170ADO54050 - Discrete output module Modicon Momentum 16 O solid state - Schneider Electric

Expected in 2-4 weeks

603,32 € excl. VAT

736,05 € incl. VAT

Text About:

Discrete output module Modicon Momentum 16 O solid state - Schneider Electric

In cart

736,05 €

SPECIFICATIONS

Main

Group of channels 2 groups of 8 outputs

Complementary

[ue] rated operational voltage 120 V AC

Product certifications CSA
UL
FM Class 1 Division 2

response time 1/2 x 1/f (= 0.5 of one line cycle) from state 0 to state 1
1/2 x 1/f (= 0.5 of one line cycle) from state 1 to state 0

Handle front plate colour 141.5 mm

maximum leakage current 1.9 mA 120 V AC

Product or component type Discrete output base AC

Current consumption 125 mA at 120 V AC

maximum voltage drop <1.5 V 0.5 A at state 1

current per channel 0.5 A

marking CE

minimum output current 30 mA

Discrete output current 4 A per group
8 A per module

width (w) 125 mm

Local signalling 16 LEDs for channel status

Net weight 0.284 kg

Discrete output type Triac

Discrete output voltage 120 V AC

Isolation between channels and bus 1780 V AC for 1 minute

Discrete output number 16

Power dissipation 7.5 W maximum
6 W typical

depth 47.5 mm

Output overload protection Internal fuse

Surge current 10 A for 2 cycles
15 A for 1 cycle
5 A for 3 cycles

Resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2

Terminals description plc n°1 (3)OUT_DIS#3
(4)OUT_DIS#4
(12)OUT_DIS#12
(8)OUT_DIS#8
TB
(10)OUT_DIS#10
( 1N)PW
(1)OUT_DIS#1
(9)OUT_DIS#9
(1L+)PW
(5)OUT_DIS#5
(13)OUT_DIS#13
( 15)OUT_DIS#15
(2)OUT_DIS#2
(11)OUT_DIS#11
(6)OUT_DIS#6
(7)OUT_DIS#7
(14)OUT_DIS#14
(16)OUT_DIS#16

Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3

Short-circuit protection Internal fuse, 5 A slow-blow per group

Environment

Ambient air temp for storage/transportation -40…85 °C

operating altitude <= 5000 m

Range of product Modicon Momentum automation platform

ambient air temperature for operation 0…60 °C

relative humidity 95 % without condensation

protective treatment TC
