18760 - Miniature circuit breaker (MCB), Acti9 NG125L, 3P, 16A, B curve, 50kA (IEC/EN 60947-2) - Schneider Electric

Expected in 2-4 weeks

154,44 € excl. VAT

188,42 € incl. VAT

Text About:

Miniature circuit breaker (MCB), Acti9 NG125L, 3P, 16A, B curve, 50kA (IEC/EN 60947-2) - Schneider Electric

In cart

188,42 €

SPECIFICATIONS

Additional Information

curve B

Main

Device short name NG125L

Range Acti9

Number of protected poles 3

Product Name Acti9 NG125

Trip unit technology Thermal-magnetic

[ui] rated insulation voltage 690 V AC 50/60 Hz conforming to EN/IEC 60947-2

Complementary

9 mm pitches 9

[in] rated current 16 A at 40 °C

[ue] rated operational voltage <= 375 V DC
380...415 V AC 50/60 Hz
500 V AC 50/60 Hz
220...240 V AC 50/60 Hz
440 V AC 50/60 Hz

[ics] rated service breaking capacity 75 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz
37.5 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz
30 kA 75 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz
11.25 kA 75 % conforming to EN/IEC 60947-2 - 500 V AC 50/60 Hz
50 kA 100 % conforming to EN/IEC 60947-2 - 375 V DC

Control type Manual tripping test
Toggle

Handle front plate colour 103 mm

Product or component type Miniature circuit-breaker

tightening torque 3.5 N.m

[uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2

Comb busbar and distribution block compatibility YES

Connections - terminals Tunnel type terminals1.5…50 mm² rigid
Tunnel type terminals1…35 mm² flexible

Locking options description Integrated padlocking

Contact position indication Yes

Device application Distribution

width (w) 81 mm

network frequency 50/60 Hz

Ik degree of protection IK05 conforming to EN/IEC 62262

Local signalling ON/OFF indication
Trip indicator

Mounting mode Clip-on

Net weight 0.72 kg

wire stripping length 20 mm

Earth-leakage protection Separate block

Mounting support 35 mm symmetrical DIN rail

depth 81 mm

mechanical durability 20000 cycles

electrical durability 10000 cycles

magnetic trip limit 4 x In

Network type DC
AC

Pollution degree 3 conforming to IEC 60947-2

Provision for padlocking Padlockable

Suitability for isolation Yes conforming to IEC 60947-2

Poles description 3P

Utilisation category Category A conforming to IEC 60947-2

Environment

Ambient air temp for storage/transportation -40…70 °C

ip degree of protection IP20 conforming to IEC 60529

operating altitude 2000 m

Range of product NG125

ambient air temperature for operation -30…70 °C

overvoltage category IV

standards EN/IEC 60947-2

Tropicalisation 2 conforming to IEC 60068-1

relative humidity 95 % at 55 °C
