82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel - Schneider Electric

Expected in 2-4 weeks
82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel - Schneider Electric - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel - Schneider Electric - 0
82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel - Schneider Electric
35,85 € excl. VAT
44,45 € incl. VAT
Text About:
Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel - Schneider Electric
44,45 €
SPECIFICATIONS
Main
Device short name Unika socket
Outlet standard Industrial
Range PratiKa
Plug, socket category Low voltage
Complementary
[in] rated current 16 A
[ue] rated operational voltage 100...130 V
Base dimension 103 x 225 mm
Handle front plate colour 225 mm
Product or component type Interlocked socket
cable entry Cable gland
Connections - terminals Captive screws
Contacts material Sleeves: nickel plated brass
width (w) 103 mm
network frequency 50/60 Hz
Colour Grey (RAL 7035)
Ground lug clockwise position 4 h
Ik degree of protection IK09 conforming to EN 62262
Mounting mode Panel-mounted
Net weight 0.644 kg
depth 127 mm
Maximum cable cross section 10 mm²
Maximum cable outer diameter 25 mm
Network type AC
Plug, socket material Housing: self-extinguishing engineering polymer
thread type Pg 21
Voltage colour Yellow
Poles description 3P + E
Protection type Without protection
Environment
ip degree of protection IP44 conforming to IEC 60529
ambient air temperature for operation 35 °C ( 86400 s )
-25…40 °C
standards IEC 60309-1
IEC 60309-2
fire resistance 750 °C conforming to IEC 60695-2-11
relative humidity 50 % at 40 °C
70 % at 30 °C
90 % at 20 °C
About this product

The 82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel is designed to match the necessities of specialized professionals, such as system integrators, wiremen, service organizations, and equipment creators. 82029 supplies extraordinary quality and merit for specialists in the electromechanical industry. This Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel and other Pratika LV Sockets And Plugs from Schneider Electric can be bought at the optimal price and delivery period through BaltElec online store, a reputable merchant assisting tradesmen in their acquisition needs.

Professionals who have purchased Schneider Electric Pratika LV Sockets And Plugs have continuously extolled the creator's soundness. It has been specified that the excellent competence of 82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel extends to a spectrum of applications. Its superior qualities make it fitting to suit a variety of needs, assuring the success of your industrial, tertiary, and automation ventures.

Our specialists dedicates in accommodating industrial and tertiary professionals’ needs. We comprehend the distinct requirements and standards of our partners in the niche. By collaborating with BALTELEC, your organization acquire access to the optimal pricing and inventory of premium products like 82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel from Schneider Electric at an affordable price. Registered customers take pleasure in special savings and priority service.

Do not hesitate and acquire 82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel at our well-established and convenient online store. Don't delay in making this prudent resolution that promises the supreme quality and satisfies the personalized requirements of customers like your business.

If you encounter any issues or concerns about 82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel or any other Schneider Electric products, communicate with us or refer to our Common Questions section below. We have brought together answers to regular inquiries to serve you further in making an enlightened decision about industrial and tertiary electrical components.

Remember, 82029 - Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel from Schneider Electric is secure, thrifty, and high-quality to its competitors in the Pratika LV Sockets And Plugs category. Don't hesitate to make it a part of your arrangement now. Acquire at baltele.eu, your steady distributor for all your Pratika LV Sockets And Plugs.

In our Baltelec.eu web store you will discover Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel - 82029 worth 43.73 €, which will be a reliable and innovative solution for your needs. This produce is designed by the Schneider Electric brand using the most recent technologies and follows the peak standards of assurance and effectiveness. We supply commodities from the Pratika LV Sockets And Plugs category that associate sturdiness and utility, which is an superb selection for various objectives. In defiance of whether you need equipment for small manufacturing or for competent industrial application, Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel will be a safe aid in your project.

Baltelec strives to make the securing process as uncomplicated and fast as possible for our consumers. We offer detailed summaries and high-quality photos of Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel so that you can make an enlightened choice. A team of authorities is always ready to help you with any uncertainties in the Pratika LV Sockets And Plugs section associated to the preferment and use of supplies. We are convinced that Unika interlocked socket 16 A 3P + E 100...130 V AC IP44 panel will meet your expectations and become an necessary element of your machinery for just 43.73 €.
