83145 - Unika interlocked socket 32 A 2P + E 380...415 V AC IP44 wall - Schneider Electric
Expected in 2-4 weeks
60,38 € excl. VAT
73,66 € incl. VAT
Text About:
Unika interlocked socket 32 A 2P + E 380...415 V AC IP44 wall - Schneider Electric
SPECIFICATIONS
Main
Device short name
Unika socket
Outlet standard
Industrial
Range
PratiKa
Plug, socket category
Low voltage
Complementary
[in] rated current
32 A
[ue] rated operational voltage
380...415 V
Base dimension
103 x 255 mm
Handle front plate colour
255 mm
Product or component type
Interlocked socket
cable entry
Cable gland
Connections - terminals
Captive screws
Contacts material
Sleeves: nickel plated brass
width (w)
103 mm
network frequency
50/60 Hz
Colour
Grey (RAL 7035)
fuse size
10.3 x 38 mm
Fuse type
Cylindrical
Ground lug clockwise position
9 h
Ik degree of protection
IK09 conforming to EN 62262
Mounting mode
Wall-mounted
Net weight
1.172 kg
depth
151 mm
Maximum cable cross section
10 mm²
Maximum cable outer diameter
25 mm
Network type
AC
Plug, socket material
Housing: self-extinguishing engineering polymer
thread type
Pg 21
Voltage colour
Red
Poles description
2P + E
Protection type
Fuse
Environment
ip degree of protection
IP44 conforming to IEC 60529
ambient air temperature for operation
35 °C ( 86400 s )
-25…40 °C
-25…40 °C
standards
IEC 60309-1
IEC 60309-2
IEC 60309-2
fire resistance
750 °C conforming to IEC 60695-2-11
relative humidity
50 % at 40 °C
70 % at 30 °C
90 % at 20 °C
70 % at 30 °C
90 % at 20 °C
