34028 - Switch disconnector, ComPact NS2000NA, fixed, front connected, manually operated, 2000A, 4P, complete device - Schneider Electric

Expected in 2-4 weeks

5 823,10 € excl. VAT

7 104,18 € incl. VAT

Text About:

Switch disconnector, ComPact NS2000NA, fixed, front connected, manually operated, 2000A, 4P, complete device - Schneider Electric

In cart

7 104,18 €

SPECIFICATIONS

Main

Device short name Compact NS2000 NA

Offer type C5

Visible break No

Product Name ComPact NS

[ui] rated insulation voltage 800 V AC 50/60 Hz conforming to IEC 60947-3

Complementary

[icm] rated short circuit making capacity 135 kA 690 V AC at 50/60 Hz

[ie] rated operational current AC-23A: 2000 A AC 50/60 Hz 220/240 V
AC-23A: 2000 A AC 50/60 Hz 380/415 V
AC-23A: 2000 A AC 50/60 Hz 440/480 V
AC-23A: 2000 A AC 50/60 Hz 500/525 V
AC-23A: 2000 A AC 50/60 Hz 660/690 V

[ue] rated operational voltage 690 V AC 50/60 Hz conforming to IEC 60947-3

[icw] rated short-time withstand current 32 kA during 3 s conforming to IEC 60947-3

[ith] conventional thermal current 2000 A at 60 °C

Control type Toggle

Product certifications ASEFA
ASTA

Connection pitch 115 mm

Handle front plate colour 350 mm

Product or component type Switch disconnector

[uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-3

Contact position indication Yes

Device application Distribution

width (w) 535 mm

network frequency 50/60 Hz

Mounting mode Fixed

Net weight 36 kg

Downside connection Front

depth 160 mm

mechanical durability 6000 cycles conforming to IEC 60947-3

electrical durability AC-23A: 1000 cycles 440 V AC 50/60 Hz conforming to IEC 60947-3

Network type AC

Pollution degree 3 conforming to IEC 60947-3

Suitability for isolation Yes conforming to IEC 60947-3

Poles description 4P

Upside connection Front

Environment

Ambient air temp for storage/transportation -50…85 °C

ambient air temperature for operation -25…70 °C

standards IEC 60947-3
