82115 - PratiKa industrial socket 32 A 2P 20...25 V AC IP44 - Schneider Electric

Expected in 2-4 weeks

9,84 €

Text About:

PratiKa industrial socket 32 A 2P 20...25 V AC IP44 - Schneider Electric

In cart

9,84 €

SPECIFICATIONS

Main

Device short name PratiKa socket

Outlet standard Industrial

Range PratiKa

Plug, socket category Extra-low voltage

Complementary

[in] rated current 32 A

[ue] rated operational voltage 20...25 V

Base dimension 70 x 82 mm

Cable cross section 4…10 mm²

Handle front plate colour 118 mm

Product or component type Socket

cable entry Fair lead

Connections - terminals Captive screws, completely loosened

cable outer diameter 6…23 mm

Contacts material Pins: stainless steel
Sleeves: nickel plated brass
Springs: stainless steel

width (w) 70 mm

network frequency 50/60 Hz

Colour Grey (RAL 7035)

Ik degree of protection IK08 conforming to EN 62262

Mounting mode Wall-mounted

Net weight 0.199 kg

depth 81 mm

Network type AC

Plug, socket material Housing: self-extinguishing engineering polymer

thread type Pg 21

Plug, socket, control station shape Angled

Voltage colour Violet

Poles description 2P

Environment

ip degree of protection IP44 conforming to IEC 60529

ambient air temperature for operation 35 °C ( 86400 s )

standards EN 60309-2
EN 60309-1

fire resistance 850 °C conforming to IEC 60695-2-11

relative humidity 50 % at 40 °C
70 % at 30 °C
90 % at 20 °C
