connections - terminals Captive screws

Contacts material Sleeves: nickel plated brass

width (w) 103 mm

network frequency 50/60 Hz

Colour Grey (RAL 7035)

fuse size 10.3 x 38 mm

Fuse type Cylindrical

Ground lug clockwise position 6 h

Ik degree of protection IK09 conforming to EN 62262

Mounting mode Wall-mounted

Net weight 1.277 kg

depth 151 mm

Maximum cable cross section 10 mm²

Maximum cable outer diameter 25 mm

Network type AC

Plug, socket material Housing: self-extinguishing engineering polymer

thread type Pg 21

Voltage colour Red

Poles description 3P + E

Protection type Fuse

Environment

ip degree of protection IP65 conforming to IEC 60529

ambient air temperature for operation 35 °C ( 86400 s )
-25…40 °C

standards IEC 60309-1
IEC 60309-2

fire resistance 750 °C conforming to IEC 60695-2-11

relative humidity 50 % at 40 °C
70 % at 30 °C
90 % at 20 °C
